- Page 1 PowerBrick™5.0 User’s Manual Edition 2.0 3 Generation Intel® i7 Industrial Computer Acura Embedded Systems Inc.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ...................... Specification ....................System ......................Connector Specification .................. VGA Connector .................... GPIO Connector ..................... COM Port Connector ..................2 .4 Power Input Connector ................. ATX 6PIN Connector (POWER OUT) ............Ignition Power Management................GPIO & Delay Time Setting................GPIO&... -
Page 3: Introduction
INTRODUCTION Specification System Intel Gen 3 Core i7-3217UE 1.7GHz Memory 1 x DDR3 1066/1333/1600 MHz SO-DIMM up to 8 GB Chipset QM77 Intel I210-AT Gb/s Ethernet Controllers Onboard LAN Chipset Support PXE and WOL Audio Realtek ALC662 HD Codec onboard Watchdog Watchdog Timer Support, Offer 1 –... - Page 4 Graphics Intel® HD Graphics 4000 DirectX Video Acceleration (DXVA) for Accelerating Video Graphics Processing - Full AVC/VC1/MPEG2 HW Decode Supports DirectX 11/10.1/10/9 and OpenGL 3.0 Resolution Up to 1920 x 1200 Qualification Certifications CE, FCC Class A, E-mark 4 x RS-232 (COM1,2 with RS-422/485, RS-485 Support Auto Direction Serial Port Control)
-
Page 5: System
1.2 System... -
Page 6: Connector Specification
CONNECTOR SPECIFICATION VGA Connector Signal Signal GREEN BLUE CER_DET DAC_SDA HSYNC VSYNC DAC_SCL GPIO Connector Signal Signal GPIO Pin GPI0 GPI1 Definition GPI2 GPI3 GPO0 GPO1 GPO2 GPO3... -
Page 7: Com Port Connector
COM Port Connector (COM) Connector pin Signal Signal COM 1,2,3,4 COM1,2,3,4_DCD COM1,2,3,4_RXD (COM1,2_RS- (Com1,2_RS- 485_TXD-/RXD-) 485_TXD+/RXD+) COM_TXD COM_DTR COM_DSR COM_RTS COM_CTS COM_RI# Power Input Connector PWRIN1 Connector definition Signal VIN (9-32V) IGNITION Power Brick 5.0 Power Wiring Diagram... -
Page 8: Atx 6Pin Connector (Power Out)
ATX 6PIN Connector (POWER OUT) Connector PWROUT1 Connector pin Signal Signal location definition +12V +12V EXT_DI1 EXT_DI2 IGNITION POWER MANAGEMENT Startup/shutdown conditions from the IGNITION signal: • IGNITION startup signal must be valid during 3 sec. (anti noise protection). • IGNITION shutdown – IGNITION signal must be inactive during 3 Sec, then PIC controller initiate Power Button signal (OS must be set to shutdown from the Power Button). - Page 9 • Ignition On/Off status detectable by SW • If the ignition is off and the system is still on after 3 Sec, PowerBrick 5.0 will shut down automatically. • If the ignition is turned on again and the power-off delay is in progress, PowerBrick 5.0 will cancel the delay function and will continue to operate normally.
-
Page 10: Gpio & Delay Time Setting
GPIO & Delay Time Setting GPIO and Ignition Control Register The General Purpose I/O is an interface available on some devices. These can read digital signals from other parts of a circuit, or output to control other devices. At GPIO control register, the GPI is use to receive data, the GPO is set data to send. - Page 11 GPIO5 Output Data Register – Index A1h Name Default Description GPIO57_DATA GPIO57 output data in output mode. GPIO56_DATA GPIO56 output data in output mode. GPIO55_DATA GPIO55 output data in output mode. GPIO54_DATA GPIO54 output data in output mode. GPIO53_DATA GPIO53 output data in output mode. GPIO52_DATA GPIO52 output data in output mode.
-
Page 12: Wdt Setting
I/O port: I/O port: 0xA35 (base address) for Control Register (Read 0xF2h bit 3) 0xA36 (base address) for Control Data Value Ignition Status 0 = Ignition off 1 = Ignition on Debug Command Line O A35 F2 I A36 // Check Bit 3 Status 4.2 WDT Setting I/O port: A10 (base address) + 05h and... - Page 13 Watchdog Timer Configuration Register 1- base address +05h Name Default Description Reserved Reserved WDTMOUT If watchdog timeout event occurs, this bit will be set _STS to 1. Write a 1 to this bit will clear it to 0. WD_EN If this bit is set to 1, the counting of watchdog time is enabled.
-
Page 14: Bios Setting
5.0 BIOS Setting Super IO Configuration Select Serial Port Mode... -
Page 15: Technical Support
With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble-free and customer-friendly service. A special customer service unit has been set up specifically to cater to our esteemed customers' needs. Technical Support: For technical support contact your Salesperson support@acuraembedded.com...
