Page 1: Digital Camera
Digital Camera EX-S770D User’s Guide Thank you for purchasing this CASIO product. • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference. • For the most up-to-date information about this product, visit the official EXILIM Website at http://www.exilim.com/.
Page 2: Unpacking
UNPACKING As you unpack your camera, check to make sure that all items shown below are included. If anything is missing, contact your original retailer. Digital Camera Special AC Adaptor (AD-C52S or AD-C52G)/AC Power Cord* CD-ROM Rechargeable Lithium Ion Battery...
Page 3: Table Of Contents
CONTENTS UNPACKING QUICK START BASICS First, charge the battery ..... 10 Configuring Display Language, Date, and Time Settings ......12 Using a Memory Card .
Page 4 SHOOTING A SNAPSHOT Holding the Camera Correctly ....63 Shooting a Snapshot......64 ■...
Page 5 ADVANCED SETTINGS Changing the Focus Mode ....112 ■ Using Auto Focus ■ Using Macro Focus ■ Using Fixed Focus (Pan Focus) ■ Using Infinity Focus ■...
Page 6 EDITING IMAGES Resizing a Snapshot ..... . . 158 Cropping a Snapshot ..... . 159 Keystone Correction .
Page 7 PRINTING Types of Printing ......200 Using Professional Print Service ... . . 201 Using Your Printer to Print Images .
Page 8 APPENDIX General Guide ......258 Monitor Screen Contents ....260 Menu Reference .
Page 9 Getting the Most Out of Your Camera Snapshots Shooting with Optimum Setups ➞ USING BEST SHOT ......98 Portrait, Scenery, Night Scene, Night Scene Portrait, Children, etc.
Page 10: Quick Start Basics
QUICK START BASICS First, charge the battery ■ Loading the Battery into the Camera Open the battery cover. While pressing lightly on the cover, slide it in the direction indicated by the arrow to open. Load the battery into the camera. Close the battery cover.
Page 11 ■ Using the USB Cradle to Charge Plug the USB cradle into a household power outlet. AC adaptor Place the camera onto the USB cradle. [CHARGE] lamp Red: Charging Green: Charged (Full) • It takes about two hours to achieve a full charge. AC power cord QUICK START BASICS...
Page 12: Configuring Display Language, Date, And Time Settings
Configuring Display Language, Date, and Time Settings [ON/OFF] (Power) [BS] The settings on this page are required the first time you turn on the camera after purchasing it. Press [ON/OFF] to turn on the camera. Use [ ], [ ], [ ], and [ ] to select the language you want and then press [SET].
Page 13 Use [ ] and [ ] to select the date format and then press [SET]. Example: December 19, 2006 To display the date like this: 06/12/19 19/12/06 12/19/06 Set the date and the time. Use [ ] and [ ] to select the setting you want (year, month, day, hour, minute) and then use [ ] and [ ] to change the setting. To switch between 12-hour and 24-hour format, press [BS].
Page 14: Using A Memory Card
Using a Memory Card ■ Loading a Memory Card into the Camera When a memory card is loaded, the camera stores images you shoot on the card. NOTE • Though the camera has built-in memory, using a memory card provides additional capacity you can use to store more images, high-quality and large-size images, and longer movies.
Page 15 ■ Formatting a Memory Card Before you can use a memory card with your camera, you must format it. IMPORTANT! • Formatting a memory card that already has snapshots or other files on it, will delete its contents. Normally you do not need to format a memory card again.
Page 16: Shooting A Snapshot
Shooting a Snapshot Auto icon Operation Lamp 15:37 Focus Frame Monitor Screen Press [ This enters the REC mode and displays “ on the monitor screen. Point the camera at the subject. ] (REC) While taking care to keep the camera still, half- press the shutter button.
Page 17 Snapshot Image Size and Image Quality Your camera lets you select from among various image size and quality settings. Note that image size and quality settings affect how many images can be stored in memory. • You can change the image size and quality settings as required to shoot a smaller or lower-resolution image for attachment to an e-mail message, for publishing on a website, etc.
Page 18: Viewing Snapshots
Viewing Snapshots ] (PLAY) [ ][ ] Press [ ] to enter the PLAY mode. If there are multiple images in memory, use [ ] and [ ] to scroll through them. ■ To return to the REC mode Press [ (page 142) QUICK START BASICS...
Page 19: Shooting A Movie
Shooting a Movie Movie Icon Remaining Recording Time Recording Time Movie Recording Screen Press [ ] to enter the REC mode. Press [ “ ” (movie icon) remains on the monitor screen while movie recording is in progress. • Audio is also recorded during movie recording. Press [ ] (REC) Movie Image Quality...
Page 20: Viewing A Movie
Viewing a Movie The film-like frame that appears on the monitor screen indicates that this is an image from a movie. “ ” Movie icon [ ] [ ] Press [ Use [ ] and [ ] to select the movie you want to play.
Page 21: Deleting A File
Deleting a File You can use the following procedure to delete files you have transferred to your computer’s hard disk, images you have printed, or files you simply no longer need. This frees up memory for recording more images. ] (PLAY) [ ] [ ] [ ] ( Press [...
Page 22: Introduction
INTRODUCTION Features ■ BEST SHOT for beautiful shots simply by selecting a sample image built into the camera Simply select the scene that is similar to what you want to shoot (Night Scene Portrait, Flower, etc.), for instant camera setups. A dedicated [BS] button gives you direct access to the BEST SHOT library of sample scenes.
Page 23 ■ High-quality (MPEG-4, DivX) movie recording • Short Movie for shooting a short movie starting a few seconds before [ ] is pressed and a few seconds after it is pressed (page 92) • Past Movie for shooting a movie that includes scenes a few seconds before [ ] is pressed (page 95) •...
Page 24: Read This First
(website data, maps, etc.) to your camera. • Bundled CASIO DATA TRANSPORT software lets you transfer documents from your computer to the camera and take it along with you (page 249).
Page 25 • Photo Loader, Photohands, Photo Transport, and CASIO DATA TRANSPORT rights are owned by CASIO COMPUTER CO., LTD. Except for the rights of other companies as defined above, all rights related to these programs and other rights shall revert to CASIO COMPUTER CO., LTD. INTRODUCTION...
Page 26 CASIO COMPUTER CO., LTD. is forbidden under copyright laws. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or loss suffered by you or any third party due to the use or malfunction of this product.
Page 27: Precautions During Use
Precautions during Use ■ Take test shots before shooting the final shot. • Before shooting your final image, shoot a test shot to ensure that the camera is recording correctly. ■ Avoid Use While In Motion • Never use the camera to record or play back images while operating an automobile or other vehicle, or while walking.
Page 28: Display Panel
2. If you are using the AC adaptor to power the camera, unplug it from the wall outlet. If you are using battery power, remove the battery from the camera, taking care to protect yourself against burn injury. 3. Contact your dealer or nearest CASIO authorized service center. INTRODUCTION...
Page 29 2. If you are using the AC adaptor to power the camera, unplug it from the wall outlet. If you are using battery power, remove the battery from the camera. 3. Contact your dealer or nearest CASIO authorized service center. ■...
Page 30 • Never try to take the camera apart or modify it in any way. Doing so creates the risk of electric shock, burn injury, and other personal injury. Be sure to leave all internal inspection, maintenance, and repair up to your dealer or nearest CASIO authorized service center. ■...
Page 31 • This battery is intended for use with a CASIO Digital Camera only. Use with any other device creates the risk of the battery damage, or deterioration of battery performance and service life. • Failure to observe any of the following precautions creates the risk of battery overheating, fire, and explosion.
Page 32 – Never try to modify the AC adaptor or subject it to bending. – Do not twist or pull on the power cord. – Should the power cord or plug ever become damaged, contact your dealer or nearest CASIO authorized service center. INTRODUCTION...
Page 33 • Never touch the AC adaptor while your hands are wet. Doing so creates the risk of electric shock. • Misuse of the AC adaptor creates the risk of fire and electric shock. Make sure you observe the following precautions when using the AC adaptor.
Page 34: Battery Life
■ Data Error Precautions • Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in camera memory. – While the camera is performing an operation, removing the...
Page 35: Operating Environment
■ Operating Environment • The operating temperature range of the camera is 0°C to 40°C (32°F to 104°F). • Do not place the camera in any of the following locations. – In an area exposed to direct sunlight, or large amounts of moisture or dust –...
Page 36: Caring For Your Camera
■ Caring for your camera • Fingerprints, dirt, and other foreign matter on the lens surface can interfere with proper operation of the camera. Avoid touching the lens surface. To clean the lens surface, use a blower to blow off dust or foreign matter and then wipe with a soft, dry cloth.
Page 37: Getting Ready
GETTING READY Charging the Battery Your camera is powered by a rechargeable lithium ion battery (NP-20). IMPORTANT! • Use of any type of battery other than NP-20 is not supported. To load the battery Open the battery cover. While pressing the battery cover, slide it in the direction indicated by the arrow.
Page 38: To Charge The Battery
Close the battery cover. Swing the battery cover closed, and then slide it securely into place as you press it against the camera. The battery is not fully charged when you use the camera for the first time after purchasing it. Use the following procedure to charge it.
Page 39 With the camera positioned so the monitor screen is facing towards you as shown in the illustration, place it onto the USB cradle. The [CHARGE] lamp lights red and charging starts. • It takes about two hours to achieve a full charge. Actual charging time depends on current battery capacity, remaining power, and charging conditions.
Page 40 If an error still continues to occur after you perform the above steps, it could mean that the battery is faulty. Contact your nearest CASIO authorized service center. IMPORTANT! • Use only the bundled USB cradle or the separately available special charger unit (BC-11L) to charge the special rechargeable lithium ion battery (NP-20).
Page 41 ■ Checking Remaining Battery Power As battery power is consumed, a battery indicator on the monitor screen indicates remaining power as shown below. Remaining High Power Battery Indicator Indicator Light Orange Color blue “ ” indicates that battery power is low. Charge the battery as soon as possible.
Page 42: Replacing The Battery
Replacing the Battery Open the battery cover. With the camera oriented with its monitor screen facing upwards as shown in the illustration, slide the stopper in the direction indicated by the arrow and hold it there. • This will cause the battery to come out part way. While still holding the stopper, pull the battery out the rest of the way.
Page 43: Turning Power On And Off
■ Storage Precautions • Though a rechargeable lithium ion battery provides high capacity in a compact configuration, long-term storage while charged can cause it to deteriorate. – If you do not plan to use a battery for some time, fully use up its charge before storing it.
Page 44 IMPORTANT! • Pressing [ON/OFF] or [ ] (REC) to turn on power also causes the lens to extend. Take care there is nothing pressing against or hitting the lens. Holding the lens with your hand so it cannot extend creates the risk of malfunction.
Page 45 Turning On Power for the First Time The first time you load a battery into the camera, a screen appears for configuring screen text language, date, and time settings. Use the procedure under “Configuring Display Language, Date, and Time Settings” (page 12) to configure the settings correctly.
Page 46: Using A Memory Card
Use [ ] and [ ] to select the sleep or Auto Power Off trigger time and then press [SET]. Selecting “Off” for the sleep setting disables the sleep feature. NOTE • Auto Power Off and sleep are disabled under the following conditions.
Page 47 Supported Memory Cards Your camera supports use of SD, SDHC, MMC (MultiMediaCard), or MMCplus (MultiMediaCardplus) memory cards. Memory Used for Storage Images recorded while a memory card is loaded are saved to the memory card. When no memory card is loaded, images are saved in built-in memory.
Page 48: Loading A Memory Card Into The Camera
• Electrostatic charge, electrical noise, and other phenomena can cause data to become corrupted or even lost. Make sure that you always back up important data on other media (CD-R, CD-RW, MO disk, hard disk, etc.). Loading a Memory Card into the Camera IMPORTANT! •...
Page 49: Replacing The Memory Card
Load a memory card into the camera. Positioning the memory card so its front is facing upwards (towards the monitor screen side of the camera), slide it into the card slot all the way in until you hear it click securely into place.
Page 50: Formatting A Memory Card
• Should water or any foreign object ever get into the card slot, immediately turn off the camera, remove the battery, and contact your retailer or nearest CASIO authorized service center. • Never remove a card from the camera while the operation lamp is flashing green.
Page 51 Load the memory card you want to format into the camera. Turn on the camera and press [MENU]. On the “Set Up” tab, select “Format” and then press [ ]. Use [ ] and [ ] to select “Format” and then press [SET] to start formatting.
Page 52: Using On-Screen Menus
Using On-screen Menus The following are menu operations you will need to use to configure camera settings. Take a few moments to become familiar with them. • See “Menu Reference” on page 262 for information about menu contents. Example Menu Screen Tabs •...
Page 53: Configuring Monitor Screen Settings
Use [ ] and [ ] to select the item you want to configure and then press [ ]. Example: Select “Continuous” and then press [ ]. Use [ ] and [ ] to select the setting you want. Apply the setting. •...
Page 54: Selecting A Screen Layout (Layout)
The following is the procedure for menu operations in the REC mode. In the REC mode, press [DISP]. This will display the display menu screen. Use [ ] and [ ] to select the setting you want. Use [ ] and [ ] to select the setting you want. •...
Page 55 Layout Type Description With this option, the image being composed completely fills the monitor Normal screen. This setting is best when you want to display the subject on a large 16:9 aspect ratio monitor screen (page 68). Icons are superimposed on the displayed image.
Page 56 ■ PLAY Mode Screen Layout The PLAY mode screen layout settings let you select how display images are shown on the monitor screen. Layout Type Description With this setting, 100% of the display image is Normal always visible. With some aspect ratios, black bands may appear above and below, or to the left and right of the image.
Page 57: Turning Display Information On And Off (Info.)
Turning Display Information On and Off (Info.) With “Info.” you can turn display information on and off. You can configure separate settings for the REC mode and PLAY mode. Display Information Description Setting Turns on display of camera setting and Show other information.
Page 58 REC Mode (Layout: Normal) PLAY mode Show +Histogram Show +Histogram Hide Hide GETTING READY...
Page 59: Adjusting Monitor Screen Brightness (Brightness)
Adjusting Monitor Screen Brightness (Brightness) You can use the “Brightness” setting to adjust the brightness of the monitor screen. This setting is the same in the REC mode and PLAY mode. Brightness Description Setting With this setting, the camera detects available light levels and automatically adjusts the brightness of the monitor screen accordingly.
Page 60: Adjusting Monitor Screen Image Quality (Type)
Adjusting Monitor Screen Image Quality (Type) You can use the “Type” setting to adjust the quality of the monitor screen image. This setting is the same in the REC mode and PLAY mode. Quality Setting Description Increases contrast of the monitor screen image so the subject stands out for easier Dynamic viewing and framing when shooting under...
Page 61: If You Lose Your Way
If you lose your way... Perform one of the following operations if you find that you have gotten lost while performing button operations during recording or playback. REC mode To return to the normal snapshot Current Screen or movie recording screen, press: Menu screen [MENU] or [ Display Menu screen...
Page 62: Using The Camera On A Trip
Using the Camera on a Trip Extra Batteries Taking along extra fully charged batteries (NP-20) is recommended while on a trip in order to avoid not being able to shoot images due to the battery going dead. Using the Camera in another Country Note the following precautions.
Page 63: Shooting A Snapshot
SHOOTING A SNAPSHOT Holding the Camera Correctly Holding the camera with one hand can result in accidental hand movement. Hold the camera securely with both hands when shooting snapshots. • To protect against accidentally dropping the camera, attach the wrist strap and make sure it is around your fingers or wrist while you are operating the camera.
Page 64: Shooting A Snapshot
NOTE • Good-looking images are impossible if you move the camera when you press the shutter button or while the Auto Focus operation is being performed. Holding the camera correctly, carefully press the shutter button and take care that you do not move the camera as the shutter releases.
Page 65 Focus the image. While the focus frame is aligned with the subject, half-press the shutter button. Auto Focus will focus the image automatically, and the focus frame and operation lamp will turn green. The shutter speed, aperture, and ISO sensitivity also will be set automatically.
Page 66 NOTE • The aperture value indicates the size of the opening that lets light into the camera. A larger aperture value indicates a smaller opening. The camera adjusts this setting automatically. • Shutter speed indicates the amount of time that light is allowed into the camera.
Page 67: Specifying Image Size
Quick Shutter. Specifying Image Size A digital camera image is a collection of small dots (pixels). The size of an image indicates how many pixels it contains, and is expressed as horizontal pixels × vertical pixels. The initial factory default image size setting is 7M (3072 ×...
Page 68 NOTE • You can also use the Panel (Operation Panel) (page 54) to change the image size setting. • The following information changes on the display during the image size selection operation. – Image size in megabytes (M) (5M, etc.) –...
Page 69: Specifying Image Quality
Specifying Image Quality Your camera lets you select “Fine” (maximum image quality), “Normal”, or “Economy” (maximum memory economy) for the image quality setting. The initial setting is “Normal”. Select “Fine” if you want to give priority to image quality, or “Economy” to give priority to the number of images you can store in memory.
Page 70: Turning Off The Af Assist Lamp
Turning Off the AF Assist Lamp The AF assist lamp emits light that helps the camera focus when you half-press the shutter button under dark lighting conditions. The AF assist lamp does not light when lighting is bright. The initial factory default AF Assist/Self-timer Lamp setting is AF assist lamp on.
Page 71: Snapshot Shooting Precautions
Snapshot Shooting Precautions ■ Operation • While the operation lamp is flashing green, never open the battery cover or place the camera onto or remove it from the USB cradle. Doing so can result in incorrect storage of the image you just shot, damage to other images stored in memory, malfunction of the camera, etc.
Page 72: Auto Focus Restrictions
Auto Focus Restrictions • Proper focus may not be possible when shooting the following types of subjects. – Solid color wall or other very low contrast subject – Strongly back lit subject – Very shiny subject – Blinds or other subject with a repeating horizontal pattern –...
Page 73 Press the zoom button to change the zoom factor. Press this side of the To do this: zoom button: Enlarge the subject and narrow the range Reduce the size of the subject and broaden the range – For more information, see “Optical Zoom and Digital Zoom Switch Point”...
Page 74 ■ Optical Zoom and Digital Zoom Switch Point If you hold down the [ ] side of the zoom button in step 2 of the above procedure, the zoom operation will stop when the optical zoom factor reaches its maximum. Momentarily releasing the zoom button and then holding down its [ to digital zoom, which you can use to set an even higher zoom factor.
Page 75 IMPORTANT! • Digital zoom is not supported while “Timestamp” (page 131) is turned on. ■ Turning Off Digital Zoom You can turn off digital zoom if you want to use optical zoom only. This will help to avoid deteriorated images due to accidentally switching over from optical zoom to digital zoom when shooting snapshots.
Page 76: Using Flash
Using Flash Perform the following steps to select the flash mode you want to use. Flash Setting Description Auto Flash Flash fires automatically in accordance with exposure (amount of light and brightness) conditions. • Initial factory default setting. Flash Off Flash does not fire.
Page 77 In the REC mode, press [ ] ( [ ] ( Use [ ] and [ ] to select the flash setting you want and then press [SET]. Press the shutter button to shoot. NOTE • If you are using the “Normal” Screen Layout setting (page 54), each press of [ ] ( ) will cycle through the available flash settings.
Page 78: Checking The Flash Mode
Red-eye reduction Using the flash to shoot at night or in a dimly lit room can cause red spots inside the eyes of people who are in the image. This is caused when the light from the flash reflects off of the retina of the eye.
Page 79 ■ Changing the Flash Intensity In the REC mode, press [MENU]. On the “Quality” tab, select “Flash Intensity” and then press [ ]. Use [ ] and [ ] to select the flash intensity setting you want and then press [SET]. You can set one of five levels, from –2 (weakest) to +2 (strongest).
Page 80: Flash Precautions
In the REC mode, press [MENU]. On the “Quality” tab, select “Flash Assist” and then press [ ]. Use [ ] and [ ] to select “Off” and then press [SET]. When you want to use flash assist, select “Auto” here. IMPORTANT! •...
Page 81: Using The Self-Timer
Using the Self-Timer With the self-timer, pressing the shutter button starts a timer, and the shutter is released and the image is shot after a fixed amount of time. Self-Timer Type Description 10 sec 10-second self-timer 2-second self-timer • When shooting under conditions that 2 sec slow down the shutter speed, you can use this setting to prevent blur due to...
Page 82 Using the Self-timer to Shoot an Image • The image is not shot AF Assist/Self-timer Lamp right away after you press the shutter button. Instead, shooting starts after the preset time elapses. The AF assist/ self-timer lamp flashes while the countdown is being performed.
Page 83: Using Continuous Shutter
Using Continuous Shutter Your camera has four continuous shutter modes. Continuous Description Shutter Mode Normal Speed (Normal-speed Continually records images until memory Continuous becomes full. Shutter) High Speed (High-speed Record up to three consecutive images Continuous at high speed. Shutter) Flash Cont.
Page 84: Recording With Normal-Speed Continuous Shutter, High-Speed Continuous Shutter, And Flash Continuous Shutter
Recording with Normal-speed Continuous Shutter, High-speed Continuous Shutter, and Flash Continuous Shutter Press the shutter button to shoot. • With Normal-speed Continuous Shutter, images continue to be shot as long as you keep the shutter button depressed. Releasing the shutter button stops shooting. •...
Page 85: Continuous Shutter Precautions
IMPORTANT! • Note that with zoom continuous shutter, you do not need to keep the shutter button depressed. • Digital zoom is disabled while shooting with zoom continuous shutter. • Zoom continuous shutter is not available when the image size setting is 3:2 (3072 × 2048 pixels) or 16:9 (3072 × 1728 pixels).
Page 86: Adding Audio To A Snapshot
• Note that the resolution of images recorded with the high- speed continuous shutter mode or flash continuous shutter mode is somewhat lower resolution and more prone to digital noise than images recorded with the normal-speed continuous shutter mode. • “Auto” ISO sensitivity always is used for the flash continuous shutter mode, regardless of the current ISO sensitivity setting.
Page 87 ■ Recording Audio for a Snapshot Press the shutter button to shoot. This monitor screen will show the image you just shot, along with the “ ” icon. • If you do not want to record audio at this time, Remaining Recording Time press [MENU].
Page 88 NOTE • After transferring an audio snapshot to your computer’s hard disk, you can play back the audio using Windows Media Player (page 228). • The following shows the formats used for storing audio snapshot data. – Image Data: JPEG (.JPG extension) –...
Page 89: Shooting A Movie
SHOOTING A MOVIE Movie Image Quality Before shooting a movie, you should specify a movie image quality setting. Movie image quality is a standard that determines the detail, smoothness, and clarity of a movie during playback. Shooting with the high-quality (HQ) setting will result in better image quality, but it also shortens the amount of time you can shoot.
Page 90: Shooting A Movie
Movie Size The following shows the approximate movie file size for a one- minute movie. Image Quality Approximate Size 28.4 MB HQ Wide 28.4 MB Normal 14.9 MB Normal Wide 14.9 MB 5.3 MB Shooting a Movie Audio is also recorded while you shoot a movie. Audio is monaural.
Page 91: Movie Recording Precautions
Shooting with BEST SHOT With BEST SHOT (page 98), you select the preset scene that is closest to the one you want to shoot, and the camera sets up for it automatically. Selecting the “Night Scene” BEST SHOT scene, for example, sets the camera to shoot bright, clear images at night.
Page 92: Using Short Movie
• You can perform digital zoom while shooting a movie by pressing [ ]. Optical zoom is not available while shooting a movie. To use optical zoom for a movie, use [ required first and then press [ ] to start recording. •...
Page 93 ■ Getting Ready to Shoot with Short Movie In the REC mode, press [BS]. Use [ ], [ ], [ ], and [ ] to select the “Short Movie” scene and then press [SET]. This causes “ ” to appear on the monitor screen.
Page 94 Use [ ] and [ ] to select the MOTION PRINT setting you want and then press [SET]. To do this: Select this setting: Create a snapshot with nine 9 frames movie frames, with the one recorded when [ ] is pressed in the center Create a snapshot of the 1 frame...
Page 95: Using Past Movie
To return to the REC mode After Short Movie recording is complete, the camera stands by for shooting of another Short Movie. To exit Short Movie recording, press [BS], select something other than “Short Movie” and then press [SET]. If you want to set the camera up for normal snapshot shooting, for example, select “Auto”...
Page 96 ■ Getting Ready to Shoot with Past Movie In the REC mode, press [BS]. Use [ ], [ ], [ ], and [ ] to select the “Past Movie” scene and then press [SET]. This causes “ ” to appear on the monitor screen, which indicates that Past Movie is enabled.
Page 97: Shooting A Snapshot While Shooting A Movie (Snapshot-In-Movie)
Shooting a Snapshot while Shooting a Movie (Snapshot-In-Movie) You can shoot a snapshot while normal movie recording is in progress. Note, however, that movie recording (image and audio) is interrupted for a few seconds while the snapshot is recorded. ■ Shooting a Snapshot During a Movie While movie recording is in progress, press the shutter button.
Page 98: Using Best Shot
USING BEST SHOT With BEST SHOT, you simply select the sample scene that is like the one you are trying to shoot, and the camera sets up automatically. Even difficult backlight scenes (which result in the main subject being too dark if set up improperly) come out looking great! ■...
Page 99 Use [ ], [ ], [ ], and [ ] to move the boundary to select the scene you want to select. • Pressing [ ] or [ ] while the red boundary is at the edge of the screen will scroll to the next screen of BEST SHOT scenes.
Page 100 BEST SHOT Scene Limitations • Business cards and documents, White board, etc., and Old Photo. These scenes cannot be used to shoot a movie. • Short Movie, Past Movie These scenes cannot be used to shoot a snapshot. • Voice Recording These scenes cannot be used to shoot a snapshot or movie.
Page 101 Displaying Detailed Information about a BEST SHOT Scene Though the name of each BEST SHOT scene is displayed as you move the selection boundary around the 15-scene selection screen, there may be times when you need more information about a scene’s setup.
Page 102 ■ Creating Your Own BEST SHOT Scenes You can use the procedure below to save the setups of snapshots or movies that you shot as BEST SHOT scenes. After that, you can recall a setup whenever you want to use it. In the REC mode, press [BS].
Page 103 • The following are the settings that are included in a user movie scene: Focus, EV Shift, White Balance, Filter, Sharpness, Saturation, Contrast • You can store up to 999 BEST SHOT user scenes. • User snapshot scenes are stored in camera built-in memory in the folder named “SCENE”...
Page 104: Reducing The Effects Of Hand And Subject Movement
Reducing the Effects of Hand and Subject Movement You can turn on the camera’s Anti Shake feature to reduce image blur due to subject movement or hand movement when shooting a moving subject using telephoto, when shooting a fast-moving subject, or when shooting under dim lighting conditions.
Page 105: Taking Bright Images Without Flash
IMPORTANT! • Anti Shake will not work unless the ISO setting (page 126) is set to “Auto”. • Shooting with Anti Shake can cause an image to appear somewhat coarser than normal and can cause slight deterioration of image resolution. •...
Page 106: Shooting Images Of Business Cards And Documents (Business Shot)
IMPORTANT! • Shooting with High Sensitivity can cause an image to appear somewhat coarser than normal and can cause slight deterioration of image resolution. • The desirable level of image brightness may not be possible under very dark conditions. • When shooting with slow shutter speeds, use a tripod to protect against the effects of hand movement.
Page 107 BEST SHOT has two Business Shot scenes from which to choose. • Business cards and • White board, etc. documents ■ Selecting a Business Shot Scene In the REC mode, press [BS]. Use [ ], [ ], [ ], and [ ] to select the “Business cards and documents”...
Page 108 Use [ ] and [ ] to select the candidate you want to use for correction. Use [ ] and [ ] to select “Correct” and then press [SET]. This will correct the image and store the resulting (corrected) image. •...
Page 109: Restoring An Old Photograph
Restoring an Old Photograph With Old Photo, you can record the image of an old, faded photograph and then use the camera’s built-in advanced digital camera technology to restore it. ■ Before Recording with Old Photo • Make sure the entire photograph you are trying to record is enclosed within the monitor screen.
Page 110 ■ Recording an Image with Old Photo Press the shutter button to shoot the image. • This displays a photograph contour confirmation screen and then saves the original recorded image. An error message will appear (page 276), without displaying the photograph contour confirmation screen, if the camera is unable to find the contour of the photograph.
Page 111 Use [ ], [ ], [ ], and [ ] to move the cropping boundary to the location you want and then press [SET]. The camera will correct color automatically and save the corrected image. • If you do not want a border around the image, configure the cropping boundary so it is slightly inside of the boundary of the displayed image.
Page 112: Advanced Settings
ADVANCED SETTINGS Changing the Focus Mode Your camera provides you with the five focus modes described below. The initial factory default focus mode is Auto Focus. Focus Mode Description Auto Automatic focus when the shutter button is half-pressed. Focus Macro Automatic focus for distances that are closer than those for (Close-up) Auto Focus.
Page 113: Using Auto Focus
Perform the following steps to change the focus mode. In the REC mode, press [ ] ( ) twice. Use [ ] and [ ] to select the focus mode setting you want and then press [SET]. • See the following pages of this section for details about shooting with each focus mode.
Page 114: Using Macro Focus
When the image is focused, press the shutter button the rest of the way to shoot. IMPORTANT! • Auto Focus and Macro Focus become fixed focus while shooting a movie. NOTE • When proper focusing is not possible because the subject is closer than the Auto Focus range, the camera will switch to the Macro Focus range automatically (Auto Macro).
Page 115 NOTE • When Macro Focus cannot focus properly because the subject is too far away, the camera will switch to the Auto Focus range automatically (Auto Macro). • Whenever you perform an optical zoom operation while shooting with Macro Focus, values will appear on the monitor screen as shown below to tell you the focus range.
Page 116 Auto Focus and Macro Focus Shooting Tips Changing the Auto Focus Area Use the following procedure to change the metering area used for Auto Focus (AF). In the REC mode, press [MENU]. On the “REC” tab, select “AF Area” and then press [ ].
Page 117 Using Focus Lock “Focus lock” is the name of a technique you can use when you want to shoot an image in which the subject to be focused on is not within the focus frame in the center of the screen. •...
Page 118: Using Fixed Focus (Pan Focus)
Quick Shutter When Quick Shutter is turned on, the camera immediately shoots the image without waiting for Auto Focus to be performed when you press the shutter release all the way down. This helps to avoid missing a special moment while you wait for the camera to Auto Focus.
Page 119: Using Infinity Focus
Using Infinity Focus As its name suggests, Infinity Focus fixes focus at infinity ( Use this mode when shooting scenery and other faraway subjects. Infinity Focus also comes in handy when shooting from a car or train window, or when shooting scenery or other subjects that are difficult to focus properly with Auto Focus.
Page 120 Use [ ] and [ ] to focus the image, as you view the results on the monitor screen. At this time the image that is within the boundary will enlarge and fill the monitor screen, which aids in focusing. For this: Press this button: Closer focus...
Page 121: Correcting Image Brightness (Ev Shift)
Correcting Image Brightness (EV Shift) You can manually adjust an image’s exposure value (EV value) before shooting it. This feature helps to achieve better results when shooting a backlit subject, a strongly lit subject indoors, or a subject that is against a dark background. Exposure Compensation Value: –2.0EV to +2.0EV Unit: 1/3EV In the REC mode, press [MENU].
Page 122 After the EV value is the way you want, press [SET] to apply it. The exposure compensation value you set remains in effect until you change it. IMPORTANT! • When shooting under very dark or very bright conditions, you may not be able to obtain satisfactory results even after performing exposure compensation.
Page 123: Controlling White Balance
Controlling White Balance Shooting on a cloudy day can give your subject a blue cast, while shooting under white fluorescent lighting can give your subject a green cast. White balance corrects for different types of lighting so the colors in your images always look natural. In the REC mode, press [MENU].
Page 124 NOTE • You can also use the Panel (Operation Panel) (page 54) to change the white balance setting. • When “Auto” is selected for the white balance setting, the camera automatically determines the white point of the subject. Certain subject colors and light source conditions can cause problems when the camera tries to determine the white point, which makes proper white balance adjustment impossible.
Page 125 Under the lighting conditions you plan to use when shooting, point the camera at a blank white piece of paper so it fills the entire monitor screen and then press the shutter button. White sheet of paper The camera will adjust white balance settings for the current conditions, and display “Complete”...
Page 126: Specifying Iso Sensitivity
Specifying ISO Sensitivity ISO sensitivity is a value that expresses sensitivity to light. A larger value indicates higher sensitivity, which is better for shooting when available lighting is dim. If you want to use faster shutter speeds, you should use a higher ISO sensitivity value. Under certain conditions, a fast shutter speed in combination with a high ISO sensitivity setting can cause digital noise, which makes an image appear rough.
Page 127: Specifying The Metering Mode
IMPORTANT! • Using flash with high ISO sensitivity can cause problems with subjects that close to the camera. • “Auto” ISO sensitivity always is used for movies, regardless of the current ISO sensitivity setting. • You can use the key customization feature to configure the [ ] and [ ] buttons so they control the ISO sensitivity setting (page 135).
Page 128 Center Weighted Center weighted metering concentrates on the center of the focus area to measure light. Use this metering method when you want to exert some control over exposure, without leaving settings totally up to the camera. Spot Spot metering takes readings at a very small area.
Page 129: Using The Camera's Filter Effects
Using the Camera’s Filter Effects The camera’s filter feature lets you add color tints to your images as you shoot them. The color effect look just like what you would get by installing a color filter on the lens of the camera. In the REC mode, press [MENU].
Page 130: Controlling Color Saturation
Controlling Color Saturation Use the following procedure to adjust the saturation of colors in your images. In the REC mode, press [MENU]. On the “Quality” tab, select “Saturation” and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 131: Date Stamping Snapshots
Date Stamping Snapshots You can have the snapshot’s recording date only, or date and time stamped in the lower right corner of the image. In the REC mode, press [MENU]. On the “Set Up” tab, select “Timestamp” and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 132: Using The On-Screen Histogram To Check Exposure
Using the On-screen Histogram to Check Exposure The on-screen histogram that provides a graphic representation of the current exposure of the image. You can also display the histogram in the PLAY mode for information about the exposure levels of images. Histogram Select either the REC mode or the PLAY mode.
Page 133 ■ How to Use the Histogram A histogram is a graph that represents the lightness of an image in terms of the number of pixels. The vertical axis indicates the number of pixels, while the horizontal axis indicates lightness. You can use the histogram to determine whether an image includes the shadowing (left side), mid tones (center), and highlighting (right) to bring out sufficient image detail.
Page 134 A centered histogram indicates that there is good distribution of light pixels and dark pixels. This type of histogram results when the overall image is at optimal lightness, as shown in the nearby image. IMPORTANT! • Note that the above histograms are shown for illustrative purposes only.
Page 135: Other Useful Recording Functions
Other Useful Recording Functions The following functions are also available in the REC mode to help make your digital image more efficient and enjoyable. • Assign functions to the [ ] and [ ] keys • Display an on-screen grid for easy image composition •...
Page 136: Displaying An On-Screen Grid
In the REC mode, press [MENU]. On the “REC” tab, select “L/R Key”, and then press [ ]. Use [ ] and [ ] to select the function you want to assign and then press [SET]. After you assign a function, you can control its setting using the [ ] and [ ] keys.
Page 137: Displaying The Image You Just Recorded (Image Review)
Displaying the Image You Just Recorded (Image Review) When you purchase your camera, it is initially configured with the Image Review feature turned on. Image Review displays the image you just recorded so you can check it. In the REC mode, press [MENU]. On the “REC”...
Page 138: Using Mode Memory To Configure Power On Default Settings
IMPORTANT! • The icons listed below do not appear on the display while icon help is turned off. – Flash mode icon (page 76) – Focus mode icon (page 112) – White balance icon (page 123) – Metering mode icon (page 127) Using Mode Memory to Configure Power On Default Settings You can configure the camera so it saves certain settings in...
Page 139 Use [ ] and [ ] to select the setting you want and then press [SET]. To do this: Save the current setting when the camera turned off, and restore it when the camera is turned back on Restore the optimum default when the camera is turned on Setting Select this...
Page 140: Resetting The Camera To Its Initial Factory Defaults
*1 “On” restores the selected BEST SHOT scene when the camera is turned back on. “Off” exits BEST SHOT when the camera is turned off. *2 Optical zoom position only. IMPORTANT! • Turning the camera off while mode memory for the BEST SHOT mode is on will restore the settings of the BEST SHOT scene what was selected when you last turned off the camera.
Page 141 IMPORTANT! • The following are not initialized when you reset the camera (page 264). – Home Time setup – World Time setup – Adjust – Date Style – Language – Video Out ADVANCED SETTINGS...
Page 142: Viewing Snapshots And Movies
VIEWING SNAPSHOTS AND MOVIES Viewing a Snapshot Use the following procedure to view snapshots on the camera’s monitor screen. Press [ ] to enter the PLAY mode. • This will display one of the snapshots in memory, along with some information about the settings used to shoot it (page 261).
Page 143: Listening To The Audio Of An Audio Snapshot
Note that if you copy an image from another type of digital camera, only a rough image may be shown on the monitor screen.
Page 144: Viewing A Movie
Audio Playback Controls The following are the different operations you can perform while audio is playing. To do this: Do this: Fast forward or fast reverse Hold down [ ] or [ ]. playback Pause or restart playback Press [SET]. Adjust volume Press [ ] or [ ].
Page 145 To switch to the REC mode Press [ Movie Playback Controls To do this: Fast forward or fast reverse playback. • Each press of either button increases the speed of the fast forward or fast reverse operation up to three steps. Return from fast forward/fast reverse to normal playback Pause or restart playback...
Page 146: Playing Back A Movie With Anti Shake
Playing Back a Movie with Anti Shake Use the following procedure when you want to play back a movie with Anti Shake. Anti Shake is particularly useful when you have the camera connected to a TV for viewing, since the effects of camera movement are more evident on a big screen.
Page 147: Playing A Slideshow On The Camera
Playing a Slideshow on the Camera The slideshow feature lets you play the files stored in memory in sequence, automatically. You can configure the slideshow so it plays the files the way you want. In the PLAY mode, press [MENU]. On the “PLAY”...
Page 148 Effect (Select Use [ ] and [ ] to select the effect you a special want. • Pattern 1, 2, 3, 4: Applies preset effects in effect.) sequence. • Random: Applies preset effects (Pattern 1, 2, 3, 4) in random sequence. •...
Page 149 “Time” setting. • In image copied from a computer or an image recorded with a different type of digital camera may remain on the screen longer than the time specified by “Interval”. ■...
Page 150 Press the USB cradle’s [PHOTO] button to start the slideshow. The slideshow is performed in accordance with the settings you configured with the procedure on page 147. The camera will turn off automatically after the time you specified with the “Time” setting elapses. •...
Page 151: Viewing Camera Images On A Tv
Viewing Camera Images on a TV Use the procedure below to view snapshots and movies on a TV screen. • You need to use the USB cradle and the AV cable that comes with the camera to connect to a TV. Connect the USB cradle to a TV.
Page 152 To turn off the camera You can turn off the camera by doing either of the following. • Press the camera’s [ON/OFF] button. • Press the USB cradle’s [USB] button. IMPORTANT! • When connecting to a TV to display images, be sure to configure the camera’s [ ] (REC) and [ buttons for “Power On”...
Page 153 ■ Selecting the Screen Aspect Ratio and Video Output System You can use the procedure in this section to select either NTSC or PAL as the video output system. You can also specify an aspect ratio of 4:3 or 16:9. For this type of TV: Standard aspect ratio screen NTSC TV (Japan, U.S., and other countries)
Page 154: Zooming The Displayed Image
Zooming the Displayed Image Perform the following procedure to zoom the image currently on the monitor screen up to eight times its normal size. In the PLAY mode, and use [ ] and [ ] to display the snapshot you want to zoom. Press the zoom button ( Each press of this button...
Page 155: Using The 12-Image Screen
Using the 12-image Screen You can use the procedure below to display a screen that shows 12 images. Press the zoom button Selection Boundary This displays the 12-image screen with a selection boundary around the last image that was on the monitor screen.
Page 156: Using Image Roulette
Use [ ], [ ], [ ], and [ ] to move the selection boundary to the date whose image you want to view and then press [SET]. This will display the first image recorded on that date. NOTE • The year and month on the calendar is displayed using the same format as you selected for the “Date Style”...
Page 157 To perform another Image Roulette operation Press [ ] or [ ]. To stop Image Roulette Press [ ] to enter the REC mode or press [ON/OFF] to turn off the camera. • The camera will exit Image Roulette automatically you do not perform the next Image Roulette operation within about one minute after the final image of the previous operation appeared on the monitor screen.
Page 158: Editing Images
EDITING IMAGES Resizing a Snapshot You can change the size of a snapshot and save the result as a separate snapshot. The original snapshot is also retained. You can resize a snapshot to any one of the following sizes. Image Size (Pixels) Print Size 5M* 2560 ×...
Page 159: Cropping A Snapshot
IMPORTANT! • Note that you cannot resize the following types of snapshots. – VGA (640 × 480 pixels) and smaller snapshots – Images created using MOTION PRINT – Images recorded with another camera • Resizing a snapshot shot with an aspect ratio of 16:9 or 3:2 will cause the left and right sides of the image to be cut off.
Page 160: Keystone Correction
Use the zoom button to zoom, and [ ], [ ], [ ], and [ ] to move around the zoomed image to display the part you want to extract. Press [SET] to extract the displayed part and save it as a separate file. •...
Page 161 Use [ ] and [ ] to select the candidate you want to correct. Use [ ] and [ ] to select “Correct” and then press [SET]. • Select “Cancel” to exit the procedure without performing keystone correction. IMPORTANT! • If the original image is smaller than 2M (1600 × 1200 pixels) size, the new (corrected) version will be the same size as the original one.
Page 162: Using Color Restoration To Correct The Color Of An Old Photograph
Color of an Old Photograph Color restoration let you correct the old color of a photograph shot with a digital camera. This function is useful for correcting existing old photographs, posters, etc. • Performing color restoration on an image causes a new (restored) 2M (1600 ×...
Page 163 IMPORTANT! • If the original image is smaller than 2M (1600 × 1200 pixels) size, the new (restored) version will be the same size as the original one. • Note that you cannot correct the following types of images. – Movie images and the voice recording file icon –...
Page 164: Editing The Date And Time Of An Image
Editing the Date and Time of an Image Use the procedure in this section to change the date and time of a previously recorded image. This capability comes in handy when the current date and time are wrong due to the following reasons.
Page 165: Rotating An Image
IMPORTANT! • You cannot change the date of the following types of files. – Movies, Voice recordings – Images created with MOTION PRINT • The date and time stamped into an image using the Time Stamp feature cannot be edited (page 131). •...
Page 166: Editing A Movie On The Camera
IMPORTANT! • You cannot rotate an image that is protected. To rotate a protected snapshot, first remove its protection (page 180). • You may not be able to rotate an image recorded with another camera. • The following images cannot be rotated. –...
Page 167 IMPORTANT! • When you edit a movie, only the result is saved. The original movie is not retained. Once you perform an editing operation, you will not be able to undo it. • A movie that is shorter than five seconds cannot be edited. •...
Page 168 Use [ ] and [ ] to select “ Point Cut) or “ Cut” (From-Point Cut) and then press [SET]. • To cancel movie editing, select “Cancel” and then press [SET]. This will return to the paused movie playback screen. Use the following operations to select the frame (point) from...
Page 169 In response to the confirmation message that appears, use [ ] and [ ] to select “Yes” and then press [SET]. • To cancel movie editing, select “No” instead of “Yes” and then press [SET]. This will return to the paused movie playback screen.
Page 170 Use [ ] and [ ] to select “ (Point-To-Point Cut) and then press [SET]. • To cancel movie editing, select “Cancel” and then press [SET]. This will return to the paused movie playback screen. Use the following operations to select the frames (points) between which you want to cut the movie...
Page 171: Creating A Snapshot Of A Movie Frame (Motion Print)
When the frame where you want the second (To) cut point to be is displayed, press [ ]. In response to the confirmation message that appears, use [ ] and [ ] to select “Yes” and then press [SET]. • To cancel movie editing, select “No” instead of “Yes” and then press [SET].
Page 172 1-frame Snapshot This format creates a snapshot using the (VGA 640 × 480 selected movie frame only. pixels) In the PLAY mode, use [ ] and [ ] to scroll through images and display the movie that contains the frame you want to use. Press [MENU].
Page 173: Using Audio
USING AUDIO Adding Audio to a Snapshot The dubbing feature of your camera lets you add audio to a snapshot after you shoot it. A snapshot that includes audio (regardless of whether the audio was recorded on the spot or added later) is indicated by the “...
Page 174 ■ Re-recording Snapshot Audio IMPORTANT! • Note that you cannot restore the original audio once you delete or re-record the audio of a snapshot. In the PLAY mode, use [ ] and [ ] to scroll through images and display the snapshot whose audio you want to re-record.
Page 175 IMPORTANT! • Take care that you do not block the camera’s microphone with your fingers while recording. • Good recording results are not possible when the camera is too far away from what you are trying to record. Microphone • You may not be able to record audio if remaining memory capacity is too low.
Page 176: Recording Audio Only (Voice Recording)
Recording Audio Only (Voice Recording) Voice Recording lets you record audio only, without a snapshot or movie. Using built-in memory only, you get up to about 18 minutes of Voice Recording. In the REC mode, press [BS]. Use [ ], [ ], [ ], and [ ] to select “Voice Recording”...
Page 177 Press the shutter button again to stop audio recording and return to the screen in step 3. • Recording also will stop automatically if memory becomes full. • If you press [ON/OFF] (Power) or play [ the battery goes dead during recording will stop the recording operation and save anything you have recorded up to that point.
Page 178 ■ Playing Back Voice Recording Data Enter the PLAY mode, and then use [ ] and [ ] to display the Voice Recording file you want to play. “ ” is displayed in place of an image for a Voice Recording file.
Page 179: Managing Your Files
MANAGING YOUR FILES Files and Folders Your camera treats each snapshot, movie, and Voice Recording, as a separate file. You can delete, protect, and copy files as required. Files are grouped in folders that are created automatically by the camera. Files and folders have their own unique names, which are assigned automatically by the camera.
Page 180: Protecting A File Against Deletion
Protecting a File Against Deletion You can protect an important file to ensure that it cannot be deleted accidentally. IMPORTANT! • Note that even if a file is protected, it will be deleted if you perform the format operation (pages 15, 50, 199). ■...
Page 181: Using The Favorite Folder
■ Protecting All Files in Memory In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Protect” and then press [ ]. Use [ ] and [ ] to select “All Files : On” and then press [SET]. This protects all files currently in memory. Press [MENU].
Page 182 ■ Copying a File to the FAVORITE Folder In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Favorites” and then press [ ]. Use [ ] and [ ] to select “Save” and then press [SET]. Use [ ] and [ ] to select the snapshot you want to copy to the FAVORITE folder.
Page 183 ■ Viewing Snapshots in the FAVORITE Folder In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Favorites” and then press [ ]. Use [ ] and [ ] to select “Show” and then press [SET]. Use [ ] and [ ] to scroll through the snapshots in the FAVORITE folder.
Page 184: Copying Files
Copying Files Files can be copied from the camera’s built-in memory to a memory card, or from a memory card to built-in memory. This makes it possible, for example, to perform the following steps and copy a file from your memory card to another person’s memory card.
Page 185 ■ Copying a Single File from a Memory Card to Built-in Memory With this procedure, files must be copied one-by-one. Load the memory card that contains the file you want to copy into the camera. Turn on the camera, enter the PLAY mode and then press [MENU].
Page 186: Deleting Files
DELETING FILES You can delete files you no longer need, or after you transfer them to your computer’s hard disk or print them. This frees up memory for new files. You can delete one specific file, or you can delete all files currently in memory.
Page 187: Deleting All Files
Deleting All Files In the PLAY mode, press [ ] ( Use [ ] and [ ] to select “All Files Delete” and then press [SET]. In response to the confirmation message that appears, use [ ] and [ ] to select “Yes”. •...
Page 188 Now you can repeat steps 5 and 6 to delete another FAVORITE folder snapshot, or you can exit this procedure by pressing [MENU] twice. ■ Deleting All FAVORITE Folder Snapshots In the PLAY mode, press [MENU]. On the “PLAY” tab, select “Favorites” and then press [ ].
Page 189: Other Settings
OTHER SETTINGS Configuring Camera Sound Settings Your camera lets you configure the following sound settings. • Type of sound for shutter release and other operations • Volume level for shutter release and other operation sounds • Volume level for movie and Voice Recording playback ■...
Page 190 ■ Setting the Operation Tone Volume Level Press [MENU]. On the “Set Up” tab, select “Sounds” and then press [ ]. Use [ ] and [ ] to select “ Use [ ] and [ ] to specify the playback volume setting you want and then press [SET].
Page 191: Turning The Startup Screen On Or Off
Turning the Startup Screen On or Off You can configure the camera to display a startup screen of an image you recorded, whenever you turn it on. • The startup screen is not displayed when you turn on the camera by pressing [ ] (PLAY).
Page 192: Specifying The File Name Serial Number Generation Rule
Specifying the File Name Serial Number Generation Rule Use the following procedure to specify the rule that governs generation of the serial number used in file names (page 179). Press [MENU]. On the “Set Up” tab, select “File No.” and then press [ ].
Page 193 Use [ ] and [ ] to select “Home” and then press [ ]. Use [ ] and [ ] to select “City” and then press [ ]. Use [ ], [ ], [ ], and [ ] to select the area where your Home City is located and then press [SET].
Page 194: Using World Time
■ Changing the Date Format You can select from among three different formats for the date. Press [MENU]. On the “Set Up” tab, select “Date Style” and then press [ ]. Use [ ] and [ ] to select the setting you want and then press [SET].
Page 195 Use [ ] and [ ] to select “City” and then press [ ]. • To configure the summer time setting, use [ ] and [ ] to select “DST” and then select “On”. • Summer time is used in some areas to advance the current time setting by one hour during the summer months.
Page 196: Changing The Display Language
Changing the Display Language You can use the procedure below to select a display text language. • The number and types of languages depend on the geographic area where the camera was marketed. Press [MENU]. On the “Set Up” tab, select “Language” and then press [ ].
Page 197: ] (Rec) And [ ] (Play) Button Settings
Use [ ] and [ ] to select the setting you want and then press [SET]. When you want to connect to this type of device: Computer With this setting, the computer sees the camera as an external storage device. Use this setting for normal transfer of images from the camera to a computer (using the bundled Photo Loader...
Page 198 Use [ ] and [ ] to select the setting you want and then press [SET]. To configure both keys to do Select this setting: this when pressed: Turn on the camera Power On Turn on or turn off the camera Power On/Off Do not turn on the camera Disable...
Page 199: Formatting Built-In Memory
Formatting Built-in Memory Formatting built-in memory deletes any data stored in it. IMPORTANT! • Note that data deleted by a format operation cannot be recovered. Check to make sure you do not need any of the data in built-in memory before you format it. •...
Page 200: Printing
PRINTING Types of Printing There are three different methods you can use for printing images. Professional Print Service (page 201) Printing at Printing on a Printer (page 202) Home Printing with a Computer Take the memory card that contains the images you want to print to a professional print service.
Page 201: Using Professional Print Service
■ Printing Precautions • See the documentation that comes with your printer for information about print quality and paper settings. • Contact the manufacturer of your printer to find out if it supports PictBridge, for new printer versions, etc. • Never disconnect cables or perform any camera or USB cradle operation while printing is in progress.
Page 202: Using Your Printer To Print Images
Using Your Printer to Print Images If your printer is either of the types described below, you can use it to print without going through a computer. – Printer equipped with an SD memory card/ SDHC memory card slot – Printer that support PictBridge ■...
Page 203 Connect the USB cable that comes bundled with the camera to the USB cradle and your printer’s USB port. USB Cable (Bundled) USB Port Connector A • Also, connect the AC adaptor to the cradle and plug the adaptor into an electrical outlet. •...
Page 204 Use [ ] and [ ] to select “Paper Size” and then press [ ]. Use [ ] and [ ] to select a paper size and then press [SET]. • The following are the available paper sizes. 3.5" × 5", 5" × 7", 4" × 6", A4, 8.5" × 11", By Printer •...
Page 205: And The Number Of Copies
Use [ ] and [ ] to select “Print” and then press [SET]. Printing will start and the message “Busy... Please wait...” will appear on the monitor screen. The message will disappear after a short while, even though printing is still being performed.
Page 206 ■ Configuring DPOF Settings Individually for Each Image In the PLAY mode, press [MENU]. On the “PLAY” tab, select “DPOF Printing” and then press [ ]. Use [ ] and [ ] to select “Select Images” and then press [ ]. Use [ ] and [ ] to scroll through the images until the one you want to print is on the monitor screen.
Page 207 ■ Configuring the Same DPOF Settings for All the Images In the PLAY mode, press [MENU]. On the “PLAY” tab, select “DPOF Printing” and then press [ ]. Use [ ] and [ ] to select “All images” and then press [ ]. Use [ ] and [ ] to specify the number of copies.
Page 208: Date Stamping
Tell your print service about your DPOF settings! If you take a memory card to a professional print service, be sure to tell them that it includes DPOF settings for the images to be printed and the number of copies. If you don’t, the print service may print all the images without regard to your DPOF settings, or they may ignore your date stamp setting.
Page 209: Supported Protocols
• Specify date stamping with Photohands (Windows only) – See the Photohands User’s Guide for details. The Photohands User’s Guide is provided as a PDF file on the CD-ROM that comes bundled with your camera. • Request date stamping when ordering prints from a professional print service –...
Page 210: Exif Print
■ Exif Print Printing on a printer that also supports Exif Print (Exif 2.2) uses information about shooting conditions recorded with the image to enhance printed image quality. Contact your printer manufacturer for information about models that support Exif Print, printer upgrades, etc. PRINTING...
Page 211: Using The Camera With A Computer
USING THE CAMERA WITH A COMPUTER What you can do Connecting the camera to a computer with the bundled USB cable provides you with the capabilities described below. You can use your computer to view camera images and for long-term storage of images. •...
Page 212: Using The Camera With A Windows Computer
The procedures you need to perform when using the camera with your computer and when using the bundled software are different for Windows and the Macintosh. • Windows users should refer to “Using the Camera with a Windows Computer” on page 212. •...
Page 213 • Installing the DivX codec also enables movie playback with Windows Media Player. Transfer XP/2000/ Photo Transport 1.0 images to the Me/98SE/ camera Transfer CASIO DATA documents to XP/2000 TRANSPORT 1.0 the camera Windows Objective page: Version XP/2000/ Me/98SE View the User’s Guide...
Page 214: Computer System Requirements
HD: 65MB for installation (18MB on hard disk) Photo Transport 1.0 Memory : At least 64MB : At least 2MB CASIO DATA TRANSPORT 1.0 • Sufficient memory to run the operating system Adobe Reader 6.0 : Pentium Memory : 32MB...
Page 215: Viewing And Storing Images On A Computer
IMPORTANT! • For details about the minimum system requirements for each software application, see the “Read me” files on the CD-ROM that comes bundled with the camera. • Visit the URL below for more information if you have any questions or problems with the DivX codec. http://www.divx.com/support/ Viewing and Storing Images on a Computer...
Page 216 ■ Installing the USB Driver (Windows 98SE and 98 Only) Do not try to establish a connection between the camera and computer before installing the USB driver on the computer. If you do, the computer will not be able to recognize the camera.
Page 217 When the final screen is reached, click “Finish”. • Depending on the version of Windows that your computer is running, a message may appear telling you to restart your computer. If your computer displays such a message, restart. To exit the installer, click [Exit] to close the CD-ROM menu and then remove the CD-ROM from your computer.
Page 218 Connect the bundled AC adaptor to the [DC IN 5.3V] connector of the USB cradle and then plug it in to a household power outlet. • If you do not plan to use the AC adaptor, make sure that the camera’s battery is fully charged. Connect the USB cable that comes bundled with the camera to the USB cradle and the USB port of your computer.
Page 219 Press the camera’s [ON/OFF] button to turn it on and then press [MENU]. • Do not place the camera on the USB cradle yet. On the “Set Up” tab, select “USB” and then press [ ]. Use [ ] and [ ] to select “Mass Storage” and then press [SET].
Page 220 Camera-Computer Connection Pressing the cradle’s [USB] button puts it into the USB mode, which is indicated by the USB lamp lighting green. In this mode, your computer recognizes the memory card loaded in the camera (or the camera’s built-in memory if it does not have a memory card loaded) as a removable disk.
Page 221 ■ Connecting the Camera to Your Computer after the First Time Since you need to install the USB driver and configure menu settings only the first time you connect the camera to your computer, later connections are much simpler. Press the camera’s [ON/OFF] button to turn it off and then place the camera on the USB cradle.
Page 222 Double-click the file that contains the image you want to view. This displays the image. • For information about file names, see “Memory Folder Structure” on page 246. NOTE • An image that was rotated on the camera will be displayed on your computer screen in its original (unrotated) orientation.
Page 223 On the shortcut menu that appears, click “Copy”. Windows XP users: Click “Start” and then “My Documents”. Windows 2000/Me/98SE/98 users: Double- click “My Documents” to open it. • If you already have a “DCIM” folder in “My Documents”, the next step will overwrite it. If you want to keep the existing “DCIM”...
Page 224: Management Of Images On The Computer
■ Removing the Camera from the USB Cradle Windows XP/98SE/98 Users Press the USB cradle [USB] button. After making sure that the cradle’s USB lamp is not lit, remove the camera from the cradle. Windows 2000/Me Users Click card services in the task tray on your computer screen, and disable the drive number assigned to the camera.
Page 225 ■ Installing Photo Loader Start up your computer, and place the bundled CD-ROM into its CD-ROM drive. • Normally, this should cause the menu screen to appear automatically. If your computer does not display the menu screen automatically, navigate to the CD-ROM on your computer and then double-click the “MENU.exe”...
Page 226 IMPORTANT! • See the “Read me” file that comes with Photo Loader for information about what you need to do to be able to use existing libraries after updating, re-installing Photo Loader, or moving Photo Loader to another computer. If you do not follow the correct procedure for installation, you may not be able to display existing library information or calendar format HTML files with Photo Loader, or imported image...
Page 227: Retouching, Reorienting, Or Printing Snapshots
Retouching, Reorienting, or Printing Snapshots In order to retouch, reorient, or print snapshots on your PC, you need to install Photohands from the CD-ROM that comes bundled with the camera. IMPORTANT! • If you already have Photohands installed on your computer, check its version.
Page 228: Playing Movies
Playing Movies To play back a movie, first copy the movie to your computer and then double-click the movie file. In order to play a movie recorded with this camera on a Windows computer, you need to install DivX Player and the DivX codec (DivX Play Bundle) from the CD-ROM that comes bundled with the camera.
Page 229: Transferring Images To The Camera
■ Minimum Computer System Requirements for Movie Playback The minimum system requirements described below are necessary to play back movies recorded with this camera on a Windows computer. Operating System : Windows XP Memory : Pentium M, 1GHz or higher Pentium 4, 2GHz or higher Required Software : DivX Player (bundled with camera) IMPORTANT!
Page 230 First, connect the camera to your computer. • See page 217 for information about connecting the camera to your computer. On your computer, click “Start”, “All Programs”, “Casio” and then “Photo Transport”. This starts up Photo Transport. USING THE CAMERA WITH A COMPUTER...
Page 231 Drop the image data you want to transfer to the camera onto the Photo Transport Transfer button. Move your mouse pointer to the image file you want to transfer, and then hold down your mouse button. Keeping your mouse button depressed, drag the mouse pointer and the image file along with it to the Photo Transport Transfer button, and then release the mouse button.
Page 232 First, connect the camera to your computer. • See page 217 for information about connecting the camera to your computer. On your computer, click “Start”, “All Programs”, “Casio” and then “Photo Transport”. This starts up Photo Transport. Display the screen whose screen capture you want to transfer.
Page 233: Viewing User Documentation (Pdf) Files
Follow the instructions that appear on the display to transfer a capture of the selected area to the camera. • The image transfer method and detailed image settings used depend on the Photo Transport settings. For details, see Photo Transport help (page 233). IMPORTANT! •...
Page 234: User Registration
IMPORTANT! • You must have Adobe Reader or Adobe Acrobat Reader installed on your computer in order to view the contents of a PDF file. If you do not already have Adobe Reader or Adobe Acrobat Reader installed, install Adobe Reader from the bundled CD-ROM.
Page 235: Using The Camera With A Macintosh
• Use iPhoto, which comes management OS X bundled with your of images on operating system. your Macintosh Transfer CASIO DATA documents to OS X TRANSPORT 1.0 the camera – • Use Adobe Reader or View the OS 9/OS X Adobe Acrobat reader, User’s Guide...
Page 236: Viewing And Storing Images On A Macintosh
CASIO DATA TRANSPORT 1.0 : OS X 10.2.8 or greater Other : Sufficient memory to run the operating system IMPORTANT! • For details about the minimum system requirements for each software application, see the “readme” files on the CD-ROM that comes bundled with the camera.
Page 237 ■ Connecting the Camera to Your Computer the First Time Connect the bundled AC adaptor to the [DC IN 5.3V] connector of the USB cradle and then plug it in to a household power outlet. • If you do not plan to use the AC adaptor, make sure that the camera’s battery is fully charged.
Page 238 Press the camera’s [ON/OFF] button to turn it on and then press [MENU]. • Do not place the camera on the USB cradle yet. On the “Set Up” tab, select “USB” and then press [ ]. Use [ ] and [ ] to select “Mass Storage” and then press [SET].
Page 239: Connecting The Camera To Your Macintosh
Camera-Macintosh Connection Pressing the cradle’s [USB] button puts it into the USB mode, which is indicated by the USB lamp lighting green. In this mode, your Macintosh recognizes the memory card loaded in the camera (or the camera’s built-in memory if it does not have a memory card loaded) as a drive.
Page 240 ■ Viewing Camera Images on Your Macintosh After connecting the camera to your Macintosh, you can view camera images on your Macintosh screen. • For information about connecting to a Macintosh, see “Connecting the Camera to Your Macintosh after the First Time”...
Page 241 ■ Saving an Image on Your Macintosh In order to work on an image to put it into an album, you must first save it to your Macintosh. To save a camera image to your Macintosh, you must first establish a connection between them via the camera’s USB cradle.
Page 242: Management Of Images On Your Macintosh
■ Removing the Camera from the USB C On your Macintosh screen, drag the camera drive to Trash. Press the USB cradle [USB] button. After making sure that the cradle’s USB lamp is not lit, remove the camera from the cradle. Transfer of Images from the Camera and radle Management of Images on Your...
Page 243: Viewing User Documentation (Pdf Files)
Acrobat Reader. ■ To view the camera user’s guide On the CD-ROM, open the “Manual” folder. Open the “Digital Camera” folder and then open the folder for the language whose user’s guide you want to view. Open the file named “camera_xx.pdf”.
Page 244: Registering As A User
On the CD-ROM, open the “Manual” folder. Open the “Photo Loader” folder and then open the “English” folder. Open “PhotoLoader_english”. Registering as a User Internet registration only is supported. Visit the following CASIO website to register: http://world.casio.com/qv/register/ Reading Files Directly from a Memory Card The method you should use to read files from a memory card depends on the type of computer you have.
Page 245: Memory Card Data
DCF is a system that defines both image file formats and the structure of the folders that store data. This makes it possible for a digital camera, printer, or other DCF-compliant device to display or print image data from another DCF device.
Page 246: Memory Folder Structure
■ Memory Folder Structure (DCIM Folder) DCIM (Total Index File) INDEX.PVM (Recording Folder) 100CASIO (Image File) CIMG0001.JPG (Movie File) CIMG0002.AVI (Audio File) CIMG0003.WAV (Audio Snapshot Image File) CIMG0004.JPG (Audio Snapshot Audio File) CIMG0004.WAV (Document Folder) 101_VIEW (Document File) VIEW001.JPE (Document File) VIEW002.JPE (Document Management File) _THUMB.FNX...
Page 247 Folder and File Contents • DCIM Folder Folder that contains all of the camera files • Total Index File Management file of the document folder • Recording Folder Folder that contains files recorded with the camera • Image File File of an image shot with the camera. Extension is “JPG”. •...
Page 248: Supported Image Files
■ Supported Image Files • Image files shot with this camera • DCF-compliant image files Even if an image is DCF-compliant, this camera still may not be able to display it. When displaying an image recorded on another camera, it may take a long time for the image to appear on this camera’s monitor screen.
Page 249: Transferring Documents To Your Camera (Data Storage)
Transferring documents from a computer running Windows To transfer documents on your computer to the camera so you can view it on the monitor screen, you need to install CASIO DATA TRANSPORT from the CD-ROM that comes with the camera.
Page 250 On the menu screen, click the tab for the language you want. • Regardless of the language you select, the English version of CASIO DATA TRANSPORT is installed. Click the DATA TRANSPORT “Read me” file and read its contents. • “Read me” files contain important information about installation, including installation conditions and computer system requirements.
Page 251: Transferring Documents From A Macintosh
“Orientation” setting, and then click the [OK] button. Transferring documents from a Macintosh To transfer documents on your computer to the camera so you can view it on the monitor screen, you need to install CASIO DATA TRANSPORT from the CD-ROM that comes with the camera. ■...
Page 252 On the menu bar, click “File” and then “Print”. Click the PDF button at the bottom of the dialog box and then select “CASIO DATA TRANSPORT” from the menu that appears. This will display a dialog box for customizing document file properties (date, file name, icon).
Page 253: The Camera
Check the current data settings (date, file name, icon) and then click the [OK] button. This will convert the document to a JPEG image and transfer the image to the camera. • You can change the date, filename, and icon settings if you want.
Page 254 Use [ ], [ ], [ ], and [ ] to move the boundary to the document you want to select. • The document menu screen can show up to 12 documents. If there are more than 12 documents in camera memory, use [ ] or [ ] to switch between the menu screens of 12 images each.
Page 255: Deleting Documents From Camera Memory
Specifying the Initial Data Mode Screen You can use the following procedure to configure the camera so either the document data list or the last document page you were viewing appears first whenever you press [DATA] to enter the data mode. Press [MENU].
Page 256: Deleting Documents
■ To delete all the pages in a document page Display a page in the document whose pages you want to delete and then press [ ] ( Use [ ] and [ ] to select “All pages” and then press [SET].
Page 257 ■ To delete all documents While the document menu is displayed, press [MENU]. Use [ ] and [ ] to select “All docs” and then press [SET]. Use [ ] and [ ] to select “Yes”. • To cancel the delete operation, select “No” instead of “Yes”.
Page 258: Appendix
APPENDIX General Guide The numbers in parentheses indicate the pages where each part is explained. ■ Camera Front Shutter (page 65) [ON/OFF] (Power) (page 43) Flash (page 76) AF Assist/Self-timer Lamp (pages 63, 70, 81, 267) Lens Microphone (pages 91, 175) Back bkbl Operation Lamp...
Page 259 Bottom Battery/Memory Card Slots (pages 37, 48) Cradle Contact (page 39) Tripod Hole Use this hole when attaching to a tripod. Speaker (page 143) ■ USB Cradle Front Back Camera Contact (page 39) USB Lamp (pages 219, 238, 270) [USB] Button (pages 205, 219, 238) [PHOTO] Button (pages 150, 151)
Page 260: Monitor Screen Contents
Monitor Screen Contents The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status. • The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes.
Page 261 ■ Snapshot Playback Mode blbk File Type (page 142) Recording Mode Protect Indicator (page 180) Battery Level Indicator Folder Name/File Name (page 41) (page 179) Histogram (page 132) Snapshot Image Quality Exposure Compensation (page 69) (page 121) Snapshot Image Size (page 67) ISO Sensitivity (page 126) Aperture Value (page 66)
Page 262: Menu Reference
Icon Help Icon Help provides you instant access to information about the icons that appear on the monitor screen in the REC mode. You can turn off icon help if you want (page 137). • Icon Help text is displayed for the following functions. Recording mode, Focus mode, Flash Mode, Metering, White Balance, Self-timer, EV Shift •...
Page 263 Icon Help On* / Off Memory BEST SHOT: On / Off* Flash: On* / Off Focus: On / Off* White Balance: On / Off* ISO: On / Off* AF Area: On* / Off Metering: On / Off* Self-timer: On / Off* Flash Intensity: On / Off* Digital Zoom: On* / Off MF Position: On / Off*...
Page 264 Saturation +2 / +1 / 0* / –1 / –2 Contrast +2 / +1 / 0* / –1 / –2 Flash Intensity +2 / +1 / 0* / –1 / –2 Flash Assist Auto* / Off Set Up Tab Menu Sounds Startup* / Half Shutter / Shutter / Operation / Operation /...
Page 265: Play Mode
■ PLAY Mode PLAY Tab Menu Slideshow Start* / Images / Time / Interval / Effect / Cancel MOTION PRINT 9 frames* / 1 frame / Cancel Anti Shake On / Off* Movie Editing Cut (Before) / Cut (Between) / Cut (After) / Cancel* Keystone –...
Page 266: Display Menu Reference
Display Menu Reference The tables in this section show the items that appears on the menus that appear on the monitor screen when you press [DISP]. Most of these items are for configuring monitor screen settings. The items included on the menus depend on whether the camera is in the REC mode or PLAY mode.
Page 267: Indicator Lamps
Indicator Lamps The camera has lamps: an Operation Lamp and an AF assist/ self-timer Lamp. These lamps light and flash to indicate the current operational status of the camera. Operation Lamp AF assist/self-timer Lamp * There are three lamp flash patterns. Pattern 1 flashes once per second, Pattern 2 flashes twice per second, and Pattern 3 flashes four times per second.
Page 268 Assist/ Operation Lamp Self-timer Lamp Green Amber Pattern Cannot charge flash. Memory card problem / Memory Pattern card is unformatted. / BEST SHOT setup cannot be registered. Memory card is locked / Cannot create folder. / Memory is full. / Write error Pattern Low battery alert Pattern...
Page 269 ■ PLAY mode Assist/ Operation Lamp Self-timer Lamp Green Amber Pattern Pattern Operation Lamp Meaning Green Operational (Power on, recording enabled) Pattern One of the following operations is in progress: Delete, DPOF, protect, copy, format, resize, trimming, adding audio to snapshot, keystone correction, color correction, MOTION PRINT, movie editing,...
Page 270: Usb Cradle Indicator Lamps
■ USB Cradle Indicator Lamps The USB cradle has two indicator lamps: a [CHARGE] lamp and a USB lamp. These lamps light and flash to indicate the current operational status of the cradle and camera. [CHARGE] lamp USB Lamp [CHARGE] Lamp USB Lamp Color Status...
Page 271: Troubleshooting Guide
Troubleshooting Guide Find the Problem and Fixing It Problem Power does not turn 1) The battery is not oriented correctly. 2) The battery is dead. Camera suddenly 1) Auto Power Off activated (page 45). powers down. 2) The battery is dead. Image is not 1) Camera is in the PLAY mode.
Page 272 Problem Possible Causes The subject is out of The image is not focused properly. focus in the recorded image. The flash does not (Flash Off) is selected as the flash mode. fire. 2) The battery is dead. 3) A BEST SHOT scene that selects the flash mode is selected.
Page 273 Problem Possible Causes Digital zoom does not 1) The digital zoom setting is turned off. work. The zoom bar 2) Date stamping is turned on. indicates zoom only up to a zoom factor of 3.0. There is a vertical Shooting a very brightly lit subject can cause a vertical line on the monitor band to appear in the monitor screen image.
Page 274 If the same message appears after you turn power back on, contact your retailer or a CASIO service center. APPENDIX...
Page 275: If You Have Problems Installing The Usb Driver
If you have problems installing the USB driver... You may not be able to install the USB driver properly if you use the USB cable to connect the camera to a computer running Windows 98SE/98 before installing the USB driver from the bundled CD-ROM, or if you have another type of driver installed. This will make it impossible for the computer to recognize the camera when it is connected.
Page 276: Display Messages
This message appears and the camera turns off whenever lens performs some unexpected operation. If the same message appears after you turn power back on, contact your retailer or a CASIO service center. Load paper! The printer ran out of paper while printing. Memory Full Memory is full.
Page 277 Take action to remove the obstacle, and try turning on power again. SYSTEM ERROR Your camera system is corrupted. Contact your retailer or an authorized CASIO service center. The card is The LOCK switch of the SD memory card or locked.
Page 278: Specifications
Specifications ■ Main Specifications Product Type ..Digital Camera Model ... . EX-S770D ■ Camera Functions Image Files Format ....Snapshots: JPEG (Exif Version 2.2);...
Page 279 Approximate Approximate Image Size Image Built-in Memory Image File (Pixels) Quality (6.0MB) Size Capacity Fine 1.17 MB 4 images (1600 × Normal 780 KB 7 images 1200) Economy 390 KB 12 images Fine 360 KB 15 images (640 × 480) Normal 240 KB 22 images...
Page 280 * Number of image values are approximate and are provided for reference only. * Based on Matsushita Electric Industrial Co., Ltd. products. The number of images you can save depends on the type of memory card you are using. * When using a memory card with a different capacity, calculate the number of images as a percentage of 256 MB.
Page 281 Exposure Control ..Metering: Multi-pattern, center weighted, and spot by imaging element Exposure: Program AE Exposure Compensation: –2EV to +2EV (in 1/3EV steps) Shutter ....CCD shutter, mechanical shutter Snapshot (Auto): 1/2 to 1/2000 second Snapshot (Night Scene):...
Page 282: Power Supply
Monitor Screen..2.8-inch Wide TFT color LCD 230,400 (960 × 240) pixels Viewfinder ... . .Monitor Screen Timekeeping Functions . . .Built-in quartz digital clock Date and Time: Recorded with image data, Time stamp Auto Calendar: To 2049...
Page 283 *2 Continuous Playback Time Standard temperature (23°C (73°F)), one-image scroll approximately every 10 seconds *3 Approximate continuous recording time • The above values are based a new battery, starting from a full charge. Repeated charging shortens battery life. • Frequency of flash, zoom, and Auto Focus usage, and the time the camera is on greatly affects recording time and number of shots values.
Page 284 ■ Rechargeable Lithium Ion Battery (NP-20) Rated Voltage ..3.7 V Rated Capacitance ..700 mAh Operating Temperature . . .0 to 40°C (32 to 104°F) Dimensions ... .33.0(W) × 50.0(H) × 4.7(D) mm (1.3"(W) ×...
Page 285 CASIO COMPUTER CO.,LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA0610-B...

Casio Exilim EX-S770D User Manual

Unpacking

Quick Start Basics

Introduction

Getting Ready

Shooting a Snapshot

Shooting a Movie

Using Best Shot

Advanced Settings

Viewing Snapshots and Movies

Editing Images

Using Audio

Managing Your Files

Deleting Files

Other Settings

Printing

Computer

Your Camera (Data Storage)

Transferring Documents to

Appendix

Quick Links

Digital Camera

Related Manuals for Casio Exilim EX-S770D

Summary of Contents for Casio Exilim EX-S770D
