Petrol Brush-cutter and Grass-trimmer

Assemby - Use - Maintenance Manual

/ Original instruction manual

Table of Contents

Need help?

Do you have a question about the 43PBC1-40BH.1 and is the answer not in the manual?

Questions and answers

Валерий

May 6, 2025

Какой присоединительный размер режущей катушки? Диаметр и шаг резьбы?

1 comments:

Mr. Anderson

May 18, 2025

The connection size (cutting thickness/diameter) of the cutting spool for the STERWINS model 43PBC1-40BH.1 is 2.4 mm. The thread pitch is not specified in the provided information.

This answer is automatically generated

Юрий

June 11, 2025

Триммер заводится, но через неск. секунд глохнет?!

Steve

February 27, 2025

When pulling the cord to my PBC2-43B-A22 (32.6cc) it comes to an abrupt not turning the engine to a full crank. It is new ,only used it Twice. Ran fine mostly getting used to th harrness for wait distribution oil & gas mix is correct

Summary of Contents for STERWINS 43PBC1-40BH.1

Page 1 43PBC1-40BH.1 Petrol Brush-cutter and Grass-trimmer Petrol Brush-cutter and Grass-trimmer EAN : 3276007173932 Жннау, лайдалану жэне техникалық Руководство По Сборке и Эксплуатации Assemby - Use - Maintenance Manual қызмет көрсету нұсқаулығы Перевод оригинала инструкции / Аударма - Гүпнұска нұсқаулар / Original instruction manual...
Page 3 Руководство По Технике Безопасности и Правовым нормам / Техникасы бойынша нусқаулығы қауіпсіздікждне құқықтық қамтамасыз ету / Legal & Safety Instructions Сборка / Монтаждау / Assembly Подготовка / Дайындау / Preparation Использование / Пайдалану / Use Уход / Қызмет көрсету / Maitenance Зимний...
Page 4: Safety Instructions
Introduction Thank you for choosing this product. Upon designing and manufacturing our products, we place all of our efforts into ensuring an excellent quality that meets the needs of the users. Following these instructions allow to optimize the lifetime IMPORTANT! IN ORDER TO OBTAIN THE UTMOST SATISFACTION FROM THIS PRODUCT UPON SETTING IT UP, USING IT, AND MAINTAINING IT, WE RECOMMEND THAT YOU CAREFULLY READ THIS USER MANUAL BEFORE USING THE PRODUCT.
Page 5: General Safety Warnings
2.1 GENERAL SAFETY WARNINGS • Do not operate the product near glass enclosures, automobiles, trucks, window wells, drop-offs, etc. without properly adjusting the aim of the discharge. • Do not force or overload the product. It will perform better and safer when it is used at the rate that it was designed to work at.
Page 6: Symbols In This Manual
The distance between the machine and Keep bystanders away. bystanders shall be at least 15 m. Beware of blade thrust. Beware of thrown objects. Don’t install or use any type of blade on Maximum rotation speed of the the unit displaying this symbol. spindle 7850min Quality control during the production...
Page 7: Electrical Safety
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. • Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.
Page 8 • It is believed that a condition called Raynaud's phenomenon (white fingers), which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Loss of color and numbness in the fingers. The following precautions are strongly recommended: 1.
Page 9 • Clear the work area before each use. • Wear a face filter mask in dusty conditions to reduce the risk of injury associated with the inhalation of dust. • Do not point the product in the direction of people or pets. •...
Page 10 2.9 PETROL BRUSH-CUTTER AND GRASS-TRIMMER SAFETY WARNINGS • The use of this machine may be hazardous. If the rotating line or blade comes in contact with your body, it will cut you. When it comes in contact with solid foreign objects such as rocks or bits of metal, it may fling them directly or by ricochet in the direction of bystanders or the operator.
Page 11: Residual Risks
• To reduce this risk when using the product, always wear protective gloves and keep your hands warm. 3. TECHNICAL DATA Model 43PBC1-40BH.1 Machine weight 8.5Kg Max engine power 1.250kW / 1.7Hp Engine displacement 42.7cm...
Page 12 Engine idling speed range 3050±350min Spark plug reference L8RTC Gasoline Tank volume 850cm Gasoline 95 unleaded (Europe-US) Type of gasoline Gasoline 92 unleaded (Russia) Sound pressure level (at operator position) Sound pressure level uncertainty K Sound power level Sound power level uncertainty K Guaranteed sound power level Vibration Vibration uncertainty K...
Page 13 4.1 UNBOXING 1. Engine 9. Air filter case 14. Upper shaft 18d. Starter aid button 2. Spark plug connector 10. Chock lever 15. Control cable 19. Bracket 3. Air vents 11. Suspension sleeve 16. Bracket 20. Gear head 4. Muffler 11a.
Page 14: Installation
• Keep instruction manual in a dry area for further consultation. 4.2 INSTALLATION Assemble the shaft : illustration Join the shaft to the motor and install the bolt by a hexagon wrench. Do not over tighten. Ensure the shaft coupler is fixed securely. Assemble the handle : illustration NOTE : There are three position notches on the stem, choose the best comfortable position when holding the tool.
Page 15: Operation
Remove the line cutting blade cover NOTE : It is recommended to cover the line blade when your work is finished. Remove this cover before you turn on the machine. Handling and filling the fuel : illustration • The engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If oil is not available, use an antioxidant added quality oil expressly labeled for air-cooled 2-cycle engine use.
Page 16 Hold the unit WARNING: Always wear eye, hearing, hand, foot and body protection to reduce the risk of injury when operating this unit. Keep all parts of your body away from the rotating cutting attachment. Stand in the operating position. Stand up straight. Do not bend over. Keep feet apart and firmly planted.
Page 17: Cutting Tips
• Keep firm footing and balance. • Do not overreach. Overreaching can result in loss of balance. Always be sure of the footing on slopes. • Walk, never run. Keep all parts of your body away from any moving part. •...
Page 18: After Use
• DO NOT force the unit. Make shallow cuts in as many passes as are necessary to achieve the desired depth. Cut at a slow, even pace. Tips for best results To direct clippings away from the operator, tilt the cutting head slightly down to the right; whenever possible swing the trimmer in a left to right cutting motion.
Page 19: Maintenance Schedule
8. MAINTENANCE 8.1 CLEANING DANGER! Risk of injury due to electric shock. Remove the sparkplug of the tool before adjusting, inspecting, cleaning or storing the product. WARNING ! Do not handle cutting parts without gloves as they are sharp and can become hot after use, potentially causing personal injury.
Page 20 Part Action Before/After each usage Every 10H • CHECK • GEARBOX CLEAN • GREASE • CHECK STARTER ROPE CHANGE WHEN IT'S NECESSARY / REFER TO TROUBLE SHOOTING 8.3 REPLACEMENT Replacing the spool (bump head) : illustration Only authorized trimmer head could be used which described in the technical data. Fit the trimmer head as described in assembly of the trimmer head, see Changing the trimmer head to the trimmer head.
Page 21: Exploded View
8.4 EXPLODED VIEW Needle bearing retainer DESCRIPTION Air filter cover Hex. Screw M5X25t Air filter sponge Fly wheel cap Sponge retainer Round pin 5X10 Hex. Screw M5X55 Hex. Screw M5X35 Damper plate Oil seal 15X30X7 Air filter base Upper crankcase Throttle trigger Deep groove ball Hex.
Page 22 DESCRIPTION Flywheel assembly Muffler cover Semicircular key 3X13 Hex. Screw M5X16 Starter Driving Plate Cylinder gasket Nut M8X1.25 Piston Ring Starter gasket Piston Starter assembly Piston Pin 57-1 Starter cover screw M5X9 Needle Bearing 10X13X13 57-2 Starter wheel Piston Pin circlip 57-3 Starter spring Crankshaft-connecting...
Page 23 Handle permanent seat DESCRIPTION upper cover Output base assembly Hex. Screw M5X35 Hex. Screw M6X30 Hex. Screw M5X20 Hex. Screw M5X12 Gear box assembly Hex. Screw M6X25 Hex. Screw M6X25 Aluminum tube Hex. Screw M5X16 Oiliness shaft sleeve Protective guard upper Transmission shaft cover Right handle...
Page 24: Troubleshooting
DESCRIPTION Multi tool Belt seat fixing clip Internal hexagonal wrench M5 Hex. Screw M5X16 Internal hexagonal Cutter blade wrench M4 Trimming head Mixing bottle Cutter blade sleeve 8.5 TROUBLESHOOTING DANGER ! Risk of injury due to electric shock. Warning ! Before any trouble shooting, switch off the product. Qualification Problems Probable causes...
Page 25 Qualification Problems Probable causes Solutions required Press the priming bulb until The priming bulb has not the gasoline is visible inside been pressed enough (4-7 times) Remove and clean the The spark plug is dirty electrode with a spark plug brush (iron bristle brush) No engine start The spark plug spring...
Page 26: End Of Life
Qualification Problems Probable causes Solutions required There is a leak of gasoline due to a defective Find the leak location and After sales Gasoline leak assembling (drilled pip/bad replace the part by a new one service connection) There is no more line on the Change the line spool Poor trimming...
Page 27: Our Warranty
In the event of a problem or defect, you should first always consult your Sterwins dealer. In most cases, the Sterwins dealer will be able to solve the problem or correct the defect. Keep your invoice or your...
Page 28 M6x25 M6x30 STERWINS...
Page 30 32 00...
Page 31 32 00...
Page 32 32 00...
Page 34 SP95 40:1 25ml 50ml 75ml 100ml 125ml 6,0 M 34 00...
Page 35 16cm 32 00...
Page 36 4. 2...
Page 37 x 6-8 39 00...
Page 38 39 00...
Page 39 39 00...
Page 40 4. 10 39 00...
Page 41 4. 11 4. 12...
Page 42 4. 13 4. 14 39 00...
Page 43 4.15 4. 16 4. 17...
Page 44 4. 18 4. 19 39 00...
Page 45 4. 20 4. 21...
Page 46 4. 22 4. 23 x 6-8 39 00...
Page 47 4. 24 4. 25 39 00...
Page 48 4. 26 4. 27 39 00...
Page 49 4. 28 4. 29 39 00...
Page 50 4. 30 4. 31 39 00...
Page 51 4. 32 4. 33 CLIC! Stop! 39 00...
Page 52 6,0 M...
Page 53 39 00...
Page 55 39 00...
Page 56 5.10 39 00...
Page 57 5.11 5.12 39 00...
Page 58 5.13 5.14 39 00...
Page 59 5.15 5.16 39 00...
Page 60 5.17 5.18 39 00...
Page 61 5.19 5.20 5.21 0,6 - 0,7 mm 39 00...
Page 62 5.22...
Page 63 SP95 Max 3 Months 39 00...
Page 64 CLIC! Stop! 4° ~ 24°...
Page 65 Ten produkt poddawany jest recyklingowi, kiedy przestaje być użyteczny należy dostarczyć go do punktu zbiórki odpadów. Этот продукт может перерабатываться. Если он больше не пригоден для пользования, сдайте его в утилизационный центр. Ьұл өнім қайта өңдеуге келеді. Оны әрі қолдануға болмайтын жағдайда, оны қайта өңдейтін орталыққа тапсыруыңызды...
