Icom IC-M506 Service Manual page 30

MP4(FRONT)
(8930089030)
MP10(FRONT)
(8930051970)
SP1(FRONT)
(2510001800)
MP6(FRONT)
(8930088990)
MP7(FRONT)
(8930089100)
MP5(FRONT)
(8310084000)
MP11(FRONT)
(Refer to the list.)
MC1(FRONT)
(Refer to the list.)
R1(VOL)
R1(SQL)
MP13(FRONT)
(8610014650)
MP15(FRONT)
(8930052280)
MP12(FRONT)
(8610014660)
MP22(CHASSIS)×7
(8810008661)
MP7(CHASSIS)
(8930084010)
MAIN UNIT
MP2(CHASSIS)
(8930083990)
MP3(CHASSIS)
(8930084000)
MP8(CHASSIS)
(8930059122)
MP1(CHASSIS)
(8010023020)
J1(CONNECT)
(6510030290)
CONNECT UNIT
MP6(CHASSIS)
MP5(CHASSIS)
(8510020340)
(8510020500)
IC1(CHASSIS)
MP23(CHASSIS)×2
MP14(CHASSIS)
(8810010021)
(8930049040)
• NMEA2000
MAIN UNIT
• NMEA2000
MP1(ACCESSORIES)×2
(8810008661)
6-4
All manuals and user guides at all-guides.com
LOGIC UNIT
DS1(LOGIC)
(5030003860)
MP22(FRONT)×3
(8810008661)
MP9(FRONT)
(8930088970)
MP8(FRONT)
(8930088960)
VOL UNIT
R1(VOL)
(7210003431)
SQL UNIT
R1(SQL)
(7210003431)
S1(DIAL)
DIAL UNIT
S1(DIAL)
(2250000730)
MP14(FRONT)
(8930069020)
MP21(FRONT)×2
(8810010610)
J1(CHASSIS)
(6510004881)
MP4(CHASSIS)
(8930034300)
• NMEA2000
CONNECT UNIT
• AIS
MAIN UNIT
• AIS
MP1(ACCESSORIES)×2
(8810008661)
MP21(FRONT)×9
(8810010610)
MP16(FRONT)
(8930055841)
MP25(FRONT)×7
(8810010620)
MP24(FRONT)×6
(8810010610)
MP11(CHASSIS)
(8510021180)
MP13(CHASSIS)
(8930058780)
MP15(CHASSIS)
(8930088950)
MP16(CHASSIS)
(8930088980)
NOTE: When replacing a flat cable, form the new one in the same shape as the original.
W2(CHASSIS)
(8920000800)
MP33(CHASSIS)
(8930055040)
MP34(CHASSIS)
(8930078850)
W1(CHASSIS)
(8920000790)
Legend:
Ref. No.
Unit Name
MP1 (CHASSIS)
(1234567890)
Parts No.
