I M P O R T A N T : Please read this entire manual before installing or operating your umbrella. D I A G R A M & P A R T S L I S T 1. Self-Locking Canopy Fastener 7.
Page 3
IMPORTANT: It is imperative to install the appropriate base weight. The minimum base weight recommended for the JCP101 is 100lbs. A S S E M B L Y I N S T R U C T I O N S Two-person team is recommended for assembly Installing Internal Stem onto JCB101 Base 1.
Page 4
Installing Umbrella 1. Lay umbrella on soft clean surface. Attach finial to canopy structure. 2. Using a two-person team, carefully lift umbrella and insert bottom of center pole onto internal mast stem. NOTE: Carefully take note of holes on umbrella center pole and holes on internal mast stem.
Page 5
To Close Canopy center hub down to unlock from pole. Guide center hub down pole until umbrella 1. Gently pull is fully closed. To Properly Fold Canopy The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time.
Page 6
2. Inspect the installation fittings, mount bolts, rib spacers, etc. on a regular basis and tighten if necessary. 3. Seaside and indoor pool use: Due to demands of both of these environments, Jardinico recommends weekly or biweekly cleaning with mild soap and water to remove the concentrated deposits and protect the powder coat finish.
Page 7
5 Year Limited Warranty covers the wheels, powder coat finish, rust and corrosion on all bases. If the powder coat finish flakes, bubbles, peels or loses color; Jardinico will re-finish or replace the defective base at its discretion. Normal wear and tear is not covered under this limited warranty.
Page 8
Those filing warranty claims will be responsible for all shipping, handling, and freight charges on all claims to Jardinico in Baldwin Park, CA. All warranty claims must be submitted with the original proof of purchase, date of purchase, name of dealer, and the description of the damage.
