- Page 1 [ENG] NetPing Supply Voltage Sensor 995S2, User guide ...
-
Page 2: Table Of Contents
[ENG] [995S2] Installation and Connection ............. 12 Connection Order..........................12 Sensor Connection Diagrams ......................13 NetPing 2/PWR-220 v3/ETH, NetPing 2 IP PDU ETH 53R14, NetPing 2 IP PDU GSM3G 203R15........13 UniPing server solution v3, UniPing server solution v4/SMS..................14 NetPing IO v2..................................15 NetPing 8/PWR-220 v4/SMS............................. - Page 3 [ENG] NetPing Supply Voltage Sensor 995S2, User guide - – ...
-
Page 4: [Eng] [995S2] Introduction
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Introduction [ENG] [995S2] Introduction This guide will help you to get to know the features of the NetPing Supply Voltage Sensor 995S2, get an idea of its functionality and technical specifications, and prepare the device for operation. -
Page 5: [Eng] [995S2] Disclaimer And Copyright
User Guide, as well as firmware and software of devices and this User Guide belong to NetPing global Ltd. Сopying, replication and translation of this user guide to other languages are not allowed without a prior written permission are not allowed without a of a rightholder. -
Page 6: [Eng] [995S2] Overview And Key Features
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Overview and Key Features [ENG] [995S2] Overview and Key Features The physical configuration of the device is shown in the photo: Bottom view: View from above: [ENG] [995S2] Overview and Key Features... - Page 7 [ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Overview and Key Features Device specifications Meaning Threshold response (valid only for 178–193 V 995S2 modification, intended for 220 V network) Threshold release (valid only for 155–175 V 995S2 modification, intended for 220 V...
- Page 8 [ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Overview and Key Features Device specifications Meaning Weight 101 gram Device dimentions 89 х 50 х 31 [ENG] [995S2] Overview and Key Features – ...
-
Page 9: [Eng] [995S2] Connectors And Indication Elements
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Connectors and Indication Elements [ENG] [995S2] Connectors and Indication Elements View from above The sensor operation indicator is on when it is connected to the power supply. [ENG] [995S2] Connectors and Indication Elements... -
Page 10: Side View
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Connectors and Indication Elements Side view [ENG] [995S2] Connectors and Indication Elements – ... -
Page 11: The Type Of Output Contacts
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Connectors and Indication Elements The type of output contacts N.O.-C pair - normally opened contacts. Opened when voltage failure is detected. N.C.-C pair - normally closed contacts. Closed when registering a lack of voltage. -
Page 12: [Eng] [995S2] Installation And Connection
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Installation and Connection [ENG] [995S2] Installation and Connection The supply voltage sensor can be installed on a horizontal or vertical surface. Mounting holes are not provided. When you install the device, the following restrictions must be considered: •... -
Page 13: Sensor Connection Diagrams
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Installation and Connection Step 2. Open to the web interface of the monitoring device / IP PDU to start the configuration. The sensor settings in the device’s web interface are specified in the firmware description, the section “Working with Channels of Discrete Input-Output”... -
Page 14: Uniping Server Solution V3, Uniping Server Solution V4/Sms
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Installation and Connection • NetPing 2 IP PDU GSM3G 203R15 — http://www.netpingdevice.com/products/netping-2-ip-pdu- gsm3g-203r15 Sensor Loop Device Terminal Black (common) Red (N.C.) I 1...4 White (N.O.) I 1...4 UniPing server solution v3, UniPing server solution v4/SMS •... -
Page 15: Netping Io V2
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Installation and Connection Sensor Loop Device Terminal Black (common) Red (N.C.) IO 1...8 Белый (N.O.) IO 1...8 NetPing IO v2 • NetPing IO v2 — http://www.netpingdevice.com/products/netping-io-v2 [ENG] [995S2] Installation and Connection... -
Page 16: Netping 8/Pwr-220 V4/Sms
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Installation and Connection Sensor Loop Device Terminal Black (common) Red (N.C.) IO 1...4 White (N.O.) IO 1...4 NetPing 8/PWR-220 v4/SMS • NetPing 8/PWR-220 v4/SMS — http://www.netpingdevice.com/products/netping-8-pwr-220-v4-sms [ENG] [995S2] Installation and Connection... - Page 17 [ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Installation and Connection Sensor Loop Device Terminal Black (common) Red (N.C.) 1...4 White (N.O.) 1...4 [ENG] [995S2] Installation and Connection – ...
-
Page 18: [Eng] [995S2] Shipping Kit Of The Device
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Shipping Kit of the Device [ENG] [995S2] Shipping Kit of the Device This shipping kit includes: • NetPing Supply Voltage Sensor 995S2 with the soldered wire of 1.5 meters long — 1 pc.;... -
Page 19: [Eng] [995S2] Warranty
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Warranty [ENG] [995S2] Warranty The manufacturer guarantees normal operation of the product within 24 months from the date specified on the warranty sticker if a buyer follows operating and storage conditions. Manufacturer warranty applies only to failure of a device which occurred because of defects in manufacturing process of products and components used. -
Page 20: [Eng] [995S2] Safety Precautions
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Safety Precautions [ENG] [995S2] Safety Precautions The next information will allow users to avoid both injuries and damaging a device as well as connected equipment. • The device should only be used on the power supply specified by the manufacturer. Use of any other type of power may damage the product. -
Page 21: [Eng] [995S2] Operating And Storage Conditions
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Operating and storage conditions [ENG] [995S2] Operating and storage conditions This sensor is designed for continuous round-the-clock operation indoors. The sensor is resistant to air temperature from -30 °С to +50 °С (without moisture condensation, at normal humidity) under operating conditions. The sensor should be protected from the impact of moisture and direct sunlight. -
Page 22: [Eng] [995S2] Additional Documents And Links
[ENG] NetPing Supply Voltage Sensor 995S2, User guide -[ENG] [995S2] Additional Documents and Links [ENG] [995S2] Additional Documents and Links The page of the device 995S2: http://www.netpingdevice.com/products/voltage-sensor-995s2 Manufacturer's website: http://www.netpingdevice.com Technical support contacts: http://www.netpingdevice.com/support Phone: +886-2-23121582 E-mail: support@netpingdevice.com [ENG] [995S2] Additional Documents and Links...
