- Page 1 MORAINE ARMCHAIR PRODUCT NO. 088-0543-0 ASSEMBLY INSTRUCTIONS HAVING TROUBLE? TOLL-FREE: 1-888-670-6684 IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference.
- Page 2 From on-trend furniture pieces to holiday décor and all your outdoor living essentials, CANVAS® makes it easy to refresh your space your unique style and the way you live every day. We would love to hear from you and welcome your thoughtful feedback.
- Page 3 TABLE OF CONTENTS Tools Required Parts List Step-by-step Guide Caring for Your Item Warranty WARNING! TO REDUCE THE RISK OF SERIOUS INJURY, READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE ASSEMBLING AND USING THE PRODUCT. • The maximum weight capacity for the chair is 225 lb (102 kg). Do not stand on the chair.
- Page 4 PARTS LIST ITEM DESCRIPTION THUMBNAIL QUANTITY Chair back Chair seat panel Right arm Left arm Seat cushion Back cushion Plastic foot MORAINE ARMCHAIR...
- Page 5 EXPLODED PARTS HARDWARE LIST ITEM DESCRIPTION THUMBNAIL QUANTITY Screw M6*18 Screw M6*40 Screw M6*45 Washer M6 Hex key Spring washer Washer M8 Wrench MORAINE ARMCHAIR...
- Page 6 STEP-BY-STEP GUIDE STEP 1 Place the right arm onto a non-abrasive surface, such as a carpet, with its inside facing upwards Attach two plastic feet to the bottom of the right arm with nuts , spring washers and washers using wrench aligning the holes.
- Page 7 STEP 2 Place the chair back onto a non-abrasive surface, such as a carpet. Attach the chair seat panel to the chair back with screws and washers using hex , aligning the holes. When assembled, tighten the screws with hex key NOTE: Do not fully tighten screws until you have assembled...
- Page 8 STEP-BY-STEP GUIDE STEP 3 Place right arm onto a non-abrasive surface, such as a carpet. Attach right arm to chair back chair seat panel with screws , butterfly bolt washers using hex key , aligning the holes. When assembled, tighten all screws with hex key NOTE: Do not fully tighten screws until you have assembled...
- Page 9 STEP 4 Place left arm onto a non-abrasive surface, such as a carpet. Attach left arm to chair back and chair seat panel with screws butterfly bolt and washers using hex key aligning the holes. When assembled, tighten all screws with hex key NOTE: Do not fully tighten screws until you have assembled...
- Page 10 STEP-BY-STEP GUIDE STEP 5 Put the seat cushion and back cushion on the seat. MORAINE ARMCHAIR...
- Page 11 OFF SEASON: Clean and dry before storing in a dry, sheltered area. WARRANTY INFORMATION This CANVAS® product carries a one (1) year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase.
