Summary of Contents for Acura Embedded Systems RoughNeck-15

  • Page 1 RoughNeck-15 Rig Floor Computer AP15HBCD-XX User Guide Published: November 2018 Version 8.5...
  • Page 2: Copyright

    All Rights Reserved – Printed in Acura Embedded Systems Inc. Disclaimer Acura Embedded Systems Inc shall not be liable for technical or editorial errors or omissions contained here; nor for incidental or consequential damages resulting from using this material, or the performance or use of this product.
  • Page 3: Safety Instructions

    RoughNeck-15 AP15HBCD-XX Safety Instructions 1. Please read these safety instructions carefully. 2. Please keep this User Guide for later reference. 3. Please disconnect this equipment from connecter before cleaning. Don’t use liquid or prayed detergent for cleaning. Use moisture sheet or cloth for cleaning.
  • Page 4: Table Of Contents

    Specification ....................................6 Technical Specifications ................................9 Physical Dimensions ................................... 11 CHAPTER 2 System Setup ....................................12 Exploring the RoughNeck-15 ..............................12 Installation Procedures ................................14 Connecting the Power Cord ..............................14 CHAPTER 3 Using the Panel PC ..................................15 USB port .....................................
  • Page 5: General Information

    RoughNeck-15 AP15HBCD-XX Chapter 1 General Information Introduction AP15HBCD is an embedded Intel® Core-I5 processor-based Rig Floor Computer PC with a high bright 15” LCD LED backlit, low power display. The powerful Intel® i5 chipsets bring the most dynamic applications to life without sacrifices to any industrial reliability. Delivering a variety of connectivity features, built-in USB and robust capacity of 2.5”...
  • Page 6: Specification

    RoughNeck-15 AP15HBCD-XX Specification The RoughNeck-15 is a flexible, multi-functional rig floor computer with following specifications that can be applied in diverse operational environments and implemented in multi-faceted applications.
  • Page 7 RoughNeck-15 AP15HBCD-XX...
  • Page 8 RoughNeck-15 AP15HBCD-XX...
  • Page 9: Technical Specifications

    RoughNeck-15 AP15HBCD-XX Technical Specifications Processor Processor Type 6th generation Intel Core i5 processor Processor Cores Processor Cache 3MB Smart Cache Storage & Memory 1 x DDR4 - 2133MT/s up to 16GB Hard Disk Drive Capacity 120GB SSD Display & Touch screen Screen Size 15"...
  • Page 10 RoughNeck-15 AP15HBCD-XX Software Pre-loaded Operating System Windows 7/10 or Linux Operating System Language English Power Power Input Voltage DC 9-36V Power Adapter AC to DC 100-240 VAC (external optional) Power Consumption 60W max Power Management APM / ACPI 2.0 Power Button...
  • Page 11: Physical Dimensions

    RoughNeck-15 AP15HBCD-XX Physical Dimensions...
  • Page 12: System Setup

    RoughNeck-15 AP15HBCD-XX Chapter 2 System Setup Exploring the RoughNeck-15 Before setting up the panel PC, get familiar with the locations and purposes of controls, drives, connectors and ports, which are illustrated in the figures below. 1 - 3 Power From...
  • Page 13 RoughNeck-15 AP15HBCD-XX POWER...
  • Page 14: Installation Procedures

    RoughNeck-15 AP15HBCD-XX Installation Procedures AP15HBCD is designed and pre-configured for easy setup and use. This section describes the installation steps you should follow to get the system running as quickly as possible. Connecting the Power Cord 1. Connect the DC Extension cable plug (4pin female) to the computer’s Power Supply Connector.
  • Page 15: Using The Panel Pc

    RoughNeck-15 AP15HBCD-XX Chapter 3 Using the Panel PC AP15HBCD is designed and pre-configured for easy setup and use. This chapter describes the installation steps you should follow to get the system up and running as quickly as possible. USB port Connect a USB accessory like a mouse, keyboard, or USB drive to port 1-3 (10pin female connector) through USB female adapter –...
  • Page 16: Lan Ports

    RoughNeck-15 AP15HBCD-XX 4. Refer to the manual(s) which accompanied any AUX device(s) for instructions on configuring the operating environment to recognize the device(s). 5. Run the BIOS setup program and configure the jumper settings to change the mode of the AUX ports.
  • Page 17: Touch Screen

    RoughNeck-15 AP15HBCD-XX Touch Screen AP15HBCD is designed using Color Active Matrix LCD technology with a high-quality touch sensitive surface. The touch screen is a display that can detect the presence and location of a touch within the display area by a finger, hand or other passive objects such as a stylus. It enables one to interact with what is displayed directly on the screen, rather than indirectly with a mouse.
  • Page 18: System Booting And Bios Setup

    RoughNeck-15 AP15HBCD-XX Chapter 4 System Booting and BIOS Setup System Booting Setup Selection (Press “F7”) To access the System Booting Setup Selection and to select boot device, complete the following steps: 1. Turn ON the system 2. Press “F7” on the keyboard to enter the System Booting program (see figure below) BIOS Setup The BIOS Setup utility reports system information and can be used to configure the server BIOS settings.
  • Page 19: Standard Cmos Features

    RoughNeck-15 AP15HBCD-XX Standard CMOS Features The Standard CMOS Configuration provides all of the general BIOS information. Advanced BIOS Features The BIOS Advanced screens provide detailed configuration information for the CPU, memory, Super IO, USB, and other system information.
  • Page 20: Chipset Features

    RoughNeck-15 AP15HBCD-XX Chipset Features The BIOS Chipset screens enable you to set the chipset parameters as described in the figure below. Boot Features The BIOS Boot screens enable you to configure the boot configuration and boot device priority.
  • Page 21: Security Management Setup

    RoughNeck-15 AP15HBCD-XX Security Management Setup The BIOS Security screen enables you to create, change, or disable Administrator Password or User Password Save & Exit Setup The BIOS Exit options enable you to save changes and exit, discard changes and exit, and discard...
  • Page 22: Warnings

    RoughNeck-15 AP15HBCD-XX WARNINGS THIS EQUIPMENT IS SUITABLE FOR USE IN CLASS1, DIVISION 2, GROUPS (AS APPLICABLE) OR NON- HAZARDOUS LOCATIONS ONLY. WARNING - EXPLOSION HAZARD - SUBSTITUTION OF COMPONENTS MAY IMPAIR SUITABILITY FOR CLASS 1, DIVISION 2. WARNING - EXPLOSION HAZARD - DO NOT REPLACE UNLESS POWER HAS BEEN SWITCHED OFF OR THE AREA IS KNOWN TO BE NON-HAZARDOUS.
  • Page 23: Appendix

    RoughNeck-15 AP15HBCD-XX Appendix Amphenol Military Connector PT02E – 12 – 4P (4PIN Male) PIN Connection Ground PT02E – 12 – 8S (8PIN female) Pin Connection PT02E – 12 – 10S (10pin female) Pin Connection VBUS...
  • Page 24 With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble-free and customer-friendly service. A special customer service unit has been set up specifically to cater to our esteemed customers' needs. Technical Support: For technical support contact your Salesperson support@acuraembedded.com...
