Icom IC-A210 Service Manual page 10

Feb. 2008
[VR UNIT]
REF ORDER
DESCRIPTION
NO. NO.
R1 7210003270 VAR TP76N00NA-26F-10KB-2974
R2 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R3 7030003320 S.RES ERJ3GEYJ 101 V (100)
C1 4030006900 S.CER C1608 JB 1H 103K-T
C2 4030006900 S.CER C1608 JB 1H 103K-T
C3 4030006860 S.CER C1608 JB 1H 102K-T
C4 4030006860 S.CER C1608 JB 1H 102K-T
J1 6510026160 S.CNR 06FLZ-SM2-TB (LF) (SN)
[K-CONNECT UNIT]
REF ORDER
DESCRIPTION
NO. NO.
D1 1790001250 S.DIO MA2S111-(TX)
D2 1790001250 S.DIO MA2S111-(TX)
D3 1790001250 S.DIO MA2S111-(TX)
D4 1790001250 S.DIO MA2S111-(TX)
D5 1790001750 S.DIO DSM3MA4
L1 6110001660 COL LA-252
R1 7030003500 S.RES ERJ3GEYJ 332 V (3 3 k)
R2 7030003500 S.RES ERJ3GEYJ 332 V (3 3 k)
R3 7030003500 S.RES ERJ3GEYJ 332 V (3 3 k)
R4 7030003500 S.RES ERJ3GEYJ 332 V (3 3 k)
R5 7030003500 S.RES ERJ3GEYJ 332 V (3 3 k)
R6 7030003500 S.RES ERJ3GEYJ 332 V (3 3 k)
R7 7030003640 S.RES ERJ3GEYJ 473 V (47 k)
R8 7030003580 S.RES ERJ3GEYJ 153 V (15 k)
R9 7030003440 S.RES ERJ3GEYJ 102 V (1 k)
R10 7030003680 S.RES ERJ3GEYJ 104 V (100 k)
R11 7540000250 ABS SA05C 401N
R12 7030003320 S.RES ERJ3GEYJ 101 V (100)
R13 7030003320 S.RES ERJ3GEYJ 101 V (100)
R14 7030003860 S.RES ERJ3GE JPW V
R15 7030003860 S.RES ERJ3GE JPW V
R16 7030003860 S.RES ERJ3GE JPW V
R17 7030003860 S.RES ERJ3GE JPW V
R18 7030003860 S.RES ERJ3GE JPW V
R19 7540000410 ABS ERZV14D470
C1 4030006900 S.CER C1608 JB 1H 103K-T
C2 4030004750 S.CER C2012 JB 1H 103K-T
C3 4030004750 S.CER C2012 JB 1H 103K-T
C4 4030006860 S.CER C1608 JB 1H 102K-T
C5 4030006860 S.CER C1608 JB 1H 102K-T
C6 4030006860 S.CER C1608 JB 1H 102K-T
C7 4030006860 S.CER C1608 JB 1H 102K-T
C8 4030006860 S.CER C1608 JB 1H 102K-T
C9 4030006860 S.CER C1608 JB 1H 102K-T
C10 4030006860 S.CER C1608 JB 1H 102K-T
C11 4030006860 S.CER C1608 JB 1H 102K-T
C12 4030006860 S.CER C1608 JB 1H 102K-T
C13 4030006860 S.CER C1608 JB 1H 102K-T
C14 4030006860 S.CER C1608 JB 1H 102K-T
C15 4030006860 S.CER C1608 JB 1H 102K-T
C16 4030006860 S.CER C1608 JB 1H 102K-T
C17 4030006860 S.CER C1608 JB 1H 102K-T
C18 4030006860 S.CER C1608 JB 1H 102K-T
C19 4030006860 S.CER C1608 JB 1H 102K-T
C20 4030006860 S.CER C1608 JB 1H 102K-T
C21 4030006860 S.CER C1608 JB 1H 102K-T
C22 4030011070 S.CER GRM31M2C2H5R0CY21L
C23 4030011070 S.CER GRM31M2C2H5R0CY21L
C24 4030006860 S.CER C1608 JB 1H 102K-T
C25 4030018980 S.CER C1608 JB 1H 104K-T
C26 4030018910 S.CER C1608 JB 0J 475K-T
C27 4030007130 S.CER C1608 CH 1H 101J-T
J1 6510014210 CNR BNC-BJ
J3 6510011591 CNR B2P-VH (LF) (SN)
J4 6510018941 S.CNR B13B-PH-SM4-TB (LF) (SN)
J6 6510017150 CNR TMP-S01X-C1
J7 6510026480 CNR HSJ1650-010020
F1 5210001070 S.FUS 0451008.MRL
W1 7120000490 JMP ERD25T0
All manuals and user guides at all-guides.com
[MB-113]
H/V
M.
LOCATION
D1
L1
R1
R2
R3
R4
R5
R6
R7
R8
R9
R10
R11
H/V
M.
LOCATION
C2
C3
T 10.9/9.7
C4
T 10.9/8.1
C5
T 15.4/12.3
C6
T 15.4/8.8
C7
T 54.2/6.7
C8
C9
C10
C11
C12
C13
T 26.4/12.5
C14
T 21.1/12.3
C15
T 28.3/12.3
C16
T 33.3/12.5
C17
T 30.7/13.3
C18
T 31.3/11.6
T 7.5/8.9
T 8.9/8.9
J1
T 16.8/12.3
J2
T 8 9/12.3
J4
J5
T 43/9.7
J6
T 45.3/8.6
T 25.2/10
T 22.6/10.4
F1
T 29.4/9.8
T 32.1/9.6
T 36.5/9.6
W1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
T 18.1/12.3
T 71.5/8
T 66.4/6.8
T 39.1/12.7
T 22.3/12.3
T 41.7/12.7
T 37.8/12.7
T 24.3/13.2
T 35.2/12.7
T 36.5/12.7
T 43/12.7
T 40.4/12.7
T 19.3/12.3
T 10.8/12.3
T 13.5/12.3
T 14.1/8.8
T 7 5/12.3
T 12.2/12.3
T 12.9/8.8
T 44.2/12.6
T 45.4/12.6
T 121.8/15.1
T 121/6.4
T 69.2/7.2
T 68/7.2
[CHN-01] only T 87/10
[CHN-01] only T 87/11.2
T 31.1/3.9
T 69.4/10.6
8
REF ORDER
DESCRIPTION
NO. NO.
1790001750 S.DIO DSM3MA4
6110001660 COL LA-252
7540000250 ABS SA05C 401N
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7030003860 S.RES ERJ3GE JPW V
7540000410 ABS ERZV14D470
7030003440 S.RES ERJ3GEYJ 102 V (1 k)
4030004750 S.CER C2012 JB 1H 103K-T
4030004750 S.CER C2012 JB 1H 103K-T
4030007130 S.CER C1608 CH 1H 101J-T
4030007130 S.CER C1608 CH 1H 101J-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030006860 S.CER C1608 JB 1H 102K-T
4030011070 S.CER GRM31M2C2H5R0CY21L
4030011070 S.CER GRM31M2C2H5R0CY21L
4030006860 S.CER C1608 JB 1H 102K-T
4030018980 S.CER C1608 JB 1H 104K-T
4030006860 S.CER C1608 JB 1H 102K-T
6510026210 CNR 2974BNC-BR
6510017150 CNR TMP-S01X-C1
6510018941 S.CNR B13B-PH-SM4-TB (LF) (SN)
6510025900 CNR DALC-J15PAF-11L9-E
6510021071 CNR S2P-VH (LF) (SN)
5210001070 S.FUS 0451008.MRL
7120000490 JMP ERD25T0
H/V
M.
LOCATION
T 65.7/16.5
T 43.5/14.1
T 40.3/14.1
T 37.9/13.4
T 35.7/14.1
T 31.6/14.1
T 29.4/13.6
T 26.1/14.1
T 24.2/13.6
T 22.3/13.4
T 53 8/5.2
T 62.4/16.5
T 43.5/12.8
T 41.1/12.1
T 38.7/11
T 35.7/12.8
T 34.5/10.8
T 31.6/12.8
T 30.5/11.5
T 28/12.1
T 26.6/12.1
T 24.1/11.7
T 7.6/8 9
T 14.1/4.1
T 52.1/5.3
T 50 8/5.3
T 22.3/10.5
T 32 3/4.9
T 49.8/11.3
S.=Surface mount
