Design and function

4.1

Design

1
Fig. 4:
1 Room for access-control device provided by the customer, e.g. card reader
2 Space for GED (passage direction display)
3 Control unit MGC
4 Drive for blocking element, consisting of 3 blocking arms
5 Blocking arm (3 x)
6 Cover for control unit and drive blocking element
consisting of cover and trapezoidal plate
7 Side part (front panel)
8 Drop arm (option)
3
2
Design, shown here mTripod FMTP-ML
6
5
4
8
