- Page 1 SP6R-LSC CONTROLLER User Manual DUPLEX LIFT STATION CONTROL BAR GRAPH 4-20 mA INPUT AUTOMATIC AL TERNATION MOTOR STATUS LEDs Ashland, OH 800-363-5842 Clearwater, FL 800-349-1905 Detroit Lakes, MN 888-342-5753 WWW.PRIMEXCONTROLS.COM Milford, OH 513-831-9959...
- Page 2 Setting Up Levels and Simulation ..........................11-12 11-12 Configuration Configuration ......................................13-15 13-15 Configuration Mode Parameters Configuration Mode Parameters ............................16 Run Mode Parameters Run Mode Parameters ..................................17 WWW.PRIMEXCONTROLS.COM PRIMEX™ SP6R-LSC Level Controller User Manual...
-
Page 3: Specifications
ENCLOSURE RATING Front Panel: IEC Standard IP54 (with additional gasket) for indoor use. Rear Case: IEC Standard IP20. BAR GRAPH 20 segment bar graph display for process value. Each bar represents 5% of full scale. PRIMEX™ SP6R-LSC Level Controller User Manual... - Page 4 4-20 mA device. The controller can be configured for pump down or pump up applications. The standard SP6R-LSC lift station controller kit contains (see Figure 2 on page 5 of this manual): • one SP6R-LSC lift station controller •...
- Page 5 Leave a minimum of 10 mm space for ventilation between the top and bottom edges of the control- ler and enclosure walls. EXPLOSION OR FIRE HAZARD Do not use this product with flammable liquids. Do not install in hazardous locations as defined by National Electrical Code, ANSI/NFPA 70. PRIMEX ™ SP6R-LSC Level Controller User Manual...
- Page 6 INSTALLATION & DIMENSIONAL DATA Pump High Level Seal Fail Lag Pump Over Temp. Lead Pump Low Level RESET FIGURE 1 Dimensions and panel cut-out. Dimensions are indicative and may be subject to change without notification. PRIMEX™ SP6R-LSC Level Controller User Manual...
- Page 7 PRIMEX ™ SP6R-LSC Level Controller User Manual...
- Page 8 INSTALLATION & DIMENSIONAL DATA FIGURE 2 Standard SP6R-LSC duplex lift station controller kit. PRIMEX ™ SP6R-LSC Level Controller User Manual...
-
Page 9: Electrical Connection
SELF POWERED SIGNAL TRANSDUCER Connect to terminal 2 and 4 and shield to terminal 3. NOTE: To avoid ground loops, the shield of the signal cable must only be grounded at one end. PRIMEX™ SP6R-LSC Level Controller User Manual... - Page 10 FIGURE 7 Self Powered Signal Connection. FIGURE 6 Loop Powered Transducer Connection. PRIMEX ™ SP6R-LSC Level Controller User Manual...
- Page 11 5. OUTPUT RELAY CONNECTIONS The relay outputs are rated up to 10 A (resistive) at 240 VAC, fuse protection is required indi- vidually or as a group. FIGURE 5 Typical Output Relay connections. PRIMEX ™ SP6R-LSC Level Controller User Manual...
- Page 12 Pressing once will increment the current value by one unit. Pressing and holding will begin repeatedly incrementing after a short delay. If the operator continues to hold the key, the value continues to increment at a faster rate. PRIMEX™ SP6R-LSC Level Controller User Manual...
- Page 13 STAR LD: Start lead pump level set point HI LEVEL: High level alarm set point 00000ec1 ALTERNAT: AUTO/1-2/2-1 alternation selector 00000ec2 FIGURE 8 Example of how to move LEVEL DISPLAY from level display screen. PRIMEX ™ SP6R-LSC Level Controller User Manual...
- Page 14 This value set the level for which all bars on the bar graph will turn OFF. BAR MAX This value set the level for which all bars on the bar graph will turn ON. PRIMEX ™ SP6R-LSC Level Controller User Manual...
- Page 15 MANUAL: The pump will shut down on over temperature and will not be allowed to run until the fault clears and the RESET button is pressed by the operator. PRIMEX™ SP6R-LSC Level Controller User Manual...
- Page 16 The pump run indication LEDs are on when the output relays for pump control are energized. RES CTRS RESET ALL COUNTERS Enter 12 in this field and all counters will be reset to zero. PRIMEX ™ SP6R-LSC Level Controller User Manual...
- Page 17 FIGURE 9 Use the arrow keys to navigate through 000UNITS these menu items. NOTE: Eight (8) seconds of inactivity (no keys pressed) will terminate the con- figuration menu and exit back to the run menu. PRIMEX™ SP6R-LSC Level Controller User Manual...
-
Page 18: Configuration Mode Parameters
LED ONLY, LOCK OUT, ONLY LAG ONLY OTHERMAL AUTO AUTO RST, LOCK OUT HIOALARM AUTO AUTO RST, MANUAL LOOALARM AUTO RST, AUTO MANUAL OOOOMODE PUMPXX PUMPXX PUMPXX ORUNOSIG USED UNUSED UNUSED RESOCTRS NOTES: PRIMEX ™ SP6R-LSC Level Controller User Manual... - Page 19 6.0 FT HIOLEVEL 999.9 7.0 FT ALTERNAT AUTO AUTO 1-2/2-1 OETM1OHR READ ONLY OETM2OHR READ ONLY OOOOOEC1 READ ONLY OOOOOEC2 READ ONLY SIMULATE 4 mA value in 20 mA value in configuration configuration NOTES: PRIMEX™ SP6R-LSC Level Controller User Manual...
- Page 20 “bubbler” control systems. Call today for more information. ASSEMBLED IN THE Ashland, OH 800-363-5842 Clearwater, FL 800-349-1905 Detroit Lakes, MN 888-342-5753 WWW.PRIMEXCONTROLS.COM Milford, OH 513-831-9959 © 2013 SJE-Rhombus® PN 1038548A PRIMEX ™ is a trademark of SJE-Rhombus®...
