  • Page 1 INFCP and INFCP-xxxB ® INFINITY C Process Panel Meter Operator’ s Manual NEWPORT Electronics, Inc. http://www.newportUS.com/manuals Downloaded from Elcodis.com electronic components distributor...
  • Page 2 European New Approach Directives. NEWPORT will add the CE mark to every appropriate device upon certification. The information contained in this document is believed to be correct but NEWPORT Electronics, Inc. accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
  • Page 3 Table of Contents PREFACE Manual Objectives This manual shows you how to set up and use the Programmable Digital Meter. Standard Procedures: Checking voltage jumpers, or changing voltage power Mounting the panel Selecting the input type Selecting a decimal point position Scaling with known loads (on-line calibration) Scaling without known loads Enabling/disabling the front-panel tare...
  • Page 4 Table of Contents Table A-1. Sections of the Manual If you want to read about: Refer to section Unpacking; safety considerations Introduction Meter description and features About the Meter Main board power jumpers; panel Getting Started mounting, sensor input, main power and analog and relay output Input type;...

  • Page 5: Table Of Contents

    Table of Contents Table of Contents Section Page SEC 1 INTRODUCTION ..........1 Unpacking .
  • Page 6 Table of Contents Table of Contents Section Page Selecting a Display Color ........30 Using Setpoint 1 Configuration .
  • Page 7 Table of Contents List of Figures Figure Page Front-Panel with “Big” LED Display ......5 Front-Panel with Standard LED Display .
  • Page 8 Table of Contents List of Tables Table Page Sections of the Manuals ........ii Accessories and Add-Ons .
  • Page 9 Notes, Warnings and Cautions NOTES, WARNINGS and CAUTIONS Information that is especially important to note is identified by three labels: • NOTE • WARNING • CAUTION • IMPORTANT NOTE: provides you with information that is important to successfully setup Note and use the Programmable Digital Meter.
  • Page 10 viii Downloaded from Elcodis.com electronic components distributor...

  • Page 11: Sec

    Introduction SECTION 1. INTRODUCTION 1.1 UNPACKING Remove the Packing List and verify that all equipment has been received. If there are any questions about the shipment, use the phone numbers listed on the back cover to contact the Customer Service Department nearest you. Upon receipt of shipment, inspect the container and equipment for any signs of damage.

  • Page 12: Safety Considerations

    Introduction SAFETY CONSIDERATIONS This device is marked with the international caution symbol. It is important to read this manual before installing or commissioning this device as it contains important information relating to Safety and EMC (Electromagnetic Compatibility). This instrument is a panel mount device protected in accordance with EN 61010- 1:2001, electrical safety requirements for electrical equipment for measurement, control and laboratory.

  • Page 13: Sec

    About The Meter SECTION 2. ABOUT THE METER 2.1 DESCRIPTION The Digital Programmable Process meter is a value packed indicator/controller. Four full digits and broad scaling capability allow for display in virtually all engineering units. A wide variety of DC current and voltage input ranges cover typical process applications. Standard features include sensor excitation and front panel or remote tare.

  • Page 14: Available Accessories

    About The Meter 2.3 AVAILABLE ACCESSORIES Table 2-1. Accessories and Add-Ons Add-On Options Special Calibration/Configuration SPC4 NEMA-4 Splash Proof Cover SPC18 NEMA-4 Splash Proof Cover, NEW Accessories TP1A Trimplate panel adaptor. Adapts DIN1A/DIN2A cases to larger panel cutouts RP18 19-In. Rack Panel for one (1) 1/8 DIN instrument RP28 19-In.

  • Page 15: Front Of The Meter

    About The Meter 2.4 FRONT OF THE METER Figure 2-1 shows each part of the front of the three-color programmable “Big” LED display meter (Version B). Digital LED Display: -1.9.9.9 or 9.9.9.9 4-digit three color programmable, 21 mm (0.83") high LED display with programmable decimal point.
  • Page 16 About The Meter 2.4 FRONT OF THE METER(Continued) METER BUTTONS SETPTS Button In the Run Mode, this button will sequentially recall the previous setpoint settings. As necessary, use the /MAX and /TARE buttons to alter these settings, then press the SETPTS button to store new values.
  • Page 17 About The Meter 2.4 FRONT OF THE METER(Continued) MENU Button In the Run Mode, press the MENU button to terminate the current measuring process and enter you into the Configuration Mode. Note Only if you have not installed the lockout jumpers on the main board. In the Configuration Mode, press the MENU button to store changes in the nonvolatile memory and then advance you to the next menu item.

  • Page 18: Back Of The Meter

    About The Meter 2.5 BACK OF THE METER Figure 2-2 shows the label describing the connectors on the back of the meter. Table 2-2 on the following page gives a brief description of each connector at the back of the meter. Figure 2-3.
  • Page 19 About The Meter 2.5 BACK OF THE METER (Continued) Table 2-2. Connector Description Connector Description TB1-1 Setpoint 1: Normally open (N.O.1) connection TB1-2 Setpoint 1: Normally closed (N.C.1) connection TB1-3 Setpoint 1: Common (COM1) connection TB1-4 Setpoint 2: Normally open (N.O.2) connection TB1-5 Setpoint 2: Normally closed (N.C.2) connection TB1-6...

  • Page 20: Disassembly

    About The Meter The DIP switches are located at the S1 position (refer to Figure 3-2). Use a small instrument, such as a paper clip, to change the switches from open to closed. Table 2-3 lists DIP switch settings at the S1 position required to complete the setup of your meter. Table 2-3.

  • Page 21: Getting Started

    Getting Started SECTION 3. GETTING STARTED Caution: The meter has no power-on switch, so it will be in operation as soon you apply power. If you power off/on the meter, or perform a hard reset (press the RESET button twice), the meter shows RST , followed by PROC .

  • Page 22: Main Board Jumper Positions

    Getting Started 3.2 MAIN BOARD POWER JUMPERS (Continued) Figure 3-2 shows the location jumper positions on the main board. MAIN BOARD E D C B A Refer to table 3-1 TP10 TP11 Figure 3-2. Main Board Jumper Positions Attach cable to P1.
  • Page 23 Getting Started 3.2 MAIN BOARD POWER JUMPERS (Continued) S2 jumpers are used for testing purposes. Do not use as reading errors may result. S3 jumpers are used for the following (refer to Figure 3-2): To enable or disable the front panel push-buttons To allow for an extremely low resistance load for analog output To disable the MENU button To perform calibration procedure...

  • Page 24: Panel Mounting

    Getting Started 3.3 PANEL MOUNTING CONNECTOR LABEL PRODUCT CASE LABEL GASKET FRONT BEZEL Figure 3-4. Meter - Exploded View PANEL THICKNESS 1. Cut a hole in your panel, as 6,4 (.25) MAX shown in Figure 3-4. For 0,8 (.03) MIN specific dimensions refer to Figure 3-5.

  • Page 25: Connecting Sensor Inputs

    Getting Started 3.4 CONNECTING SENSOR INPUTS Figures 3-6 through 3-12 describe how to connect your sensors. 20mA N/C EXC SIG Figure 3-6. 3-Wire DC Input Connections with Internal Excitation 20mA N/C EXTERNAL SUPPLY Figure 3-7. 3-Wire DC Input Connections with External Excitation Downloaded from Elcodis.com electronic components distributor...
  • Page 26 Getting Started 3.4 CONNECTING SENSOR INPUTS (Continued) 20mA N/C VOLTAGE EXCITATION OUTPUT Figure 3-8. 4-Wire DC Input Connections with Internal Excitation 20mA N/C SENSOR EXTERNAL OUTPUT SUPPLY Figure 3-9. Wire DC Input Connections with External Excitation Downloaded from Elcodis.com electronic components distributor...

  • Page 27: Dc Current Input Connections With External Excitation

    Getting Started 3.4 CONNECTING SENSOR INPUTS (Continued) 20mA N/C 4-20mA Transmitter Figure 3-10. DC Current Input Connections with Internal Excitation 20mA N/C EXTERNAL 4-20mA SUPPLY Transmitter Figure 3-11. DC Current Input Connections with External Excitation Downloaded from Elcodis.com electronic components distributor...

  • Page 28: Connecting Main Power

    Getting Started 3.4 CONNECTING SENSOR INPUTS (Continued) 20mA N/C MAX. 20mA Figure 3-12. DC Current Input Connections with Current Source 3.5 CONNECTING MAIN POWER Connect the AC main power connections as shown in Figure 3-13. WARNING: Do not connect AC power to your device until you have completed all input and output connections.

  • Page 29: Main Power Connections - Dc Powered Unit

    Getting Started 3.5 CONNECTING MAIN POWER (Continued) Table 3-2 shows the wire color and respective terminal connections for both USA and Europe. Table 3-2. Main Power Connection - AC Powered Unit WIRE COLORS AC POWER EUROPE ~ AC Line Brown Black ~ AC Neutral Blue...

  • Page 30: Conecting External Tare Switch

    Getting Started 3.6 CONNECTING EXTERNAL TARE SWITCH Connect external tare connections as shown in Figure 3-15. 1 2 3 4 1 2 3 4 OPEN 7 8 9 10 11 12 5 6 7 8 CLOSED EXTERNAL TARE SWITCH Figure 3-15. External Tare Connections 3.7 CONNECTING ANALOG AND RELAY OUTPUTS If you have purchased a meter with analog or dual relay or isolated analog output, refer to the following drawings for output connections.

  • Page 31: Relay Output Connections

    Getting Started 3.7 CONNECTING ANALOG AND RELAY OUTPUTS (Continued) Relay 1 Relay 2 EXTERNAL LOAD COM2 FUSE 1 2 3 4 1 2 3 4 5 6 5 6 7 8 7 8 9 10 11 12 Figure 3-17. Relay Output Connections. 0—20mA 0—10VDC 4—20mA...

  • Page 32: Sec

    Configuring The Meter SECTION 4. CONFIGURING THE METER Refer to Table 6-1 for a summary list of menu configuration. Note INPT 4.1 SELECTING THE INPUT TYPE To select your appropriate input type signal, follow these steps: Before proceeding, set the input DIP switch settings at the back of your Note meter.

  • Page 33: Selecting A Decimal Point Position

    Configuring The Meter DEC.P 4.2 SELECTING A DECIMAL POINT POSITION Note Refer to Table 6-1 for a summary list of menu configuration. To select a decimal point display position, follow these steps: Press the MENU button until the meter shows DEC.P . Press the ∂TARE button.

  • Page 34: Scaling With Known Loads

    Configuring The Meter 4.3.1 Scaling with Known Loads (On-Line Calibration) For maximum resolution, find the maximum signal that will be applied to the Note meter input. • For regular voltage input, refer to the main body of Table 4-1. • For millivolt or milliamp input, refer to the main body of Table 4-2.
  • Page 35 Configuring The Meter 4.3.1 Scaling with Known Loads (On-Line Calibration) (Continued) To scale with known inputs: apply known loads to a transducer connected to a meter, or simulate the transducer output with a voltage or current simulator. To scale with known inputs, follow these steps: Apply a known load equal to approximately 0% of the transducer range.
  • Page 36 Configuring The Meter 4.3.1 Scaling with Known Loads (On-Line Calibration) (Continued) Apply a known load equal to approximately 100% of the transducer range. Press the ∂TARE button again. The meter shows the last stored value for Input 2. Press the ∂TARE button once more. The meter shows the actual signal being received.

  • Page 37: Scaling Without Known Loads

    Configuring The Meter 4.3.2 Scaling Without Known Loads To scale without known inputs, calculate input values based on the transducer specifications and manually enter them on the front-panel pushbuttons. The following example assumes a pressure transducer with these specifications: Pressure Range: 0 to 2000 PSI Output Span: 1 to 5 Vdc Determine the correct values for IN1 and IN!2 based on the transducer...

  • Page 38: Using Reading Configuration

    Configuring The Meter 4.3.2 Scaling Without Known Loads (Continued) Determine IN1 & IN!2 input range and resolution. The example selects the 0 to 10 V range and 10 uV resolution (R.2=4 ). Example: IN1 = (1 Volt) x (1000 cts/v) x (1.000) = 1000 IN!2 = (5 Volt) x (1000 cts/v) x (1.000) = 5000 RD1 = 0000 RD!2 = 2000...

  • Page 39: Enabling Or Disabling The Front-Panel Tare

    Configuring The Meter 4.4.1 Enabling or Disabling the Front-Panel Tare To enable or disable the front-panel tare, follow these steps: Press the MENU button until RD.CF displays. Press the ∂TARE button. The meter shows one of the following: R.1=T (Tare enabled) (Default) •...

  • Page 40: Displaying The Filtered/Unfiltered Input Signal

    Configuring The Meter 4.4.3 Displaying the Filtered/Unfiltered Input Signal To display the filtered/unfiltered signal input, follow these steps: Press the MENU button until RD.CF displays, then press the ∂TARE button three times. Press the ∂TARE button from R.2. One of the following displays: R.3=F (Filtered value) (Default) •...

  • Page 41: Using Setpoint 1 Configuration

    Configuring The Meter S1.CF 4.6 USING SETPOINT 1 CONFIGURATION Note Refer to Table 6-1 for a summary list of menu configuration. Setpoint 1 Configuration S1.CF is not active unless your meter has dual relay output capabilities. The LED's will display whether the S1.CF is active or not. You may use Setpoint 1 Configuration S1.CF for the following: •...

  • Page 42: Using Setpoint 2 Configuration

    Configuring The Meter S2.CF 4.7 USING SETPOINT 2 CONFIGURATION Note Refer to Table 6-1 for a summary list of menu configuration. Setpoint 2 Configuration S2.CF is not active unless your meter has dual relay output capabilities. The LED's will display whether the S2.CF is active or not. You may use Setpoint 2 Configuration S2.CF for the following: •...

  • Page 43: Setting The Setpoint 1 Deadband

    Configuring The Meter S1.DB 4.8 SETTING THE SETPOINT 1 DEADBAND Note Refer to Table 6-1 for a summary list of menu configuration. Setpoint 1 Deadband S1.DB is not active unless your meter has dual relay output capabilities. The LED's will display whether the S1.DB is active or not. The Setpoint 1 Default deadband is 0003.

  • Page 44: Alarm Example

    Configuring The Meter Figure 4-1. Alarm Example SETPOINT SIGNAL LEVEL ACTIVE BELOW ACTIVE ABOVE DEADBAND SETPOINT SIGNAL LEVEL ACTIVE BELOW ACTIVE ABOVE WITH DEADBAND 3 WITH DEADBAND 3 NOTE: DEADBAND WORKS AS HYSTERISIS SETPOINT SIGNAL LEVEL ACTIVE BELOW LATCHED ACTIVE ABOVE LATCHED Note To reset latched alarms you must: 1.

  • Page 45: Using Output Configuration

    Configuring The Meter OT.CF 4.10 USING OUTPUT CONFIGURATION Note Refer to Table 6-1 for a summary list of menu configuration. Output Configuration OT.CF is not active unless your meter has analog output capabilities. The menu will display whether analog output is present or not. Analog output must be ordered at the time of purchase.

  • Page 46: Selecting Analog Output As Current Or Voltage

    Configuring The Meter 4.10.2 Selecting Analog Output as Current or Voltage Press the MENU button until it shows OT.CF, then press the ∂TARE button twice. Press the ∂TARE button from 0.1 . The meter shows one of the following: O.2=C (Analog output = current) (Default) •...
  • Page 47 Configuring The Meter 4.10.3 Selecting Analog Output or Proportional Control (Continued) If you select O.3=A , press the MENU button to store your selection. The meter momentarily shows STRD , followed by OT.S.O (Output Scale and Offset). If you select O.3=P , press the ∂TARE button. The meter shows one of the following: O.4=D •...

  • Page 48: Selecting Proportional Band

    Configuring The Meter P.BND 4.11 SELECTING PROPORTIONAL BAND Proportional Band P.BND is not active unless your meter has analog output and relay capabilities. The menu will display whether analog output is present or not. • A proportional controller's output is linearly proportional to the change of the error signal, whenever the signal is within 2 prescribed values (Proportional Band).
  • Page 49 Configuring The Meter P.BND 4.11 SELECTING PROPORTIONAL BAND (Continued) If A is the controller gain then, Proportional Band = Max. out - Min. out CONTROLLER OUT = A • ERROR + OFFSET To select the proportional band for your proportional controller, follow these steps: Press the MENU button until the meter shows P.BND .

  • Page 50: Using Manual Reset

    Configuring The Meter M.RST 4.12 USING MANUAL RESET Note Refer to Table 6-1 for a summary list of menu configuration. Manual Reset M.RST is not active unless your meter has analog output and relay capabilities. The menu will display whether analog output is present or not. This feature allows you to offset the error that may occur with your setpoint.

  • Page 51: Using Output Scale And Offset

    Configuring The Meter OT.S.O 4.13 USING OUTPUT SCALE AND OFFSET Note Refer to Table 6-1 for a summary list of menu configuration. Output Scale and Offset OT.S.O is not active unless your meter has analog output capabilities. The menu will display whether analog output is present or not. Output Scale and Offset OT.S.O scales your analog output to be equal to the meter's display and/or any engineering units you require.
  • Page 52 Configuring The Meter OT.S.O 4.13 USING OUTPUT SCALE AND OFFSET (Continued) Press the ∂TARE button. The meter shows last previously stored 4-digit number (-1999 through 9999) displays with flashing 4th digit. Press the ßMAX button to change the value of the flashing digit. If you continue to press the ßMAX button, the flashing digit's value continues to change.

  • Page 53: Using Lock Out Configuration

    Configuring The Meter LK.CF 4.14 USING LOCK OUT CONFIGURATION Note Refer to Table 6-1 for a summary list of menu configuration. Use Lock Out Configuration LK.CF for the following: • To enable or disable setpoint changes • To enable or disable the RESET button in the Run Mode •...

  • Page 54: Software Version Or Setpoint Value

    Configuring The Meter 4.14.3 SETPOINT Display Function: Firmware version or Setpoint value Press the MENU button until the meter shows LK.CF (after OT.S.O ). Press the ∂ ∂ TARE button three times. The meter shows one of the following: • L.3=0 SETPTS button will display setpoint values. •...

  • Page 55: Display Messages

    Display Messages Display Messages SECTION 5. DISPLAY MESSAGES Table 5-1. Display Messages MESSAGE DESCRIPTION PROC Process Meter Hard (Power On) Reset INPT Input Type DEC.P Decimal Point RD.S.O Reading Scale and Offset RD.CF Reading Configuration COLR Display Color S1.CF Setpoint 1 Configuration S2.CF Setpoint 2 Configuration S1.DB...

  • Page 56: Menu Configuration Displays

    Menu Configuration Displays SECTION 6. MENU CONFIGURATION DISPLAYS Not all menu items display on standard meters. Table 6-1. Menu Configuration Displays (Defaults in Bold and Italics) ∂TARE ßMAX MENU 100M Show input choices: ±50M INPT ±5V 0-20 ( Default ) FFFF ( Default ) Show current decimal F.FFF...

  • Page 57: Sec

    Menu Configuration Displays SECTION 6. MENU CONFIGURATION DISPLAYS (Continued) Table 6-1. Menu Configuration Displays (Continued) (Defaults in Bold and Italics) ∂TARE ßMAX MENU R.1=T (Tare enabled) R.1= Reading Configuration R.1=N (Tare disabled) RD.CF R.2=0 (1 µV resolution for unipolar R.2= &...
  • Page 58 Menu Configuration Displays SECTION 6. MENU CONFIGURATION DISPLAYS (Continued) Table 6-1. Menu Configuration Displays (Continued) (Defaults in Bold and Italics) ∂TARE ßMAX MENU Press to scroll to the Press to change the value of the Setpoint 1 Deadband next digit to the right flashing digit S1.DB Press to scroll to the...
  • Page 59 Menu Configuration Displays SECTION 6. MENU CONFIGURATION DISPLAYS (Continued) Table 6-1. Menu Configuration Displays (Continued) (Defaults in Bold and Italics) ∂TARE ßMAX MENU P.BND Shows prior value entered. Changes the value Proportional Band Scrolls to the next digit to the right. of the flashing digit shown menu if 0.3=P M.RST...
  • Page 60 Menu Configuration Displays SECTION 6. MENU CONFIGURATION DISPLAYS (Continued) Table 6-1. Menu Configuration Displays (Continued) (Defaults in Bold and Italics) ∂TARE ßMAX MENU RS=E (Enable RESET button in the Run Mode) Lock Out Configuration RS=D (Disable RESET button in the Run Mode) LK.CF SP=E (Enable setpoint changes) SP=D (Disable setpoint changes)

  • Page 61: Setpoint Configuration Displays

    Setpoint Configuration Displays SECTION 7. SETPOINT CONFIGURATION DISPLAYS Table 7-1. Setpoint Configuration Displays ∂ ∂ TARE ß ß MAX MENU Description SETPOINT 1 Press to scroll to Press to change Select from -1999 the next digit to the the value of the through 9999 right flashing digit...

  • Page 62: Sec

    Specifications SECTION 8. SPECIFICATIONS SIGNAL INPUT Input Ranges: 0-100 mV, ± 50 mV, 0-10 V, ± 5 V, 0-20 mA, 4-20 mA Isolation: Dielectric strength to 2500V transient per 3mm spacing based on EN 61010 for 260Vrms or DC working voltage Noise Rejection: Normal Mode Rejection (NMR) = 60 dB Common Mode Rejection (CMR) = 120 dB...

  • Page 63: Sec

    Specifications SECTION 8. SPECIFICATIONS (Continued) ALARM OUTPUTS (if applicable) 2 Form "C" on/off relays. Configurable for latched and unlatched by software. Max current: 5 AMPS, resistive load Max voltage: 250 Vac or 30 Vdc ANALOG OUTPUT (if applicable) Signal Type: Current or voltage Signal Level: Current: 10 V max compliance at 20 mA output...
  • Page 64 Specifications SECTION 8. SPECIFICATIONS (Continued) INPUT POWER INFORMATION ~ AC units 115/230 V~(AC) + 10%, 50/60 Hz 9.5 W max, power consumption (Non-Isolated Analog Out) 11.0 W max, power consumption (Isolated Analog Out) DC units 10-32 Vdc or 26-56 Vdc, 8W (Refer to Table 8-1 below) External Fuse Required: IEC 127-2/III...
  • Page 65 Specifications SECTION 8. SPECIFICATIONS (Continued) Table 8-1. COLOR CHART FOR DC POWER COLOR HIGH BRIGHTNESS MEDIUM & LOW BRIGHTNESS Sensor Excitation: Any combination of Sensor Excitation 24 V @ 25 mA, and Analog Output 12 V, 10 V, 5 V @ 35 mA Max 24 V @ 25 mA, Analog Output: 12 V @ 35 mA Max...
  • Page 66 Specifications SECTION 8. SPECIFICATIONS (Continued) 48,0 (1.89) 96,0 (3.78) FRONT BEZEL 20,3 (.80) RETAINER CASE REAR COVER TOP VIEW SIDE VIEW PANEL THICKNESS 6,4 (.25) MAX 0,8 (.03) MIN R(.06) 45,00 + 0,61/-0,00 (1.772 + .024/–.000) 4 PLCS 92,00 + 0,81/–0,00 (3.622 + .032/–.000) NOTE: Dimensions in Millimeters (Inches) Figure 8-1 Meter Dimensions/ Panel Cutout...

  • Page 67: Factory Preset Values

    Factory Preset Values SECTION 9. FACTORY PRESET VALUES Table 9-1. Factory Preset Values MENU ITEM FACTORY PRESET VALUES INPT Input Type: 0-20 (0-20 mA dc input) DEC.P Decimal Point Position: FFFF RD.S.O Reading Scale and Offset: 4-20 mA dc = 0-1000 RD.CF Reading Configuration: R.1=T (Tare enabled)

  • Page 68: Ce Approval Information

    CE APPROVALS INFORMATION This product conforms to the EMC directive 89/336/EEC amended by 93/68/EEC, and with the European Low Voltage Directive 72/23/EEC. Electrical Safety EN61010-1:2001 Safety requirements for electrical equipment for measurement, control and laboratory. Double Insulation Pollution Degree 2 Dielectric withstand Test per 1 min •...
