7.4.5
Foundation and empty conduit plan and reinforcement mTripod
FMTP-MS
5
Fig. 8:
1
Foundation, frost depth, outdoor area
2
Outline mTripod FMTP-MS
3
Boreholes (6 x)
4
Feed-through for empty conduits
5
Passage side, side of the locking arms
400
(180)
8.5
40
22.5
mTripod FMTP-MS foundation and empty conduit plan (dimensions in mm)
1
2
3
4
10
mTripod
Installation and assembly
1
