1 BEFORE USING THE INSTRUMENT

1-1 Names of Parts

Collimator
Power focus key
Eyepiece
Circular vial
Display panel
Key board
Circular vial
Leveling screw
10/30/02 11:21 AM Page 9
R-325(N)/R-322(N)/R-323(N): Detachable type
1 BEFORE USING THE INSTRUMENT
Focusing knob
Laser indicator
Instrument height
Telescope tangent
Telescope clamp
Tangent screw
Detaching knob
AF button
mark
Battery latch
Battery pack
screw
screw
Clamp screw
Base plate
