Aligning the Wildlife Camera

The SETUP (test) mode is useful for determining the best possible angle for the PIR
sensors. To use the SETUP (test) mode, attach the Wildlife Camera to a tree, post or object
at approximately 0.8-1 metres height and position the camera in the desired direction.
1. Slide the power/mode switch to SETUP. Close the protective case and lock the brackets.
2. Moving parallel to the Wildlife Camera, move slowly from one side of the
observation area to the other.
3. The motion indicator light will flash red indicating that you were detected by the
central sensor. The motion indicator light will flash blue indicating that you were
detected by the side sensors. In this way you can determine the best position for
aligning the Wildlife Camera.
4. It is recommended to try out different angles and distances.
5. Once the Wildlife Camera is positioned in the ideal location, open the protective
case and slide the power/mode switch to ON to enter live mode or to OFF to switch
off the camera. Then close the protective case and lock the brackets.
NOTE: The motion indicator light will only flash either red or blue when the PIR has
detected movement in the SETUP (test) mode. The motion indicator lights will not
illuminate or flash when the Wildlife Camera is switched ON (in live mode).
NOTE: To prevent incorrect signals and unnecessary images, we recommend not
positioning the Wildlife Camera at sunny points and check that no branches are in
the active area of the PIR sensors. The optimum alignment is in either in the north
or south direction. The detection range of the sensors is approximately 120°, and the
detection range of the lens is approximately 120°.
NOTE: It is recommended to only move horizontally when testing the best possible
angle for the PIR sensors. The PIR sensors do not pick up vertical movement as well
as horizontal movement. Remember that you will need to be in front of the Wildlife
Camera while testing is underway.
NOTE: It is recommended to move quickly when you do the test in a long distance in
front of the PIR detection area.
NOTE: The PIR detection distance will be shorter if the environment temperature
reaches 30˚C or above.
