- Page 1 LOG SPLITTER BE-LS40TS390 OPERATIONS & PARTS MANUAL PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INFORMATION SAFETY DECALS PRE-OPERATION SETTING UP OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS BREAKDOWN BE-LS40TS390 USER MANUAL... -
Page 3: Important Safety Information
Indicates a hazardous situation which, if not followed, could result in minor to moderate injury. NOTICE Is important information about the proper use of your machine. Failure to follow this instruction could result in damage to your machine or property. BE-LS40TS390 USER MANUAL... - Page 4 WARNING Your Responsibility - Restrict the use of this power machine to persons who read, understand and follow the warnings and instructions in this manual and on the machine. BE-LS40TS390 USER MANUAL...
- Page 5 Make sure you comply with applicable local, state and federal codes. Take appropriate firefighting equipment with you. NEVER Use this log splitter for any purpose other than splitting wood, It is designed for this use can cause serious injury or death. BE-LS40TS390 USER MANUAL...
-
Page 6: Pre-Operation
We recommend a Wide Vision Safety Mask for use over eyeglasses or standard safety glasses with side shields. Always use eye protection marked to comply with ANSI Z87.1. BE-LS40TS390 USER MANUAL... - Page 7 • NEVER move the log splitter while the engine is running. Shut o the engine if you are leaving the log splitter, even for a short period of time. • ALWAYS be careful when moving or lifting the log splitter. Get assistance if it feels too heavy to move • yourself by yourself. BE-LS40TS390 USER MANUAL...
-
Page 8: Setting Up
2. Use a black plastic bushing to fix the axle cap (#75) like below picture. Please cover the black bushing onto the axle cap, and use rubber/wooden hammer knocking the end of the plastic bushing and make the axle cap fixed on wheel. Plastic Bushing Axle Cap Figure 3-2 BE-LS40TS390 USER MANUAL... - Page 9 Assemble the right fender (#53) to right side to the oil tank, and left fender (#56) to another side, and fixed by hex bolt M10x30 (#41), flat wash Ø10 (#42), lock nut M10 (#43). Note: Put a rubber washer (#105) between fenders and oil tank. 41 42 43 41 42 43 Figure 3-4 BE-LS40TS390 USER MANUAL...
- Page 10 2. Assemble the gear pump assembly to the engine by using hex bolt M8x25 (#86), lock washer Ø8 (#87) and flat washer Ø8 (#4). 3. Assemble the connector cover (#99) to the gear pump stand by using hex bolt M5x10(#98). Figure 3-7 BE-LS40TS390 USER MANUAL...
- Page 11 2. Assemble the wood tray (#37) to tray frame (#38), fixed by hex bolt M8x35 (#39), flat washer Ø8 (#4), nylon lock nut M8 (#5). 3. Attach the wood tray assembly to the right log cradle (#40). 39 4 5 Figure 3-9 BE-LS40TS390 USER MANUAL...
-
Page 12: Operation
14. D.O.T Pneumatic Tire: Maximum rated speed is 45 MPH. 15. Fenders with Reflector Lamp 16. Large Wood Tray 17. Log Cradle: Keeps the log on the beam without operator assistance. 18. Cast Steel Wedge Component. Figure 4-1 BE-LS40TS390 USER MANUAL... - Page 13 8. After engine starts, move choke lever (if equipped) to OFF position. Place throttle lever to the speed desired. 9. In cold weather, run wedge up or down beam 6 to 8 times to circulate the hydraulic fluid. BE-LS40TS390 USER MANUAL...
- Page 14 1) If coupler hitch does not fit on ball: Turn adjustment nut one turn counter-clockwise. Figure 4-5 2) If coupler hitch is too loose on ball: Turn adjustment nut one turn clockwise. 5. Connect the safety chains to the towing vehicle. BE-LS40TS390 USER MANUAL...
- Page 15 HORIZONTAL OPERATING POSITION Figure 4-6 WARNING Always use the log splitter in the vertical position when splitting heavy logs. BE-LS40TS390 USER MANUAL...
- Page 16 6. Use a flexible “spider” type coupling between engine and pump drive shafts. 7. Keep hoses clear and unblocked, untouched any metal part. 8. Bleed air out of hoses before operating. 9. Flush and clean hydraulic system before restarting after servicing. 10. Use “pipe dope” on all hydraulic fittings. BE-LS40TS390 USER MANUAL...
- Page 17 5. Connect the safety chains to the towing vehicle. WARNING Do not tow faster than 45mph and check local, state requirements before towing on any public road. NOTE: Use caution when backing up. It is recommended to use a spotter outside the vehicle. BE-LS40TS390 USER MANUAL...
-
Page 18: Maintenance
6. Replace spark plug. 7. Do not store gasoline from one season to another. 8. Replace your gasoline can if it starts to rust. Rust and/or dirt in the gasoline will cause problems. BE-LS40TS390 USER MANUAL... - Page 19 Excessive pressure when seating beads may cause tire/rim assembly to burst with force sufficient to cause serious injury. Refer to sidewall of tire for recommended pressure. NOTE: Always dispose of used hydraulic fluid and engine oil at approved recycling centers only. BE-LS40TS390 USER MANUAL...
- Page 20 9. Store unit in a clean, dry area. Do not store next to corrosive materials, such as fertilizer. NOTE: If storing in an unventilated or metal storage shed, be certain to rustproof the equipment by coating with a light oil or silicone. BE-LS40TS390 USER MANUAL...
-
Page 21: Troubleshooting
6. See authorized service dealer. Hydraulic lines blocked. Flush and clean hydraulic system. 8. Incorrect oil level. 8. Check oil level. 9. Damaged directional valve. 9. See authorized service dealer. 10. Blocked directional valve. 10. Flush and clean hydraulic system. BE-LS40TS390 USER MANUAL... -
Page 22: Specifications
Oil Capacity is 3.4 gallons(12.8L). Use types 10W AW32, ASLE H-150, and ISO32. The manufacturer reserves the right to make improvements in design and/or changes in specifications at any time without incurring any obligation to install them on units previously sold. BE-LS40TS390 USER MANUAL... -
Page 23: Breakdown
BREAKDOWN BE-LS40TS390 USER MANUAL... - Page 24 Lock Washer Ø12 9210-12000-DX Thick Hex Nut M12 LSA22-03001 Keeper Plate LST37-00001 Wood Tray LST37-11000 Wood Tray Frame 9101-08035-DX Hex Bolt M8x35 LST37-02000 Left Log Cradle 9101-10030-DX8.8 Hex Bolt M10x30 9301-10000-DX Flat Washer Ø10 9206-10000-DX Hex Lock Nut M10 BE-LS40TS390 USER MANUAL...
- Page 25 Wheel / Tire Assembly LST37-08000 Outside Wheel Bushing LST37-09000 Moving Pipe NS10-02001 Screw Rod LST37-00016 Oil Return Pipe Connector 9121-06010-FH Screw M6x10 LSP35-02001 Gasoline Engine 13HP LSP35-00001 Polyurethane Block 9302-10000-DX Big Flat WasherØ10 9101-08025-DX8.8 Hex Bolt M8x25 BE-LS40TS390 USER MANUAL...
- Page 26 LSP35-02005 Gear Pump Stand 8801-7X7X40 Flat Key 9101-05010-DX8.8Q Hex Bolt M5x10 LSP25-10006 Connector Cover 9901-14*2.5 O Ring 14x2.5 LST37-00006 Hydraulic Hose (Valve-Oil Tank) LST37-00008 Hydraulic Hose (Valve-Pump) LSP25-00011-DG Hose Clamp LST37-00011 Oil Pipe LSA22-00021 Rubber Washer 2 BE-LS40TS390 USER MANUAL...
- Page 27 BE-LS40TS390 USER MANUAL...
- Page 28 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-LS40TS390 USER MANUAL...
