Summary of Contents for Upper Bounce BOUNCE GALAXY UBSF01-3856-BT
- Page 3 Please read these warnings and the information in this manual in its entirety. Failure to comply with the following instructions may increase the risk of serious injury. This unit is designed for jogging in place and similar bouncing exercises. • DO NOT wear glasses or helmets when using the trampoline.
- Page 4 Assembled Frame Lower Handle Base Middle Handle Bar Upper Handle Bar Legs Metal Plate Center Base Tube Frame Cover Screw Driver Long Screw+ Bolt Set Short Screw+ Bolt Set Triangle Screws Wrench PART QTY. PRODUCT PARTS PART NO. DESCRIPTION (PCS) DRAWING...
- Page 5 ensure the frame is completely open & flat. Repeat the process when opening the other side. Turn the frame upside-down (Bounce Galaxy logos facing down), straighten the frame hinges and smooth out the mat. Use your knees and body weight to ASSEMBL Y STEPS STEP Before you unfold the frame, please...
- Page 7 Attach the sides of the lower handle bases to both sides of the frame with the metal plates (F) using the screw bolt sets (!) with the screw driver (I) and wrench (M) as shown on this diagram. Fasten the center base tube (G) on both sides using the short screw bolt sets (K) with...
