Do not use products that form a protective film on the glass as these agents may be perceived as patchy or as a flow pattern in the screen print. Macro Design showers must not be cleaned with agents that contain aromatic hydrocarbons, acids, ammonia, sodium hydroxide solution or chlorine.
Page 3
SV - Alla duschar från Macro Design AB är CE-märkta och uppfyller kraven i standarden. GB - All showers from Macro Design AB are CE marked and meet the requirements of the standard. NO - Alle dusjer fra Macro Design AB er CE-merket og oppfyller kravene i standarden.
Page 4
SV - Måttskiss / GB - Measurement diagram / NO - Målskisse Infälld blandare / Recessed mixer / Innfelt blandebatteri Standard & Standard blandare /mixer /blandebatteri 2150 1980 1980 1100 1050 810 x 810 mm 1140 910 x 910 mm 1280 D = Öppning/ Opening/...
Page 7
SV - Montering / GB - Fitting / NO - Montering 2509 2506 (x3) ALT. 103800 3085M(x2) 103801 SV - Har badrummsgolvet så mycket lutning/fall så att den mittersta korta ställfoten inte går att justera ut tillräckligt. Byt då plats på den korta ställfoten och en lång ställfot som inte är utjusterad så mycket. GB - Has the bathroom floor so much slope / fall that the middle short feet cannot be adjusted out sufficiently.
Page 8
103141 SV - Karet ska vägas in på samma plats som duschkabinens placering. Säkerställ att alla fötter och hjul har stöd mot golvet. GB - The tray should be leveled on the same spot as the shower cabin location. Make sure that all feets and wheel are supported on the floor. NO - Karet skal være satt med vater på...
Page 13
SV - Skruva nedre hållaren först utan rör. Övre skruv går 17. Standard genom både rör och hållare. GB - Screw the lower holder first without pipe. The upper screw goes through both the pipe and the holder. NO - Skru nedre holder først uten rør. Den øvre skruen går gjennom både røret og holderen.
Page 14
26106 (x2) 3094 (x2) SV - Obs! Hjul med fjäder ska vändas nedåt, mot duschkaret GB - Note! Wheels with spring must be turned downwards. NO - Merk! Hjul skal være nede på dørene, mot dusj-karet. 14 (16)
Page 16
MACRO DESIGN ÄR ETT SVENSKT FÖRETAG SOM TILLVERKAR DUSCHAR, BADRUMSMÖBLER OCH BADRUMSTILLBEHÖR. NÄR DU VÄLJER EN PRODUKT FRÅN MACRO DESIGN SÅ VET DU ATT DU HAR GJORT ETT TRYGGT KÖP, MED GENERÖSA GARANTIER OCH EN PRODUKT SOM KOMMER ATT HÅLLA I MÅNGA ÅR FRAMÖVER.
