inbody 270 Quick Installation Manual

Your InBody 270 package comes with the following:
InBody 270
Do not cut too deep when opening up the unit box. Cutting too deep may damage the InBody unit and/or unit padding.
1
Keep the box right side up.
Slice between the flaps to open the
unit box. Do not cut too deeply or
you may damage the contents.
Unfold and take out all the padding
on top to reveal the unit.
4
Level Indicator
Leveled
Tilt the head upright and
straighten out the handles.
Check the level indicator to
see if the unit is balanced.
| Quick Installation Guide
Adapter
Power Cord
UNBOXING + ASSEMBLY
2
Lift the unit up from the box,
making sure you are holding onto
the footplate with both hands.
Keep the footplate horizontal to
the ground.
5
Not leveled
If not level, adjust the four
footplate supports until the
bubble is inside the red ring.
Rotate clockwise to lower the
height of the support or
counterclockwise to raise it.
User's Manual
3
(This may require two people)
6
www.inbody.com
Once you place the unit on the
ground, use one hand to hold the
footplate and the other hand to
push the head upright to a vertical
position until you hear a click.
InBody
Connect the adapter to the
power input port located on
the rear panel of the unit.
Connect the adapter to the
power cord. Plug the power
cord into an outlet.
