Enerpac 80 Series Instruction Sheet

POWERFUL SOLUTIONS. GLOBAL FORCE.
L1657 Rev. E 01/2019
Table of Contents:
ENGLISH (EN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
PORTUGUÊS (PT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.0 IMPORTANT RECEIVING INSTRUCTIONS
Visually inspect all components for shipping damage .
Shipping damage is not covered by warranty . If shipping
damage is found, notify carrier at once . The carrier is
responsible for all repair and replacement costs resulting
from damage in shipment .
SAFETY FIRST
2.0 SAFETY ISSUES
Read all instructions, warnings, and cautions
carefully . Follow all safety precautions to
avoid personal injury or property damage
during system operation . Enerpac cannot be
responsible for damage or injury resulting from unsafe
product use, lack of maintenance or incorrect product
and/or system operation . Contact Enerpac when in doubt
as to the safety precautions and operations . If you have
never been trained on high-pressure hydraulic safety,
consult your distribution or service center for information
about an Enerpac Hydraulic Safety Course .
Failure to comply with the following cautions and warnings
could cause equipment damage and personal injury .
A CAUTION is used to indicate correct operating or
maintenance procedures and practices to prevent damage
to, or destruction of equipment or other property .
A WARNING indicates a potential danger that requires
correct procedures or practices to avoid personal injury .
A DANGER is only used when your action or lack of
action may cause serious injury or even death .
WARNING: Wear proper personal protective gear
when operating hydraulic equipment .
sgls . eps
WARNING: Stay clear of loads supported by
hydraulics. A cylinder, when used as a load lifting
device, should never be used as a load holding device .
After the load has been raised or lowered, it must always be
undr.eps
blocked mechanically .
Instruction Sheet
80 Series Pumps
WARNING: USE ONLY RIGID PIECES TO HOLD
LOADS. Carefully select steel or wood blocks that are
capable of supporting the load . Never use a hydraulic
®
cylinder as a shim or spacer in any lifting or pressing
blk d .eps
application .
DANGER: To avoid personal injury keep hands
and feet away from cylinder and workpiece
during operation .
The 80 Series Pumps (electric and gasoline) are ideal
for high-tonnage cylinders or multiple-cylinder hookups
in construction or lifting applications. They are normally
used with our largest cylinders because of the high flow
and large reservoir capacities. These pumps may also be
used on the 100 and 150 ton presses.
WARNING: Do not exceed equipment ratings . Never
attempt to lift a load weighing more than the capacity
of the cylinder . Overloading causes equipment failure
and possible personal injury . The cylinders are designed for a
Dexceed.eps
max . pressure of 700 bar . Do not connect a jack or cylinder to
a pump with a higher pressure rating .
Never set the relief valve to a higher pressure than the
maximum rated pressure of the pump . Higher settings
may result in equipment damage and/or personal
injury .
danger.eps
WARNING: The system operating pressure must not
exceed the pressure rating of the lowest rated
component in the system . Install pressure gauges in
the system to monitor operating pressure . It is your window to
gge.e ps
what is happening in the system .
