Icom IC-M506 Service Manual page 26

[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R71 7030005310 S.RES ERJ2GEJ 124 X (120K)
R72 7030005310 S.RES ERJ2GEJ 124 X (120K)
R73 7030005090 S.RES ERJ2GEJ 104 X (100K)
R74 7030005090 S.RES ERJ2GEJ 104 X (100K)
R75 7030007280 S.RES ERJ2GEJ 331 X (330)
C1 4030017390 S.CER C1005 CH 1H 180J-T
C2 4030016790 S.CER C1005 JB 1E 103K-T
C4 4030017640 S.CER C1005 CH 1H 150J-T
C5 4030017760 S.CER C1005 JB 1H 222K-T
C6 4030017760 S.CER C1005 JB 1H 222K-T
C7 4030018010 S.CER C1005 CH 1H 360J-T
C9 4030017040 S.CER C1005 JB 1A 333K-T
C10 4030017760 S.CER C1005 JB 1H 222K-T
C11 4030017040 S.CER C1005 JB 1A 333K-T
C12 4030019990 S.CER C1005 JB 1C 104K-T
C13 4030016790 S.CER C1005 JB 1E 103K-T
C14 4030020000 S.CER C1005 JB 1A 105K-T
C15 4030017620 S.CER C1005 CH 1H 100C-T
C16 4030017680 S.CER C1005 CH 1H 820J-T
C17 4030017620 S.CER C1005 CH 1H 100C-T
C18 4030017390 S.CER C1005 CH 1H 180J-T
C19 4030017760 S.CER C1005 JB 1H 222K-T
C20 4030017760 S.CER C1005 JB 1H 222K-T
C21 4030017640 S.CER C1005 CH 1H 150J-T
C22 4030017760 S.CER C1005 JB 1H 222K-T
C24 4030017710 S.CER C1005 CH 1H 181J-T
C25 4030017370 S.CER C1005 CH 1H 3R5B-T
C27 4030017710 S.CER C1005 CH 1H 181J-T
C28 4030017760 S.CER C1005 JB 1H 222K-T
C30 4030017380 S.CER C1005 CH 1H 050B-T
C32 4030020000 S.CER C1005 JB 1A 105K-T
C34 4030017350 S.CER C1005 CH 1H 020B-T
C36 4030017630 S.CER C1005 CH 1H 120J-T
C37 4030017040 S.CER C1005 JB 1A 333K-T
C38 4030017350 S.CER C1005 CH 1H 020B-T
C39 4030019990 S.CER C1005 JB 1C 104K-T
C40 4030017670 S.CER C1005 CH 1H 390J-T
C41 4030019990 S.CER C1005 JB 1C 104K-T
C42 4030019990 S.CER C1005 JB 1C 104K-T
C43 4030019990 S.CER C1005 JB 1C 104K-T
C44 4030017040 S.CER C1005 JB 1A 333K-T
C45 4030017760 S.CER C1005 JB 1H 222K-T
C46 4030017040 S.CER C1005 JB 1A 333K-T
C47 4030020310 S.CER GRM31CB31C106KA88L
C49 4030017380 S.CER C1005 CH 1H 050B-T
C54 4030017040 S.CER C1005 JB 1A 333K-T
C55 4030017390 S.CER C1005 CH 1H 180J-T
C56 4030017660 S.CER C1005 CH 1H 330J-T
C57 4030017570 S.CER C1005 CH 1H 040B-T
C58 4030019990 S.CER C1005 JB 1C 104K-T
C59 4030017670 S.CER C1005 CH 1H 390J-T
C60 4030019990 S.CER C1005 JB 1C 104K-T
C61 4030019990 S.CER C1005 JB 1C 104K-T
C62 4030019990 S.CER C1005 JB 1C 104K-T
C63 4030017040 S.CER C1005 JB 1A 333K-T
C64 4030017760 S.CER C1005 JB 1H 222K-T
C65 4030017040 S.CER C1005 JB 1A 333K-T
C66 4030020310 S.CER GRM31CB31C106KA88L
C67 4030019990 S.CER C1005 JB 1C 104K-T
C68 4030017760 S.CER C1005 JB 1H 222K-T
C69 4030019990 S.CER C1005 JB 1C 104K-T
C70 4030020000 S.CER C1005 JB 1A 105K-T
C71 4030017040 S.CER C1005 JB 1A 333K-T
C72 4030017760 S.CER C1005 JB 1H 222K-T
C73 4030017760 S.CER C1005 JB 1H 222K-T
C74 4030017040 S.CER C1005 JB 1A 333K-T
C75 4030020000 S.CER C1005 JB 1A 105K-T
C77 4030016790 S.CER C1005 JB 1E 103K-T
C78 4030019990 S.CER C1005 JB 1C 104K-T
C79 4030017430 S.CER C1005 CH 1H 101J-T
C80 4030019990 S.CER C1005 JB 1C 104K-T
C81 4030017400 S.CER C1005 CH 1H 220J-T
C82 4030019990 S.CER C1005 JB 1C 104K-T
C84 4030016790 S.CER C1005 JB 1E 103K-T
C86 4030016790 S.CER C1005 JB 1E 103K-T
C87 4030020310 S.CER GRM31CB31C106KA88L
C88 4030016790 S.CER C1005 JB 1E 103K-T
C89 4030016790 S.CER C1005 JB 1E 103K-T
C90 4030020310 S.CER GRM31CB31C106KA88L
C91 4030016790 S.CER C1005 JB 1E 103K-T
C92 4030016790 S.CER C1005 JB 1E 103K-T
C93 4030019990 S.CER C1005 JB 1C 104K-T
C94 4030016790 S.CER C1005 JB 1E 103K-T
C95 4030016790 S.CER C1005 JB 1E 103K-T
C96 4030020310 S.CER GRM31CB31C106KA88L
C97 4030017420 S.CER C1005 CH 1H 470J-T
C98 4030017420 S.CER C1005 CH 1H 470J-T
C101 4030017760 S.CER C1005 JB 1H 222K-T
C102 4030017760 S.CER C1005 JB 1H 222K-T
C103 4030017350 S.CER C1005 CH 1H 020B-T
C104 4030017650 S.CER C1005 CH 1H 270J-T
C105 4030017650 S.CER C1005 CH 1H 270J-T
C106 4030017400 S.CER C1005 CH 1H 220J-T
C107 4030017340 S.CER C1005 CH 1H 010B-T
J1 6510030460 CON IMSA-9210B-2-06Z236-GF
J2 6510021411 S.CON S6B-ZR-SM4A-TF(LF)(SN)
EP1 6910016330 S.BEA MMZ1005S 601CT-S
EP3 6910016330 S.BEA MMZ1005S 601CT-S
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
All manuals and user guides at all-guides.com
H/V
M.
LOCATION
T 17.7/28.7
T 16.7/28.7
T 16.0/6.8
T 15.0/6.8
T 13.1/43.8
T 34.7/48.1
T 37.7/35.1
T 39.5/33.5
T 35.9/33.5
T 37.7/33.5
T 29.2/35.1
T 26.5/35.1
T 31.6/32.8
T 29.2/33.5
T 28.3/33.5
T 25.6/35.1
T 19.6/22.2
T 20.6/25.0
T 20.6/25.9
T 20.6/26.8
T 23.5/34.2
T 23.4/32.4
T 21.8/28.8
T 20.2/38.5
T 21.4/35.2
T 21.2/38.3
T 25.9/38.0
T 30.6/40.9
T 30.6/40.0
T 30.9/23.4
T 22.3/34.8
T 16.2/22.6
T 16.2/21.0
T 23.0/17.5
T 11.6/21.3
T 9.4/18.7
T 18.1/15.6
T 9.4/9.0
T 9.4/14.9
T 18.1/13.2
T 18.1/14.1
T 18.1/18.0
T 10.4/20.8
T 7.2/21.3
T 39.7/23.7
T 37.7/14.3
T 31.3/15.4
T 32.5/14.0
T 30.9/14.0
T 27.9/12.3
T 36.7/9.2
T 27.9/2.6
T 27.9/8.5
T 36.7/6.8
T 36.7/7.7
T 36.7/11.6
T 29.0/13.7
T 38.9/10.1
T 16.1/48.7
T 28.1/44.0
T 29.9/44.0
T 26.9/45.3
T 26.0/45.3
T 25.1/45.3
T 25.1/43.7
T 26.0/43.7
T 26.9/43.7
T 4.4/27.0
T 6.9/26.4
T 6.9/23.2
T 9.9/26.3
T 11.4/24.2
T 15.8/25.5
T 1.4/33.1
T 1.4/34.1
T 1.3/25.3
T 7.3/27.6
T 2.9/27.7
T 18.1/38.6
T 17.7/41.9
T 16.8/41.9
T 16.7/30.3
T 17.9/29.9
T 17.9/30.8
T 18.1/33.7
T 14.9/28.7
T 15.8/27.1
T 16.9/3.6
T 14.1/3.6
T 33.2/36.1
T 36.6/46.0
T 41.1/36.4
T 39.5/35.1
T 38.6/33.5
T 7.2/52.0
T 21.1/34.0
T 29.0/44.0
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5-12
S.=Surface mount
