- Page 1 4 in / 2 out portable audio/MIDI interface for iOS, Android and Mac/PC, with standalone functionality USER MANUAL...
-
Page 2: Table Of Contents
Contents Table of Contents Contents English Safety information iRig Pro Quattro I/O Register your iRig Pro Quattro I/O iRig Pro Quattro I/O overview Battery and external supply 1 Installation and setup 1.1 Mac/PC 1.2 Standalone operations 2 Setup your DAW... -
Page 3: English
Safety information CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. iRig Pro Quattro I/O can ONLY be used with: • Consumer grade non-rechargeable CARBON-ZINC batteries • ALKALINE batteries • Consumer grade Ni-MH rechargeable batteries... -
Page 4: Irig Pro Quattro I/O Overview
1. External DC power input - 2-pole barrel socket. 9V DC, 1.75A (max), positive on the external pole. When iRig Pro Quattro I/O is connected to a Lightning iOS device, using this DC In with the optional PSU (included in Deluxe version) will charge the connected iPhone or iPad. - Page 5 18. Loopback - the audio that is input to the iRig Pro Quattro I/O from your host is returned back to the host thru inputs 1 and 2. It is possible to control the level of the loopback stream with the host’s volume control.
-
Page 6: Battery And External Supply
Use only the specified AC adaptor (iRig PSU 9175) and make sure the line voltage at the installation matches the input voltage specified on the AC adaptor’s body. IK Multimedia will not be responsible of any damage caused by usage of any AC adaptor other than the specified one (iRig PSU 9175). -
Page 7: Installation And Setup
4. Download the IK apps and software. 5. You can connect up to four microphones using the XLR inputs on the iRig Pro Quattro I/O. 6. Inputs 1 and 2 can alternatively be used to connect Hi-Z instruments like guitar and bass, using a regular 1/4”... - Page 8 MIDI data. 12. To control an external MIDI device from an app, connect the MIDI OUT port of the iRig Pro Quattro I/O to the MIDI IN port of the external device. Always check for specific MIDI output settings in your app to make sure they are set to transmit MIDI data.
-
Page 9: Mac/Pc
1.2 Standalone operations It is also possible to use the iRig Pro Quattro I/O without any digital host connected: in this case it acts as a standalone mixer/mic preamp device. Just power it up thru battery, external USB or PSU and use the full set of inputs/outputs. -
Page 10: Direct Monitoring
4 Loopback With the Loopback function turned on, the audio that is input to the iRig Pro Quattro I/O from your host via USB is returned back to the host thru inputs 1 and 2. It is possible to control the level of the loopback stream with the host volume’s control. -
Page 11: Mode Switches
English 6 Mode switches 6.1 Multichannel mode When multichannel mode is selected, all four inputs are recorded as separate tracks in your DAW. Multichannel Stereo Mono MODE MODE MODE Safe Channels Safe Channels IN 1 IN 2 IN 3 IN 4 IN 1+3 IN 2+4 IN 1+3... -
Page 12: Stereo Mode
English 6.2 Stereo mode When stereo mode is selected, inputs 1 and 3 are mixed into a single track (DAW input 1), as well as inputs 2 and 4 (DAW input 2). When in this mode, DAW inputs 3 and 4 are used as safety channels: this means that you’ll be able to record the same signal present on DAW input 1 and 2 but reduced by 12dB as a backup in case your sound source gets loud unexpectedly and causes the main channel to distort. -
Page 13: Mono Mode
Pro Quattro I/O. NOTE: In your audio software, select the appropriate iRig Pro Quattro I/O input (1 to 4) as the source of the track you will be recording to. Adjust the channel gain knob until you have a sufficient audio signal without clipping. -
Page 14: Condenser Microphones
Connect them into the XLR ports on the top of iRig Pro Quattro I/O and activate the 48V phantom power and you’re ready to record in any situation. -
Page 15: Connecting Instruments
Quattro I/O using an 1⁄4” plug unbalanced (TS or “mono”) guitar cord. NOTE: In your audio software, select the appropriate iRig Pro Quattro I/O input (1 or 2) as the source of the track you will be recording to. Adjust the channel gain knob until you have sufficient audio signal without clipping. -
Page 16: Midi In/Out
11 MIDI IN/OUT 11.1 MIDI IN • Connect the 2.5mm-to-MIDI cable to the iRig Pro Quattro I/O MIDI IN port and to the MIDI OUT port on your keyboard or controller. • Open a Core MIDI compatible application on your iOS device or on your computer and set “iRig Pro Quattro I/O”... -
Page 17: Troubleshooting
This means your USB host device is not capable of providing the necessary current. Please install four AA batteries, or use an external power supply (DC IN or micro-USB) in iRig Pro Quattro I/O in order to use it with this USB host. -
Page 18: Specifications
English 14 Specifications Common AD and DA Resolution: 24-bit Sampling Rate: 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz Power: USB bus power, battery power (4 x AA), DC power supply (9VDC) or external USB power supply (5VDC, 1A min) Device Connection: Mini-DIN Size: 166 mm / 6.54″ x 92 mm / 3.62″ x 43 mm / 1.69″... - Page 19 English Frequency response: from 7 Hz to 46 kHz within 3 dB (96 kHz sample rate), min gain Dynamic range: 103 dB(A), min gain Microphone Inputs 3-4 2 x balanced, XLR. Pin 2: hot / Pin 3: cold / Pin 1: ground Input impedance: 1 kOhms Input level, min gain: 0 dBFS is obtained with a -3 dBu signal at the XLR input Input level, max gain: 0 dBFS is obtained with a -54 dBu signal at the XLR input...
- Page 20 English Stereo Output (unbalanced) Unbalanced, TRS 1/8” stereo Jack Output impedance: 150 Ohms balanced Output level: 0 dBFS corresponds to +12 dBu Frequency response: from 5 Hz to 44 kHz within 3 dB (96 kHz sample rate) Dynamic range: 100 dB(A) Channels crosstalk: 88 dB(A) Headphones Output TRS 1/8”...
-
Page 21: Warranty
English Warranty Please visit: www.ikmultimedia.com/warranty for the complete warranty policy. Support and more info www.ikmultimedia.com/support Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. - Page 22 Pro Quattro I/O, AmpliTube®, iRig® Recorder, VocaLive®, SampleTank® are trademarks property of IK Multimedia Production Srl. iPad, iPhone, iPod touch, Retina and Mac are trademarks of Apple Inc., registered in the U.S. and other countries. iPad Air, iPad mini, and Lightning are trademarks of Apple Inc. All other trademarks are property of their respective owners.
Need help?
Do you have a question about the iRig Pro Quattro I/O and is the answer not in the manual?
Questions and answers
why is Channel one of irig pro quattro not working
Channel one on the IK Multimedia iRig Pro Quattro I/O may not be working due to one of the following reasons:
1. The microphone is not properly connected. Always use an XLR-to-XLR balanced cable for microphones.
2. If using a dynamic microphone, phantom power must be turned OFF. Make sure the Phantom Power switch is OFF and the Phantom LED is off.
3. If using a condenser microphone, phantom power must be ON. Ensure the Phantom Power switch is ON and the Phantom LED is on.
4. In your audio software, the correct input (channel 1) may not be selected.
5. The gain for channel one may be too low. Adjust the gain knob to get a proper signal without clipping.
Check these settings to ensure channel one functions correctly.
