- Page 1 Acura Embedded Systems Inc. Rugged Panel PC Solutions Applied Panel PC AcuPanel 12V2 / 15V2 / 17V2 / 19V2 User Manual Acura Embedded Systems Inc. www.acuraembedded.com Published May 2016...
-
Page 2: Table Of Contents
Content ontents ............Preface Knowing AcuPanel Series ................Rear Top ................Copyright ..............Rear Bottom ................Disclaimer ................Rear ..............Acknowledgements ............Mechanical Dimensions ..........Regulatory Compliance Statements ............AcuPanel12V2/12V2X ............Declaration of Conformity ..............AcuPanel15V2 ..............RoHS Compliance ..............AcuPanel17V2 .............. - Page 3 Content Chapter 3: System Setup Placing Panel Mount Hole Blocks............26 Installing the Power Adapter Bracket............. 27 Panel Mounting..................28 Chapter 4: BIOS Setup About BIOS Setup .................. When to Configure the BIOS..............30 Default Configuration................31 Entering Setup..................31 Legends....................
-
Page 4: Preface
The information in this document is subject to change without prior notice designed to provide reasonable protection against harmful interference and does not represent commitment from Acura Embedded Systems Inc. when the equipment is operated in a commercial environment. This... -
Page 5: Rohs Compliance
0.1% or 1,000ppm, and Polybrominated diphenyl Ethers (PBDE) < 0.1% or 1,000ppm. In order to meet the RoHS compliant directives, Acura Embedded Systems Inc.has established an engineering and manufacturing task force to implement the introduction of green products. The task force will ensure that we follow the standard ACURA EMBEDDED SYSTEMS INC. -
Page 6: Safety Information
Preface Installation Recommendations Safety Information Ensure you have a stable, clean working environment. Dust and dirt can get Before installing and using the device, note the following precautions: into components and cause a malfunction. Use containers to keep small ▪ Read all instructions carefully. components separated. -
Page 7: Safety Precautions
Preface Safety Precautions 11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 1. Read these safety instructions carefully. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. -
Page 8: Technical Support And Assistance
Service Contact Information 2. Maintenance: to keep the unit clean, use only approved cleaning products or clean with a dry cloth. Acura Embedded Systems Inc. 3. CompactFlash: Turn off the unit’s power before inserting or removing a CompactFlash storage card. -
Page 9: Package Contents
Preface Package Contents Before continuing, verify that the package you received is complete. Your AcuPanel12V2/12V2X/15V2/17V2/19V2 package should have all the items listed in the table. AcuPanel12V2/12V2X/15V2/17V2 Panel Mount Kit PS/2 Y Cable Item Description (AcuPanel12V2/12V2X/15V2/17V2) PS/2 Y cable Panel Mount Kit Driver CD Touch Pen Terminal block 3-pin Phoenix Contact Plug... - Page 10 Preface Your AcuPanel19V2 package should have all the items listed in the table. AcuPanel19V2 Item Description PS/2 Y cable Panel Mount Kit Panel Mount Kit Driver CD PS/2 Y Cable (AcuPanel19V2) Touch Pen Terminal block 3-pin Phoenix Contact Plug Flat Head for SSD Installation Panel Mount Hole Block Note: Package contents may vary depending on your country region, some items may be optional.
-
Page 11: Ordering Information
Preface Ordering Information The following information below provides ordering information for the AcuPanel series. Barebone Optional • AcuPanel12V2 • 12V, 60W AC/DC power adapter w/o power cord ® 12.1” SVGA LED Backlight Touch Panel PC, Intel Atom™ E3826 1.46GHz, touch screen, 2GB DDR3L, 2 x RS232/422/485, 120SSD Brightness adjustment buttons •... -
Page 12: Chapter 1: Product Introduction
Chapter 1: Product Introduction 1: P hapter roduct ntroduction AcuPanel12V2/12V2X Overview Key Features ▪4:3 12.1” SVGA Fanless LED Panel Computer (AcuPanel12V2) ▪4:3 12.1” XGA Fanless LED Panel Computer (AcuPanel12V2X) ® ▪Intel Atom™ E3826, Dual Core, Low Consumption CPU ▪Flush Panel by 5-wire Touch Screen ▪Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS ▪USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485 ▪Fieldbus port... -
Page 13: Specifications
Chapter 1: Product Introduction Specifications ▪ System memory: 2x 204-pin DDR3L SO-DIMM socket, 4GB DDR3L Panel (Default), Support up to 8GB DDR3L-1066/1333, Non-ECC and Un- AcuPanel12V2 ▪ LED Size: 12.1”, 4:3 buffered ▪ Storage Device: ▪ Resolution: SVGA 800x600 ▪ Luminance: 450cd/m ––... - Page 14 Chapter 1: Product Introduction ▪ Power adapter: Optional AC to DC power adaptor (+12V, 60W) –– 4x Digital Output (Sink type) ▪ Vibration: –– Output Voltage: 3.6V ~ 5V –– Sink current: 200 mA max. per channel –– IEC 68 2-64 (w/ HDD) ▪...
-
Page 15: Acupanel15V2
Chapter 1: Product Introduction AcuPanel15V2 Key Features ▪4:3 15” XGA Fanless LED Panel Computer ▪Intel ® Atom™ E3826, Dual Core, Low Consumption CPU ▪Flush Panel by 5-wire Touch Screen ▪Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS ▪USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485 ▪Fieldbus port ▪DDR3L 2GB/2.5”... -
Page 16: Specifications
Chapter 1: Product Introduction Specifications Panel Rear I/O ▪ LED Size: 15”, 4:3 ▪ Ethernet: 2x RJ45 ▪ Resolution: XGA 1024 x 768 ▪ 2nd display VGA port: 1x DB15 ▪ Luminance: 400cd/m ▪ Audio port: 1x Line-out ▪ Contrast ratio: 700 ▪... - Page 17 Chapter 1: Product Introduction Audio Certifications ▪HD audio codec: Realtek ALC886-GR ▪CE approval ▪Audio interface: Line-out/ Line-in (optional)/ Mic-in (optional) ▪FCC Class A Ethernet ® ▪ LAN chip: dual Intel I210AT Gigabit LAN ▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible Mechanical &...
-
Page 18: Acupanel17V2
Chapter 1: Product Introduction AcuPanel17V2 Key Features ▪4:3 17” SXGA Fanless Panel Computer ▪Intel ® Atom™ E3826, Dual Core, Low Consumption CPU ▪Flush Panel by 5-wire Touch Screen ▪Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS ▪USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485 ▪Fieldbus port ▪DDR3L 2GB/2.5”... -
Page 19: Specifications
Chapter 1: Product Introduction Specifications Panel Rear I/O ▪ LED Size: 17”, 4:3 ▪ Ethernet: 2x RJ45 ▪ Resolution: SXGA 1280x1024 ▪ 2nd display VGA port: 1x DB15 ▪ Luminance: 350cd/m ▪ Audio port: 1x Line-out ▪ Contrast ratio: 1000 ▪... - Page 20 Chapter 1: Product Introduction Audio Certifications ▪HD audio codec: Realtek ALC886-GR ▪CE approval ▪Audio interface: Line-out/ Line-in (optional)/ Mic-in (optional) ▪FCC Class A Ethernet ® ▪ LAN chip: dual Intel I210AT Gigabit LAN ▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible Mechanical &...
-
Page 21: Acupanel19V2
Chapter 1: Product Introduction AcuPanel19V2 Key Features ▪4:3 19” SXGA Fanless LED Panel Computer ▪Intel ® Atom™ E3826, Dual Core, Low Consumption CPU ▪Flush Panel by 5-wire Touch Screen ▪Dual GbE/2nd display-VGA/Line-out/PS2 KB/MS ▪USB x 3/2 x Mini-PCIe sockets/1 x CFast/2 x RS232/422/485 ▪Fieldbus port ▪DDR3L 2GB/2.5”... -
Page 22: Specifications
Chapter 1: Product Introduction Specifications Panel Rear I/O ▪ LED Size: 19”, 4:3 ▪ Ethernet: 2x RJ45 ▪ Resolution: SXGA 1280x1024 ▪ 2nd display VGA port: 1x DB15 ▪ Luminance: 350cd/m ▪ Audio port: 1x Line-out ▪ Contrast ratio: 1000 ▪... - Page 23 Chapter 1: Product Introduction Audio Certifications ▪HD audio codec: Realtek ALC886-GR ▪CE approval ▪Audio interface: Line-out/ Line-in (optional)/ Mic-in (optional) ▪FCC Class A Ethernet ▪ LAN chip: dual Intel ® I210AT Gigabit LAN ▪ Ethernet interface: 10/100/1000 Based-Tx Ethernet compatible Mechanical &...
-
Page 24: Knowing Acupanel Series
Chapter 1: Product Introduction Knowing AcuPanel Series Antenna holes for optional 3.5G/Wi-Fi The 3 external antenna holes are used to mount and connect optional Rear Top 3.5G/ Wi-Fi antennas. CFast Card Socket Used to insert a CFast card. Antenna holes Backlight on/off Decrease Brightness Power Switch Press to power-on or power-off the panel PC. -
Page 25: Rear Bottom
Chapter 1: Product Introduction Rear Bottom PS/2 KB/MS Used to connect a PS/2 keyboard or a PS/2 mouse. Line-out Used to connect a headphone or a speaker. Remote On/Off Switch Used to connect a remote to power on/off the system. LAN 1 and LAN 2 PS/2 KB/MS Line-out USB 3.0 COM 2... -
Page 26: Rear
Chapter 1: Product Introduction Rear VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Hole VESA Mounting Holes These are the mounting holes for VESA mount (100x100mm) -
Page 27: Mechanical Dimensions
Chapter 1: Product Introduction Mechanical Dimensions AcuPanel12V2/12V2X 304.50 5 mm 301.73 56.90 67.22 67.23 34.86 100.25 100.25 CUT OUT SIZE T=5MM (MAX) 317.00 65.89 108.68 100.00 8.50 8.80... -
Page 28: Acupanel15V2
Chapter 1: Product Introduction AcuPanel15V2 371.00 366.32 160.00 89.26 67.22 67.23 7.41 63.20 19.20 CUT OUT SIZE T=5MM (MAX) 384.37 56.2 142.27 10.40... -
Page 29: Acupanel17V2
Chapter 1: Product Introduction AcuPanel17V2 399.00 12mm 392.40 134.45 67.22 CUT OUT SIZE T=12MM (MAX) 65.90 410.42 28. 90 270.00 6.00 100.00... -
Page 30: Acupanel19V2
Chapter 1: Product Introduction AcuPanel19V2 436.00 431.34 270.36 121.32 67.22 67.23 41.49 104.50 97.35 104.50 457.64 CUT OUT SIZE T=3MM (MAX) 61.25 24.25 179.30 100.00 8.10 16.15 10.15... -
Page 31: Chapter 2: Connectors
Chapter 2: Connectors 2: Connectors hapter Connector Pin Definitions External I/O Interfaces Line-out Connector Remote Power On/Off Switch Connector type: 1x 3.5mm TRS Connector type: 2-pin switch Connector location: CN3 Connector location: JP10 Definition Definition Definition LOUT_R PWRBT LOUT_L... -
Page 32: Lan1 Port
Chapter 2: Connectors LAN1 Port LAN2 Port Support Wake on LAN (WOL) Connector type: RJ45 port with LEDs Connector type: RJ45 port with LEDs Connector location: LAN2 Connector location: LAN1 Status Status Flashing Yellow Data activity Flashing Yellow Data activity LINK LINK No activity... -
Page 33: Dual Usb 2.0 Port
Chapter 2: Connectors Dual USB 2.0 Port Single USB 3.0 Port Connector type: USB 2.0 ports, Type Connector type: USB 3.0 port, Type A Connector location: USB1 A Connector location: CN5 Definition Definition Definition Definition VCC5 USB 2N VCC5 USB 0N USB 2P USB 0P VCC5... -
Page 34: Com1 Port
Chapter 2: Connectors COM1 Port COM2 Port Connector type: DB-9 port, 9-pin D- Connector type: DB-9 port, 9-pin D- Sub Connector location: CN10 Sub Connector location: CN12 RS232 RS422 RS485 RS232 RS422 RS485 COM1_TXD- COM2_TXD- COM1_DCD COM1_TXD- COM2_DCD COM2_TXD- COM1_RXD- COM2_RXD- COM1_TXD+ COM2_TXD+... -
Page 35: Vga Port
Chapter 2: Connectors VGA Port 12V - 30V DC Power Input Connector type: DB-15 port, 15-pin D-Sub Connector type: Phoenix Contact 1x3 3-pin terminal Connector location: VGA1 block Connector location: CN16 15 11 Definition Definition Definition Green Blue DDC Data HSYNC VSYNC DDC Clock... -
Page 36: Cfast Card Slot
Chapter 2: Connectors CFast Card Slot Reset Button Connector type: Standard CFast connector Connector location: SW3 Connector location: J14 Definition Reset S1 S7 PC1 PC17 Reset Definition Definition SATA_TXP2 SATA_TXN2 SATA_RXN2 SATA_RXP2 CFAST_CDI CFAST_LED1_C CFAST_LED2_C PC10 PC11 PC12 PC13 VCC3 PC14 VCC3 PC15... -
Page 37: Chapter 3: System Setup
Chapter 3: System Setup 3: S hapter ystem etup 1. Locate the panel mount openings on the chassis. Placing Panel Mount Hole Blocks The APPC series comes with panel mount hole blocks to cover the panel mount openings on the chassis to prevent dust invasion. You can also choose to cover the panel mount holes when VESA mount is used. -
Page 38: Installing The Power Adapter Bracket
Chapter 3: System Setup 2. Insert the hole block into the opening until it is pushed in completely. -
Page 39: Panel Mounting
Chapter 3: System Setup 371.00 Panel Mounting 1. Select a place on the panel where you will mount the Panel PC. 2. Cut out a shape on the panel that corresponds to the Panel PC’s rear dimensions. The thickness of the panel (e.g. steel board, plank, acrylic board, wall, etc.) where you will mount the Panel PC must not exceed 5mm for AcuPanel12V2/12V2X/15V2, 12mm for AcuPanel17V2, and 3mm for AcuPanel19V2. - Page 40 Chapter 3: System Setup 436.00 3. Slide the Panel PC through the hole until it is properly fitted against the panel. 4. Position the mounting clamps along the rear edges of the Panel PC. The first and second clamps must be positioned and secured diagonally prior to mounting the rest of the clamps.
-
Page 41: Chapter 4: Bios Setup
Chapter 4: BIOS Setup 4: BIOS Setup hapter This chapter describes how to use the BIOS setup program for the The settings made in the setup program affect how the computer performs. AcuPanel Series. The BIOS screens provided in this chapter are for It is important, therefore, first to try to understand all the setup options, and reference only and may change if the BIOS is updated in the future. -
Page 42: Default Configuration
Chapter 4: BIOS Setup Default Configuration Legends Most of the configuration settings are either predefined according to the Function Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. Moves the highlight left or right to select a menu. There are a few settings that you may need to change depending on your system configuration. -
Page 43: Bios Setup Utility
Chapter 4: BIOS Setup System Date BIOS Setup Utility The date format is <day>, <month>, <date>, <year>. Day displays a Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on the day, from Monday to Sunday. Month displays the month, from January to December. -
Page 44: Advanced
Chapter 4: BIOS Setup Advanced ACPI Settings This section is used to configure ACPI Settings. The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. while others, if enabled, will improve the performance of your system or Main Advanced... - Page 45 Chapter 4: BIOS Setup ACPI Sleep State IT8786E Super IO Configuration This section is used to configure the serial ports. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Main Advanced Chipset...
- Page 46 Chapter 4: BIOS Setup Serial Port 1 Configuration Serial Port 2 Configuration This section is used to configure serial port 1. This section is used to configure serial port 2. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
- Page 47 Chapter 4: BIOS Setup Hardware Monitor VCore Detects and displays the Vcore CPU voltage. This section is used to monitor hardware status such as temperature, fan speed and voltages. VCC12 Detects and displays 12V voltage. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Advanced VCC5 Pc Health Status...
- Page 48 Chapter 4: BIOS Setup CPU Configuration Execute Disable Bit When this field is set to Disabled, it will force the XD feature flag to always This section is used to configure the CPU. return to 0. XD can prevent certain classes of malicious buffer overflow Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
- Page 49 Chapter 4: BIOS Setup Socket 0 CPU Information PPM Configuration Display information on the CPU installed on socket 0. This section is used to configure the Processor Power Management (PPM) configuration. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Advanced Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
- Page 50 Chapter 4: BIOS Setup IDE Configuration SATA Mode Configures the SATA as IDE or AHCI mode. This section is used to configure the SATA drives. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. This option configures the Serial ATA drives as Parallel ATA Advanced physical storage device.
- Page 51 Chapter 4: BIOS Setup USB Configuration Troubleshooting: When installing Windows 7 from USB, This section is used to configure the USB. USB 3.0 will not be supported. Please disable XHCI and enable EHCI to allow USB installation of Windows 7. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
-
Page 52: Chipset
Chapter 4: BIOS Setup Chipset Backlight Dimming Reverse The available options are PWM & Analog Dimming Reverse and Normal. This section gives you functions to configure the system based on the specific features of the chipset. The chipset manages bus speeds and Backlight Dimming Control By access to system memory resources. - Page 53 Chapter 4: BIOS Setup South Bridge PCH Azalia Configuration Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Chipset Chipset ►Azalia HD Audio Audio Configuration Control Detection of the Azalia Azalia HD Audio Options ►...
- Page 54 Chapter 4: BIOS Setup USB Configuration PCI Express Configuration Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Chipset Chipset USB Configuration PCI Express Configuration Control the USB EHCI (USB 2.0) Enable or Disable the PCI functions.
-
Page 55: Security
Chapter 4: BIOS Setup Security Boot This section is used to configure the boot features. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Main Advanced Chipset Security Boot Save &... - Page 56 Chapter 4: BIOS Setup Network Hard Drive BBS Priorities Controls the execution of UEFI and legacy PXE OpROM. Sets the order of the legacy devices in this group. Onboard LAN PXE Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Options to disable onboard LAN PXE ROM or enable it for LAN1 or LAN2 .
-
Page 57: Save & Exit
Chapter 4: BIOS Setup Save & Exit Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc. Main Advanced Chipset Security Boot Save & Exit Save Changes and Reset Reset the system after saving Discard Changes and Reset the changes. Restore Defaults →←: Select Screen ↑↓: Select Item Enter: Select +/-: Change Opt. -
Page 58: Appendix A: Power Consumption
Appendix A: Power Consumption A: P ppendix ower onsumption AcuPanel19V2 Power Consumption Management Purpose +12V +24V +30V The purpose of the power consumption test is to verify the power Full-Loading Mode 1.99A 1.04A 0.86A dissipation of the system and the load of the power supply. Total 23.88W 24.96W... - Page 59 +12V +24V +30V Full-Loading Mode 1.19A 0.63A 0.52A Contact Information Total 14.28W 15.12W 15.6W Standby Mode 0.1A 0.1A 0.1A Acura Embedded Systems Inc. Total 1.2W 1.2W 1.2W AcuPanel12V2 +12V +24V +30V Full-Loading Mode 1.46A 0.66A 0.56A Total 17.52W 15.84W 16.8W Standby Mode 0.1A...
