Rutland County Garden Furniture Barleythorpe bench Assembly Instructions Manual

Before you commence the assembly process, we recommend that you read these instructions
thoroughly beforehand to familiarise yourself with the assembly process and to also check that you have
the correct components. If for any reason you need assistance, you can find our contact details on the
final page of these instructions.
We highly recommend that any assembly is carried out on a flat, level surface if possible and that you
use another person to assist you if necessary.

Package contents

1 x Seat panel
1 x Seat backrest
2 x A-frame
2 x Backrest support
2 x Brace
20 x M8 Coach screws - 60mm
20 x Cover caps
* 8ft version additionally includes - 1 x centre support and braces, 6 x
60mm Coach screws and 6 x cover caps. The 4ft version only has 1 x
straight brace.
Assembly Instructions
Barleythorpe bench

Tools required

10mm socket or spanner
The Barleythorpe bench
1
