BODY COMPOSITION ANALYZER
MC-780MA-N
Separate Version
<Usage Conditions>
5 to 35°C
Temperature
:
Relative Humidity :
30 to 80%
(without condensation)
Maximum Altitude : 2,000m ASL
Atmospheric
:
86 to 106kPa
Pressure Range
Please read this Instruction Manual carefully and keep it for future reference.
Instruction Manual
<Storage Conditions>
Temperature
RelativeHumidity
Atmospheric Pressure Range : 70 to 106kPa
To avoid malfunctions, avoid storing the equipment in a place with direct sunlight,
significant temperature changes, a risk of dampness, a large amount of dust or a
risk of vibration or impact, or in the vicinity of flames.
Column Mounted Version
-10 to 50°C
:
:
10 to 90% (without condensation)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MC-780MA-N and is the answer not in the manual?

Questions and answers

Summary of Contents for Tanita MC-780MA-N

  • Page 1 BODY COMPOSITION ANALYZER MC-780MA-N Instruction Manual Separate Version Column Mounted Version <Usage Conditions> <Storage Conditions> 5 to 35°C -10 to 50°C Temperature Temperature Relative Humidity : 30 to 80% RelativeHumidity 10 to 90% (without condensation) (without condensation) Atmospheric Pressure Range : 70 to 106kPa...
  • Page 2 Intended Use TANITA Body Composition Analyzers have been clinically proven to be accurate, reliable and provide highly repeatable results. Our Analyzers are used worldwide by health, research and medical professionals primarily in the following fields: - medical screening and health assessments of adults and children - monitoring the progress of weight loss during medical treatment relating to lifestyle diseas- es such as diabetes, hyperlipidemia, bariatric surgery, hypertension and fatty liver disease.
  • Page 3: Table Of Contents

    Contents Before Use For Your Safety Part Names & Connection Procedure Power Supply Settings How to Use Taking a Measurement Body Composition Mode Measurement Results Scale Mode Weight Lock Mode General Instructions for Body Composition Measurement Judgment Results Body Water and Extracellular Water Output and Storage of Measurement Results If Necessary Troubleshooting...
  • Page 4: For Your Safety

    For Your Safety This section explains precautionary measures to be taken to avoid injury to the users of this device and others, and to prevent damage to property. Please familiarise yourself with this information to ensure safe operation of this equipment. Warning Failure to follow instructions highlighted with this mark could result in death or severe injury.
  • Page 5 Caution Keep away from water. Avoid using on subjects with metal allergies. Allergic reactions may be caused by the stainless steel used in the electrodes of this device. Do not jump on the equipment. Do not lean on the equipment. Do not use this equipment near other products that emit electromagnetic waves.
  • Page 6 For Accurate Measurements Avoid measuring after strenuous exercise. This may cause inaccurate measurements. Please take measurements after sufficient rest. Avoid measuring after excessive food or fluid intake or when dehydrated. This may cause inaccurate measurements. For greater accuracy, avoid using directly after waking up.
  • Page 7 Scheduled Maintenance TANITA recommends that each facility conduct periodic checks of each unit. 1. Check the following at least daily:  • The unit is on a stable and level surface ie on a firm flooring, not on a thick carpet  •...
  • Page 8: Part Names & Connection Procedure

    Part Names & Connection Procedure Symbols and their Meanings Conformity with Medical Serial interface Device Directive 0123 93/42/EEC Alternating current Direct current Grip Input, Output Class II Equipment Control Unit Type BF applied part Manufacturer - Grips and platform Caution WEEE - Waste Electrical Refer to the attached and Electronic...
  • Page 9 Display and Keys Standard Athletic Male Female 5 - 99 Setting Height 90.0 - 249.9cm Enter Meanings of the LED Indicators and Keys Display Body Fat (percentage and mass) Turn ON / OFF the power *Not measured value but calculated value Display Body Muscle (percentage and mass) *Not measured value but calculated value Printout result...
  • Page 10: Power Supply

    Power Supply Turning the Main Power ON/OFF Turning the main power ON. Press the     key to turn on the power. The initial screen is displayed. Turning the main power OFF. Press the key to turn the power off. Emergency Shut Down Keep the area around the plug socket clear during operation of the equipment in case of an emergency.
  • Page 11: Settings

    Settings Press the key to change the Setting mode. The setting screen is displayed. Note •The key cannot be used when the scale is measuring weight or impedance. Setting Select the setting item from the list below. Enter numerical values and Press the key.
  • Page 12 Settings (continued) Select the Measurement Mode Select the measurement mode by pressing the    key. The measurement mode is switched Body Composition Mode in the following order when the    key is pressed: MC-780 III Max 300kg Min 2kg e=0.1kg T = -10kg Standard Athletic Female...
  • Page 13: Taking A Measurement

    Taking a Measurement Body Composition Mode Two step flow Measure body weight first Enter the preset tare value (clothes weight) and press     key Enter Turn the power on, and check that the " " mark flashes. Enter the preset tare value (clothes weight) The tare value range is 0.0 to 10.0k .
  • Page 14 Taking a Measurement (continued) Body Composition Mode Select gender Male Female Enter age and press Enter Standard Athletic Male Female 5 - 99 Setting The age range : 5 to 99 Height 90.0 - 249.9cm Enter Enter height Height and press Enter Standard Athletic...
  • Page 15: Measurement Results

    Measurement Results ( Body Composition Mode ) Output Measurement Results (Body Composition Mode) The measurement results are displayed on the LCD after measurement is completed. The results are output to the PC immediately after measurement is completed. Press the key to select the measurement display. The measurement display is switched in the following order by pressing the key.
  • Page 16 Taking a Measurement (continued) Measurement Results ( Body Composition Mode ) Body Water Body weight (k ) Body water % Body water (k ) Body water icon Visceral Fat Rating Body weight (k ) Visceral fat rating Visceral fat rating VFR icon Basal Metabolic Rate (BMR) Body weight (k )
  • Page 17: Scale Mode

    Scale Mode The " " icon is displayed when the scale mode is selected. Enter the ID number If the ID number function is set to OFF, the scale starts measuring weight immediately. Enter the ID number. The ID number range is from 0 to 9999999999999999. Press    to enter tare value (clothes weight).
  • Page 18: Weight Lock Mode

    Taking a Measurement (continued) Weight Lock Mode   " are displayed when The " " icon and " the weight lock mode is selected. Enter the preset tare value (clothes weight) Enter the preset tare value (clothes weight) The tare value range is 0.0 to 10.0k . Enter the ID number If the ID number function is set to OFF, the scale starts measuring weight immediately.
  • Page 19: General Instructions For Body Composition Measurement

    - People who are professional athletes. Target Body Fat •A target body fat % should be set by a professional only. Tanita is not responsible for setting the appropriate target body fat % for specific individuals. Attention •Posture when measuring - Stand with both feet parallel on the electrodes.
  • Page 20: Body Water And Extracellular Water

    Taking a Measurement (continued) Body Water and Extracellular Water Body water can be broadly classified into extracellular water and intracellular water. The percentage of this water accounted for by extracellular water is known as the extracellular water ratio. In medical textbooks, this is defined as: Extracellular Water (ECW): Intracellular Water (ICW) = 1:2 (i.e.
  • Page 21: Output And Storage Of Measurement Results

    •Please provide your own cable as necessary as none are included. USB cable : Type-A 4 - pin (male) - Type-B 4 - pin (male) •You must install the necessary driver onto your PC, available download from http://www.tanita.eu Data Storage Data storage of measurement results The results are saved to the SD card immedi- ately after measurement is completed.
  • Page 22 Output and Storage of Measurement Results (continued) Reading Stored Measurement Result Data Reading stored measurement result data (→P.11 Setting 60) Select the file that you want to load using the or  key and  or  key and press Enter Month and date Displaying stored data Year Date and time when the Data ID...
  • Page 23: Troubleshooting

    Troubleshooting Please check the following before requesting repair. Problem Solution •Hold the handgrips and electrodes firmly with fingers and palms. Error with •Stand barefoot on the platform for measurement. impedance •If the soles of the feet are dry, use a dropper measurement to apply about 0.5 mL of water before measurement.
  • Page 24: Specifications

    Specifications Model Number MC-780MA-N MDD: CLASS IIa Accuracy Grade NAWI: CLASS III Power Source 100 to 240V AC 18VA Electric Current Range Multi-Frequency 8 Electrode Measurement System 5kHz/50kHz/250kHz Measurement Frequency 90µA or less Measurement Current Impedance Electrode Materials Feet: Stainless steel/Handgrips: plated...
  • Page 25 Clothes Weight 0 to 10.0kg (0.1kg increments) Serial No. Up to 16 digits Gender Female/Male Input Body Type Standard/Athletic items 5 to 99 years old Height 90.0 to 249.9cm (0.1cm increments) Target Body fat % 4 to 55% (1% increments ) 16 digits Female/Male Gender...
  • Page 26 MEMO...
  • Page 28 ・SD, SDHC and SDXC Logos are trademarks or registered trademarks of SD-3C LLC in the United States, other countries or both. ・PictBridge and the PictBridge logo are trademarks of the Camera & Imaging Products Association (CIPA). <Manufacturer> <EU Representative> TANITA Corporation of America, Inc. TANITA Corporation TANITA Europe B.V. 2625 South Clearbrook Drive,...
