Identifying the Correct
Com Port
The computer Communications Port to which the
PC-3.5 serial cable is connected can be identified by
using a paper clip
1. Disconnect the meter from the serial cable.
2. Click on the Com Port button on the main
software screen. This will bring up the Port
Selection screen.
3. Select the Com port to be tested and click on the
Port Test button. In the Port Test screen, click the
Test Port Now button.
4
