SERVICE MANUAL
MONO POWER AMPLIFIER
11 / 07-A
T0110700116
MRP-M1000

Advertisement

loading
Need help?

Need help?

Do you have a question about the MRP-M1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Alpine MRP-M1000

Summary of Contents for Alpine MRP-M1000

  • Page 1 All manuals and user guides at all-guides.com SERVICE MANUAL MONO POWER AMPLIFIER 11 / 07-A T0110700116 MRP-M1000...
  • Page 2 All manuals and user guides at all-guides.com <Cautions for Safe Repair Work> The following cautions will prevent accidents in the workplace and will ensure safe products. *The symbols indicate caution is needed to prevent injuries and damage to property. The symbols and their meanings follow. If you ignore this symbol and handle the product incorrectly or unsafely, Warning serious injury or death may result.

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com MRP-M1000 Contents Packing Assembly Parts List Packing Method View Specifications Block Diagram Parts Layout on P.W.Boards and Wiring Diagram Schematic Diagram 8 , 9 Terminal Voltage of IC/TR 10 to 12 Description of IC Terminal...

  • Page 4: Packing Assembly Parts List

    All manuals and user guides at all-guides.com MRP-M1000 Packing Assembly Parts List Symbol Symbol Part No. Description Part No. Description #1 101 68-10872Z20 MANUAL,OWNER'S(AO) 01E39152S01 ASSY,CONNECTOR 4P $1 101 15E40539S01 COVER,PLATE-R 68-10872Z21 MANUAL,OWNER'S(GO) %1 101 15E40540S01 COVER,PLATE-L 68-10872Z21 MANUAL,OWNER'S(GO) &1 101...

  • Page 5: Specifications

    All manuals and user guides at all-guides.com MRP-M1000 Specifications Power Output (20Hz, 4ohm, 1.0% T.H.D. (14.4V)) 600W (100Hz, 4ohm, 1.0% T.H.D. (14.4V)) 600W (20Hz, 2ohm, 1.0% T.H.D. (14.4V)) 1000W (100Hz, 2ohm, 1.0% T.H.D. (14.4V)) 1000W T.H.D. (100Hz, 10W, 4ohm (14.4V), Gain position : Center(NOM)) 1.0%...

  • Page 6: Block Diagram

    All manuals and user guides at all-guides.com MRP-M1000 Block Diagram IRF3415 x8 SUBSONIC FILTER OUTPUT(+) ISOLATOR INPUT GAIN BASS REVERSE BUFFER FILTER BUFFER LC Filter RCA IN 4P DRIVER 4560 4560 4560 4560 4560 4560 4560 NJM2137 MC14069 MC14081 IR2010S...

  • Page 7: Parts Layout On P.w.boards And Wiring Diagram

    All manuals and user guides at all-guides.com Parts Layout on P.W.Boards and Wiring Diagram MRP-M1000 MAIN P.W.Board (Component Side View) Q4001 C324 Q4003 Q4002 C4007 Q4004 E9905 E9904 Q9904 Q9905 Q9902 Q9903 D9901 C9903 TH9601 E9903 C9907 C9906 C9905 R9924...
  • Page 8 All manuals and user guides at all-guides.com R1109 TP1109 R1101 E1101 3.3/50 11kF C1205 R1905 R1906 5.1k R1102 TP1205 C1902 C1603 C1502 R1207 R1602 N.U. 0.12(MMTS) 11kF R1201 TP1201 VOL1501 E1102 15kF CB1101 3.3/50 TP1110 15kF C1903 C1601 C1602 0.1(MMTS) C1504 CONN, WAFER 4P N.U.
  • Page 9 All manuals and user guides at all-guides.com D4001 SK2BS R4103 R4107 E9801 R9719 C9716 C4003 C4008 R4001 30 - 1/4 C4105 0.01 - 5W N.U. 1200p R4002 30 - 1/4 220pF 220pF 1200p R4003 30 - 1/4 C9801 R9720 C9715 1000p Q4002 1200p...

  • Page 10: Terminal Voltage Of Ic/Tr

    All manuals and user guides at all-guides.com MRP-M1000 Terminal Voltage of IC/TR Unit : V IC1101 IC1102 IC1201 IC1401 8.9mv 8.9mv 0.4mv 0.6mv 8.8mv 8.8mv 4.9mv 0.6mv 8.6mv -0.6mv 4.9mv 0.5mv -15.05v -15.06v -15.06v -15.08v 8.7mv 9.4mv 7.3mv 8.8mv 9.1mv 5.5mv...
  • Page 11 All manuals and user guides at all-guides.com MRP-M1000 IC5003 IC5005 IC5201 13.57v 5.01v 0.7v 5.06v 0.6mv 5.06v 5.07v 5.07v 0.06mv 5.07v 0.6mv 0.06mv 5.07v -1.02v 0.06mv 31.9mv 4.13v 144.9mv 31.9mv 0.06mv 5.07v IC8801 IC9301 IC9302 IC9701 14.33v 4.97v 0.5mv 2.13v 0.7mv...
  • Page 12 All manuals and user guides at all-guides.com MRP-M1000 IC9902 IC9903 50.6mv 50.5mv 2.21v 2.206v 0.8mv 0.8mv 2.21v 2.206v 2.513v 2.506v 8.99v 8.99v 2.513v 2.51v 50mv 51.5mv Q4001 -43.8v 0.633v -47v Q1701 0.033 Q4002 -43.8v -0.285v -47v Q4401 4.93 4.91 -4.95 Q4003 1.7v...

  • Page 13: Description Of Ic Terminal

    All manuals and user guides at all-guides.com MRP-M1000 Description of IC Terminal TMP87C847UG : IC5002 Symbol Terminal Description SHORT_1(PULL-UP) SHORT_2(PULL-UP) Pull-up connect terminal. SHORT_3(PULL-UP) DATA_IN2(PULL-UP) iLIMIT_1 Output overcurrent detection terminal-1. iLIMIT_2(PULL-UP) iLIMIT_3(PULL-UP) iLIMIT_4(PULL-UP) Pull-up connect terminal. DC_OFFSET_1(PULL-UP) DC_OFFSET_2(PULL-UP) DC_OFFSET_3(PULL-UP) DC_OFFSET_4(PULL-UP) TEST(GND) GND connect terminal.

  • Page 14: Exploded View (Cabinet)

    All manuals and user guides at all-guides.com Exploded View (Cabinet) FUSE3 HL9002 FUSE2 FUSE1 HL9001 TML9001 FUSE4 TML4201 CB1101 VOL1401 JK1101 VOL1901 VOL1501...
