Please check the pack contents before attempting to assemble this product. A full checklist of components is given in this leaflet. If any components are missing, please contact your the John Lewis Helpline. This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE CARE WHEN LIFTING to avoid personal injury and (or) damage to the product.
Page 2
Fitting and parts checklist M4 Allen Key x 1 Side Caps x 30 M5 Allen Key x 1 M6 X 25mm Bolts x 2 Centre Caps x 15 M6 X 40mm Bolts x 8 Headboard x 1 Footboard x 1 Side Rails x 2 Slats x 30 Centre Rail x 1...
Page 3
Step by step assembly instructions Step One Place wooden legs (6) over the holes in the underside of the headboard (1) and foot board (2) as per below drawing. M6 x 40 bolt M6 x 40 bolt M6 x 40 bolt Allen Key M6 x 40 bolt Bed Leg...
Page 4
Step Three Insert centre rail (5) into the brackets in the centre of the headboard (1) and foot board (2). Push down fully and secure in place using M6 x 25mm bolt (E) tighten using allen key M4 (A). Centre Rail M6 x 25mm M6 x 25mm Step Four...
Please be careful to retain all fitting when doing this. If you require any additional information or have any issues with this product please call the John Lewis Helpline on 01244 689949 or email mail@fwgroup-uk.com John Lewis Partnership 171 Victoria Street, London , SWIE 5NN.
