Pushbutton Loopback
Front panel LBK SEL pushbutton (SW1) controls loopback mode as described here:
To initiate a network loopback, press SW1 once and hold for 5 seconds. The NTWK LBK LED flashes rapidly,
I
indicating the network loopback is "arming." After 5 seconds, the network loopback enables, the NTWK LBK LED
turns On solid, and SW1 can be released.
To initiate a customer loopback, press SW1 twice and hold for 5 seconds. The CUST LBK LED flashes rapidly,
I
indicating the customer loopback is "arming." After 5 seconds, the customer loopback enables, the CUST LBK LED
turns On solid, and SW1 can be released.
To initiate a dual (bidirectional) loopback, press SW1 three times and hold for 5 seconds. During this time, the
I
NTWK LBK and CUST LBK LEDs flash rapidly, indicating the dual loopback is "arming". After 5 seconds, the dual
loopback enables, the NTWK LBK and CUST LBK LEDs turn On solid, and SW1 can be released.
If SW1 is released before the arming period expires, the loopback does not initiate, preventing an inadvertent
loopback.
I If a loopback is in effect, pressing SW1 disables the loopback, regardless of initiation point.
Time Out
After a loopback or pattern test is initiated, unless terminated manually, a time out returns the loop to normal
operation after a selected time of 20 min, 60 min, 120 min, or 24 hrs. The timer is reset at any point by sending the
FEAC loop up code. The test time out can be set or disabled through the craft interface. Pressing the LBK SEL
button during a test releases the loopback and returns the unit to normal operation.
CONTROL PORT OPERATION
The NIU3 PM front panel DB-9 provides an RS-232 interface for connection to a controlling terminal. To initiate a
terminal session, insert a DB-9 jack into the RS-232. The terminal interface operates at data rates from 1.2 kbps to 19.2
kbps. The asynchronous data format is fixed at 8 data bits, no parity, and 1 stop bit. The supported terminal type is
VT100 or compatible.
NOTE: When conducting a terminal session, always select VT100 mode in the Settings menu prior to making the craft
connection.
Terminal Session
The NIU3 PM synchronizes upon insertion in a powered-up shelf or housing. After synchronization, terminal sessions
provide access to screen menus for provisioning, monitoring, testing, or obtaining performance or event history.
Terminal screens are password protected with "ADTRAN" as the password. The adjacent menu tree identifies the
menu screens (not all are depicted).
NOTE: If using a personal computer with terminal emulation capability, disable all power saving programs.
Otherwise, communication between the PC and the NIU3 PM may be disrupted, resulting in misplaced
characters or screen time outs.
COMPLIANCE
This product is compliant with: I NEBS-Level 3
Code Input Output
Power Code (PC) F C
Telecommunication Code (TC) – –
Installation Code (IC) A –
NOTE: This product is intended for use in a restricted access area in a Type "B" or "E" enclosure only.
PART NUMBERS AND CLEI CODES
Description Part Number
12-slot, 19-in. shelf: 1212078L1
I
I 3-slot, 19-in. shelf: 1212073L1
I Standalone Housing: 1212070L1
NIU3 PM: 1212075L2
I
AC/DC Transformer: 1212074L1 (separate purchase)
I
WITH PERFORMANCE MONITORING
I ANSI-T1.404 I UL 60950
CLEI
NCM5RZ0D
NCM5K4ZD
NCM5KWVD
NCD3EGNA
DS3 NIU3
DS3 NIU3 MENU TREE
NIU3 Unit Information
Provisioning
Status
Loopback
and Test Commands
Performance History
(Submenu items are identical for
15-min, 60-min, 24-hr, and 30-day history)
Event History
Alarm Log
Set Circuit ID/Scratchpad
Set Date & Time
Terminal Modes
Software Download
*Factory Default Settings in Bold text
WARRANTY
ADTRAN will replace or repair this product within the warranty period if it does not meet its published
specifications or fails while in service. Warranty information can be found at www.adtran.com/warranty.
U.S. and Canada customer Faxback: 877-457-5007, Document 414.
PRICING AND AVAILABILITY 800.827.0807
TECH SUPPORT 800.726.8663
RETURN FOR REPAIR 256.963.8722
Pt No: 1212075L2
S/N: xxxxxxxxx
CLEI: NCD3EGNA
Rev: A 1. Test Time Out
2. Inband Loopback
LOS
3. KAS for Cust LOS
LOF
AIS
RAI DS3 Signal
Framing
Idle
Ones dBdsx Level
Detailed Status
ES-P/ES-L 15MIN/24H/30D
SES-P/SES-L 15MIN/24H/30D
UAS-P/LOSS-L 15MIN/24H/30D
1. Lbk Ntwk
2. Lbk Cust
1. Clear PM data
3. Dual Loopback
4. Ptrn to Ntwk
2^23-1
5. Deactivate Ptrn to Ntwk
QRSS
6. Ptrn to Cust
Idle
7. Deactivate Ptrn to Cust
Blue
8. Pattern Type
User Defined
9. Framing for Ptrn
C-Bit, M13, Unframed
10. Timing Source for Ptrn
Ntwk, Local
11. Insert Bit Error
12. Reset Ptrn Errors
1. Definitions
2. Reset Data
3. 15 Min Data
4. 60 Min Data
5. 24 Hr Data
6. 30 Day
7. Line Data
New ID
8. Path Data 1
New Scratchpad 9. Path Data 2
10. Ntwk Near End
New Date = mm/dd/yy
11. Cust Near End
12. Ntwk Far End
New Time = hh:mm:ss
13. Cust Far End
14. Change Thresholds
Manual Update Mode, Real-Time Update Mode
www.adtran.com
61212075L2-22D
20 Min
60 Min
120 Min*
24 hrs
Disabled
Enabled*
Disabled
Idle
AIS*
No Signal
Screen 1, Screen 2
Performance
Thresholds
