Technical data

Column:
Product Code
Tube i.d. (mm)
Cross sectional area (cm
Maximum bed height (cm)
Minimum bed height (cm)
Max. column volume (L)
Adjustable capacity (L)
Pressure rating (bar/psi)
Operating temperature
Bed support size

Weights and Dimensions

Column:
Product Code
Adjuster Weight (kg)
Total weight empty (kg)
Total Weight Full* (kg)
Maximum diameter excluding casters (mm)
Maximum diameter including casters (mm)
Maximum height (mm)
Minimum clearance** (mm)
*based on bed height of 520 mm and specific gravity 1.05
**minimum height required to remove adjuster from acrylic tube unit
PC: Evolve 200_250 Columns Operating Manual v2
200
AB200505
200
2 ) 314.2
520
20
16.3
15.7
4/ 58
250
AB250505
250
490.9
520
20
25.5
24.5
4/ 58
2 to 30°C
8µm
200
AB200505
12.7
45.5
60
455
455
1550
1750
250
AB250505
15
52
76
495
495
1550
1750
6
