Broyhill A3TPB-1 Assembly Instructions Manual
Broyhill A3TPB-1 Assembly Instructions Manual

Broyhill A3TPB-1 Assembly Instructions Manual

Adjustable height sit-stand desk

Advertisement

Remove
bar
if no
collec-
tion
name
Min. clearance
Min. clearance
44/47 type

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A3TPB-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Broyhill A3TPB-1

  • Page 1 Remove if no collec- tion name Min. clearance Min. clearance 44/47 type...
  • Page 2: Maintenance

    GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to begin Two adults are recommended for assembly Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its number in the package Helpful hints provided along the way WARNINGS:...
  • Page 3: Setup And Installation

    SET UP AND INSTALLATION Once the desk is fully assembled and placed in the desired location, level the desk using the adjustable feet. Once the desk is level, plug the desk into a 100-240 VAC outlet. The desk is then ready to use. Make sure that no cables can get jammed.
  • Page 4: Parts List

    PARTS LIST Desk Frame Top Panel Bracket Foot Power Cord Power Supply Handset HARDWARE LIST X 14 M8x30 M6x12 ST4.2x16 Umbrella Head Bolt Allen Bolt Tapping Screw Allen Wrench Allen Wrench Philips head screwdriver is needed and not included...
  • Page 5 STEP 1 Use M4 Allen Wrench (4) to attach Bracket (C) to Desk Frame (A) with Allen Bolt (2). Fully tighten all bolts.
  • Page 6 STEP 2 Use M4 Allen Wrench (4) to attach Assembled Frame in Step 1 to Top Panel (B) with Allen Bolt (2). Fully tighten all bolts.
  • Page 7 STEP 3 Use M5 Allen Wrench (5) to attach Foot (D) to Desk Frame (A) with Umbrella Head Bolt (1). Fully tighten all bolts.
  • Page 8 STEP 4 All screws need to be tightened to obtain optimal stability. Use Phillips Screw Driver (not included) to attach Handset (G) to Top Panel (B) with Tapping Screw (3). Fully tighten all screws.
  • Page 9 STEP 5 STEP a STEP b Connect the Cord on the Handset (G) and Power Supplier (F) as shown in STEP a, then insert the Power Cord (E) in the Power Supplier (F) as shown in STEP b.
  • Page 10 STEP 6 Assembly is now complete. Do not use this desk or insert the plug before the product is fully assembled.
  • Page 11: Directions For Use

    DIRECTIONS FOR USE Set key Display Screen Up&Down key Memory key The whole handset surface is a button panel. If there is no press within 30 seconds, the screen is locked and M1/M2/M3/M4 keys are locked correspondingly, you should press up or down key first, it can be used when the display screen light up.
  • Page 12 DIRECTIONS FOR USE 2. Forced initialization: Press the " " button until the desk frame reaches its lowest point, then release the button and press it again for about 5 seconds until hear the " di " sound and desk frame rebound, and the initialization is completed.
  • Page 13 DIRECTIONS FOR USE Advanced Function Settings Limited height setting: Press " " and " " key for 5 seconds till heard a bee sound, limited height setting success. {minimum limited height<37.79”(960mm), maximum limited height>38.19“(970mm)}. Cancel the function, run to the limit height, press " "...
