Icom IC-A210 Service Manual page 39

[VR UNIT]
REF ORDER
DESCRIPTION
NO. NO.
R1 7210003270 VAR TP76N00NA-26F-10KB-2974
R2 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R3 7030003320 S.RES ERJ3GEYJ 101 V (100)
C1 4030006900 S.CER C1608 JB 1H 103K-T
C2 4030006900 S.CER C1608 JB 1H 103K-T
C3 4030006860 S.CER C1608 JB 1H 102K-T
C4 4030006860 S.CER C1608 JB 1H 102K-T
J1 6510026160 S.CNR 06FLZ-SM2-TB (LF) (SN)
[K-CONNECT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
D1 1790001250 S.DIO MA2S111-(TX)
D2 1790001250 S.DIO MA2S111-(TX)
D3 1790001250 S.DIO MA2S111-(TX)
D4 1790001250 S.DIO MA2S111-(TX)
D5 1790001750 S.DIO DSM3MA4
L1 6110001660 COL LA-252
R1 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R2 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R3 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R4 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R5 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R6 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k)
R7 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R8 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R9 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R11 7540000250 ABS SA05C 401N
R12 7030003320 S.RES ERJ3GEYJ 101 V (100)
R13 7030003320 S.RES ERJ3GEYJ 101 V (100)
R14 7030003860 S.RES ERJ3GE JPW V
R15 7030003860 S.RES ERJ3GE JPW V
R16 7030003860 S.RES ERJ3GE JPW V
R17 7030003860 S.RES ERJ3GE JPW V
R18 7030003860 S.RES ERJ3GE JPW V
R19 7540000410 ABS ERZV14D470
C1 4030006900 S.CER C1608 JB 1H 103K-T
C2 4030004750 S.CER C2012 JB 1H 103K-T
C3 4030004750 S.CER C2012 JB 1H 103K-T
C4 4030006860 S.CER C1608 JB 1H 102K-T
C5 4030006860 S.CER C1608 JB 1H 102K-T
C6 4030006860 S.CER C1608 JB 1H 102K-T
C7 4030006860 S.CER C1608 JB 1H 102K-T
C8 4030006860 S.CER C1608 JB 1H 102K-T
C9 4030006860 S.CER C1608 JB 1H 102K-T
C10 4030006860 S.CER C1608 JB 1H 102K-T
C11 4030006860 S.CER C1608 JB 1H 102K-T
C12 4030006860 S.CER C1608 JB 1H 102K-T
C13 4030006860 S.CER C1608 JB 1H 102K-T
C14 4030006860 S.CER C1608 JB 1H 102K-T
C15 4030006860 S.CER C1608 JB 1H 102K-T
C16 4030006860 S.CER C1608 JB 1H 102K-T
C17 4030006860 S.CER C1608 JB 1H 102K-T
C18 4030006860 S.CER C1608 JB 1H 102K-T
C19 4030006860 S.CER C1608 JB 1H 102K-T
C20 4030006860 S.CER C1608 JB 1H 102K-T
C21 4030006860 S.CER C1608 JB 1H 102K-T
C22 4030011070 S.CER GRM31M2C2H5R0CY21L
C23 4030011070 S.CER GRM31M2C2H5R0CY21L
C24 4030006860 S.CER C1608 JB 1H 102K-T
C25 4030018980 S.CER C1608 JB 1H 104K-T
J1 6510014210 CNR BNC-BJ
J3 6510011591 CNR B2P-VH (LF) (SN)
J4 6510018941 S.CNR B13B-PH-SM4-TB (LF) (SN)
J6 6510017150 CNR TMP-S01X-C1
J7 6510026480 CNR HSJ1650-010020
F1 5210001070 S.FUS 0451008.MRL
W1 7120000490 JMP ERD25T0
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
