- Page 1 RTSO-6001B Product Manual Realtimes Beijing Technology Co., LTD. Fax：+86 010-84284669 / 84280996 Email: info@realtimes.cn Web Page: http://www.realtimesai.com Address: 11th Floor, Block B, 20th Heping Xiyuan, Pingxi Street, Chaoyang District, Beijing 100013,P.R.China...
- Page 2 Realtimes Beijing Technology Co.,LTD www.realtimesai.com Revision History Applicable Editor Revision Date Reason for change hardware version V1.0 2020-02 Initial release V1.0 V1.1 2020-06 Add notes and indicators V1.0 RT0086 V1.2 2022-03-08 Add software version supporting instructions V1.0 RT0086 RTSO-6001B Product Manual V1.2...
-
Page 3: Table Of Contents
BBREVIATION ........................20 THER RELATED INTRODUCTIONS 3.1 Jetpack ................................20 3.1.1 Jetpack Component summary ........................20 3.1.2 How to install Jetpack ..........................21 3.2 Developer tools ............................. 22 3. 3 Documentation .............................23 TERMS OF WARRANTY ...........................24 RTSO-6001B Product Manual V1.2... - Page 4 Realtimes Beijing Technology Co.,LTD www.realtimesai.com COPYRIGHT NOTICE ...............................25 RTSO-6001B Product Manual V1.2...
- Page 5 Therefore, it is recommended to observe anti-static safety precautions when handling any circuit board component (including RTSO-6001B). Anti-static safety protection measures include, but are not limited to the following: a) The smart box should be placed in an anti-static bag during transportation and storage, and then the board should not be taken out during installation and deployment.
- Page 6 5) Various peripheral module drivers released by the company; 6) The company's product fault diagnosis and after-sales maintenance services; 2. Scope of technical discussion Due to the wide range of embedded system knowledge and various types of involvement, we can not RTSO-6001B Product Manual V1.2...
- Page 7 Updates of subsequent documents, BSP, driver files and other official account will be updated in time. We will pay close attention to our developments in order to ensure that your information is up to date. We will push through WeChat public. RTSO-6001B Product Manual V1.2...
-
Page 8: Product Presentation
Nano , with a working temperature of -40℃ -- +80℃, low power consumption and high safety level, which can meet various harsh conditions. -
Page 9: Ordering Information
M.2 Video capture card,Eco Capture Dual SDI M.2 (dual-channel Eco Capture Dual SDI M.2 (optional) SDI video input), Eco Capture Quad SDI M.2(four-channel SDI Eco Capture Quad SDI M.2(optional) Video input) ME909S-821(optional) mini-PCIe Full netcom 4G module Order online https://shop340963258.taobao.com https://mall.jd.com/index-824786.html RTSO-6001B Product Manual V1.2... -
Page 10: Product Specifications
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Product specifications External interface function and location RTSO-6001B Product Manual V1.2... -
Page 11: Connectors Description
Connect external cooling fan Function Molex PicoBlade Header Type Pin define Signal Signal TACH 2.3 Micro SD card slot Function Micro SD（TF）slot Marking Micro SD（TF） Type Pin define Signal Signal SDIO_DATA2 SDIO_DATA3 SDIO_CMD SDIO_VCC SDIO_CLK SDIO_DATA0 SDIO_DATA1 SDIO_CD RTSO-6001B Product Manual V1.2... -
Page 12: Micro Sim Slot
Signal Signal CON_CSI_A_D0_N CON_CSI_A_D0_P CON_CSI_A_D1_N CON_CSI_A_D1_P CON_CSI_A_CLK_N CON_CSI_A_CLK_P CON_CAM1_PWDN CON_CAMA_MCLK CAM_I2C_SCL CAM_I2C_SDA VDD_3V3 2.6 RTC battery interface RTC battery Function 1.0mm Pitch 1x3Pin SIP Type Pin define Signal Signal Pin-1：The green box on the right . RTSO-6001B Product Manual V1.2... -
Page 13: Mini Pcie Slot
1.5V SMB_CLK SMB_DAT PCIE_TX- PCIE_TX+ CON_USB2_D- CON_USB2_D+ VCC_3V3_PCIE VCC_3V3_PCIE 1.5V 3.3V 2.8 Power interface Power IN Function Type 3.5mm Pin define Signal Signal VCC (+) GND (-) Pin-1：The green box on the right . in：single +5V RTSO-6001B Product Manual V1.2... -
Page 14: Led
TMDS Clock GND TMDS Clock- No Connect DDC clock DDC data DDC GND +5V Power Hot Plug Detect 2.11 Gigabit Ethernet Function Gigabit Ethernet Type RJ45 Pin define Signal Signal TP0+ TP0- TP1+ TP2+ TP2- TP1- TP3+ TP3- RTSO-6001B Product Manual V1.2... -
Page 15: Usb
Signal Signal VBUS USB 2.0 D- USB 2.0 D+ USB ID When usb-otg is in host mode, the USB ID Pin needs to float. When usb-otg is slave mode, USB ID Pin needs to be grounded. RTSO-6001B Product Manual V1.2... -
Page 16: Function Pin
UART1 Debug serial port, 3.3V TTL logic level The mapping file on the Linux system is ttyS0 in the /dev directory. The derived GEN1_I2C and GEN2_I2C buses correspond to the iic-1 and iic-0 buses in the Linux system. RTSO-6001B Product Manual V1.2... -
Page 17: Serial Port
Pin-2: the mark in the green box of the picture on the right. Pin location: marked by the blue box on the right. The mapping files for SPI1 and SPI2 on Linux systems are spi0.0 and spi1.0 in the /dev directory. RTSO-6001B Product Manual V1.2... -
Page 18: Dip Switch
2BIT Dip Switch Type Pin define status default：enables USB2.0，Mini PCIE disables USB2.0 BIT1 disables USB2.0，Mini PCIE enables USB2.0 default： enables Micro USB2.0 power supplies to carrier board BIT2 disables Micro USB2.0 power supplies to carrier board RTSO-6001B Product Manual V1.2... -
Page 19: Product Size
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 3 Product size 4 Hardware update history RTSO-6001B update history Version Reason for change V1.0 Initial release RTSO-6001B Product Manual V1.2... -
Page 20: Software Version Supporting Instructions
USB cable to connect the keyboard and mouse...) d) connect the power cord to the power supply. e) RTSO-6001B adopts automatic/manual power on design. Turn on the power and the system starts to work. f) for systems without protective enclosure, please avoid moving the whole system after the system is powered on. -
Page 21: Recovery Mode
Procedure to place system in Force USB Recovery Mode: Power down the device. Use USB cable to connect RTSO-6001B OTG-USB port (P4) with Jetson to develop host USB port. Press the Recovery button and do not release it. Power supply to the system will be maintained for more than 3 seconds, and then release the Recovery button The system enters the Recovery mode, and subsequent operations can be carried out at this time. -
Page 22: How To Install Jetpack
Use Micro USB cable to connect Linux host and Jetson Feiyun Smart Box (or network (same network segment)) During the setup process, SDK Manager will provide Internet connection for your jetson Feiyun Smart Box via USB or network connection. RTSO-6001B Product Manual V1.2... -
Page 23: Developer Tools
API debugging through the user interface and command line tools. • NSight Graphics for Graphics Application Debugging and Profiling: A consolegrade tool for debugging and optimizing OpenGL and OpenGL ES programs. Running on a Linux host. All Jetson products are supported. RTSO-6001B Product Manual V1.2... -
Page 24: Documentation
Documentation • CUDA Toolkit • NVIDIA Container Runtime • OpenCV Documentation • Jetson Linux Multimedia API Reference • Nsight Systems • nvprof • Visual Profiler • Nsight Graphics • Nsight Compute CLI • VPI–Vision Programming Interface RTSO-6001B Product Manual V1.2... -
Page 25: Terms Of Warranty
Other failures which are clearly due to misuse(such as overvoltage,polarity reversal, the pin bent or broken,the wrong connection,drop damage,transportation damage,damage due to over operating temperature and so on). e) The logo and part number on the product have been deleted or removed. The product is out of warranty. Special concerns RTSO-6001B Product Manual V1.2... - Page 26 Without the written permission of the company, no unit or individual may copy, extract, backup, modify, disseminate, translate into other languages, or use all or part of it for commercial purposes in any way or form. RTSO-6001B Product Manual V1.2...
