H20N
User's Manual
* Disclaimer: This device is not a medical device. It cannot determine the presence of an illness or
disease. The examination of a medical professional is required for diagnosis.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H20N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for inbody H20N

Summary of Contents for inbody H20N

  • Page 1 H20N User’s Manual * Disclaimer: This device is not a medical device. It cannot determine the presence of an illness or disease. The examination of a medical professional is required for diagnosis.
  • Page 2 InBody Test Posture Stretch out your arms. Avoid contact with your waist. Put your thumb on the round electrodes. Place your heel at the end of the heel electrodes and allow the rest of your foot to point forward.

  • Page 3: Table Of Contents

    Contents Precautions Product Components and Set-Up Instructions A. Product Components B. Installing InBody App C. Pairing InBody H20N with InBody App Weight Measurement III. InBody Test A. Precautionary Steps B. Test Posture C. Test Instructions D. Understanding InBody Outputs Troubleshooting A.

  • Page 4: Precautions

    Co., Ltd. is not liable for any incidental or consequential damages that occur. 2. Place the InBody on a flat and vibrationless floor. Placing it on an uneven floor, like a carpet or a mattress can result in incorrect measurements. For long-term storage, remove the battery pack, and place it on a flat surface. 3. Keep your InBody device away from other electronics while testing. It may cause errors. 4. After an individual with any kind of contagious disease or infection tests on the InBody, sterilize the device with a soft cloth or with ethyl alcohol wipes before use. 5. Excessively high or low temperatures, humidity, and pressure can affect the accuracy of the InBody.

  • Page 5: Product Components

    II. Product Components A. Product Components Product components: InBody H20N, User’s Manual, AA Battery (4) Hand electrodes Display screen Battery insert Dial Foot electrodes Footplate Back cover Display screen: Displays outputs on the screen. Dial: Use to power ON/OFF, input height and check results. Hand electrodes: User holds the device with hands and fingers. Foot electrodes: User stands on the device, placing the back of heels on the rear electrodes. Footplate: Measures the weight of the user.

  • Page 6: Installing Inbody App

    II. Product Components B. Installing InBody App Download and install the InBody App from the iPhone App Store or Google Play Store prior to testing. (iOS 8, or newer. Android 5.0, or newer.) Scan the QR code below. For an Android phone, turn on NFC (Read/Write) and tap the NFC mark to move to the app download page automatically. Once the download is complete, open the InBody App and register as a new user. Keep the Bluetooth ON to use the InBody H20N.

  • Page 7: Pairing Inbody H20N With Inbody App

    II. Product Components C. Pairing InBody H20N with InBody App...
  • Page 8 II. Product Components * The InBody H20N will automatically transfer data to the InBody App once syncing is complete.

  • Page 9: Weight Measurement

    0.0 is displayed on the screen. A “beepˮ will indicate when the measurement is complete. The power turns off automatically when you step off the footplate. * Zero-Point Adjustment When the device is being calibrated, a scrolling rectangle will appear on the screen. If you want to test on the InBody H20N immediately after measuring weight, turn the dial and input height. Then, hold the hand electrodes and stand with the correct test posture to take the InBody Test.

  • Page 10: Inbody Test

    IV. InBody Test A. Precautionary Steps Do not eat immediately before testing on the InBody. Test in the morning, if possible. Test after going to the bathroom. Test prior to working out. Test prior to taking a shower, bath or using a sauna. Stand for about 5 minutes prior to testing.

  • Page 11: Test Posture

    IV. InBody Test B. Test Posture Arms and legs aren’t Arms are extended Arms are too high Arms are too low touching each other Arms are bent Do not let your arms touch your stomach and make sure your arms are Hold the hand electrodes extended from your body and wear light clothes with sleeves. and extend your arms.

  • Page 12: Test Instructions

    IV. InBody Test C. Test Instructions Power ON: Press the dial to turn the power on. Open InBody App: Initiate the InBody Test through the app.
  • Page 13 IV. InBody Test Step on the InBody H20N to begin testing.
  • Page 14 IV. InBody Test Weight Measurement and InBody Test: Step on the footplate barefoot and stand as shown in the figure below. Hold the hand electrodes as previously described. After finishing the weight measurement, it will beep twice and the InBody Test will initiate. The Test runs for about 10 seconds and is finished when it rings. Once “End” appears on the screen, step down from the footplate. If a user’s palms and/or soles are dry or callused, he or she may have difficulty testing. Wipe hands and feet with an InBody Tissue for more accurate results.
  • Page 15 IV. InBody Test Check Test Results Data will automatically sync between the InBody H20N and InBody App.

  • Page 16: Understanding Inbody Outputs

    IV. InBody Test D. Understanding InBody Outputs Body fat mass and muscle mass change with diet and exercise. • Weight : Total body mass Weight is the total mass of the human body. • Percent Body Fat : Total mass of fat mass divided by total body mass A person’s body fat percentage is the total fat mass divided by the person’s weight.

  • Page 17: Troubleshooting

    V. Troubleshooting A. Error Message The InBody displays an error message on the LCD screen if a disruption occurs. Error messages caused by incorrect testing posture If the following error messages appear, check your testing posture and try again. Error messages caused by internal malfunction of the InBody H20N If the following error messages appear, please contact us at contact@inbody.com.

  • Page 18: Solving Simple Problems

    V. Troubleshooting B. Solving Simple Problems If the problem still persists, please contact us at contact@inbody.com for assistance. Q1. The power does not turn on after pressing the dial. This can happen when the batteries are dead. Replace the batteries. This can happen when the batteries are not inserted correctly. Insert the batteries so the positive (+) and the negative (-) terminals align correctly.

  • Page 19: Frequently Asked Questions (Faq)

    VI. Frequently Asked Questions (FAQ) If your question is not listed here, please contact us at contact@inbody.com for assistance. Q1. The InBody Test results vary. Why is there a difference in outcomes? A. If you are standing with incorrect posture, outcomes will vary. Make sure your hands and feet are come in contact with the electrodes properly. Maintain this posture until the Test is complete. If you have dry hands and/or feet, clean them with an InBody Tissue before testing.
  • Page 20 VI. Frequently Asked Questions (FAQ) Q5. If the user’s thighs or armpits touch, would that affect the test results? A. Yes. If the user’s thighs or armpits touch, have him or her wear a light short sleeve shirt and shorts to obtain more accurate results. Q6. How do you make the results stay on the screen longer? A. InBody Test results are shown on the LCD screen for 100 seconds. If you want to see it for a longer period of time, turn the dial.

  • Page 21: Specifications

    VII. Specifications Bioelectrical Bioelectrical Impedance(Z) : 10 Impedance measurements are taken Impedance (BIA) by using two(2) different frequencies (20kHz, 100kHz) in each of the Measurement Items five (5) segments (right arm, left arm, trunk, right leg, left leg) Electrode Method Tetrapolar 8-Point Tactile Electrode Methods Testing Method Direct Segmental Multi-frequency Bioelectrical Impedance Analysis Method, DSM-BIA type Body Composition No Empirical Estimation Calculation Method Outputs Weight, Body Fat (Percent Body Fat), (LCD Screen) Muscle (Skeletal Muscle Mass), BMI Applied Rating 100 ㎂ Current Power Consumption DC 6V(1.5V AA battery 4 EA) Display Type...
  • Page 22 • is connected. Consult the dealer or an experienced radio/TV technician for help. • * This product complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This product may not cause harmful interference, and (2) this product must accept any interference received, including interference that may cause undesired operation. ©2019 InBody Co., Ltd. All rights Reserved. Reproduction, adaptation, or translation of this manual is prohibited without prior written consent from InBody Co., Ltd under the copyright laws. This manual might have typographical errors, and its content can be changed without prior notice. InBody Co., Ltd. shall not be liable for any errors, incidental, or consequential damages that occurred by not complying with the contents of the Users̓ Manual.

  • Page 23: Product Warranty

    Date of Purchase : Place of Purchase : This product warranty gives an assurance for the InBody product as below: 1. This product undergoes a strict review process to ensure quality control 2. The warranty period of this product follows the warranty period policy of the manufacturer.
  • Page 24 TEL: +1-323-932-6503 FAX: +1-323-952-5009 Website: https://www.inbody.com E-mail: contact@inbody.com InBody HQ InBody Bldg., 625, Eonju-ro, Gangnam-gu, Seoul, 06106 KOREA TEL: +82-2-501-3939 FAX: +82-2-578-2716 Customer Center: 1899-5841 Website: https://www.inbody.com E-mail: info@inbody.com InBody JAPAN Tani Bldg., 1-28-6, Kameido, Koto-ku, Tokyo 136-0071 JAPAN TEL: +81-3-5875-5780 FAX: +81-3-5875-5781 Website: https://www.inbody.com/jp/ E-mail: inbody@inbody.co.jp InBody CHINA 904, Xing Di Plaza, No. 1698 Yishan Road, Shanghai, 201103, CHINA TEL: +86-21-64439738, 9739, 9705 FAX: +86-21-64439706 Website: https://www.inbody.com/cn/ E-mail: inbodyhp@inbodychina.com InBody INDIA 1046 a/b Level ground 1 trade center BKC bandra east Mumbai 400051, India TEL : +91 22-6223-1912 Website: http://www.inbody.com/in/ InBody EU Hessenbergweg 75A 1101CX Amsterdam-Zuidoost TEL : +31-20-2386080 Website: http://www.inbody.com/eu/ E-mail : info.eu@inbody.com InBody ASIA Unit 3A-11, Oval Damansara, No.685 Jalan Damansara, 60000 Kuala Lumpur, Malaysia TEL : +603-7732-0790 © 2019 InBody Co., Ltd. All rights reserved. BM-USA-M4-A-190129...
