Page 1: Table Of Contents
Service Contact Information Chapter 1: Product Introduction ..............Overview .............. Key Features AEAD 104 ..........Hardware Specifications ..........Knowing Your AEAD 104 ..........Mechanical Dimensions Chapter 2: BIOS Setup ............About BIOS Setup Quick Manual ......... When to Configure the BIOS ...........
Page 2: Acura Embedded Systems Inc
Hardware Specifications Acknowledgements CPU Support AEAD 104 is a trademark of Acura Embedded Systems Inc. All other product names ▪ mentioned herein are registered trademarks of their respective owners. On-board Intel® Atom™ Dual Core processor D2550, 1.86 GHz, 1M L2 cache ▪...
Page 3: Knowing Your Aead 104
0.5Grms @5~500 Hz according to IEC68-2-6 Certifications ▪ CE approval ▪ FCC Class A 9~36 DC 9~36V DC Input Knowing Your AEAD 104 Front Panel Used to plug a DC power cord. DVI-I Used to connect a digital LCD panel. HDMI Used to connect a high-definition display.
Page 4: Mechanical Dimensions
Chapter 2: BIOS Setup Mechanical Dimensions This chapter describes how to use the BIOS setup program for the AEAD104. The BIOS screens provided in this chapter are for reference only and may change if the BIOS is updated in the future. To check for the latest updates and revisions, visit www.acuraembedded.com.
Page 5: Default Configuration
Scroll Bar Default Configuration When a scroll bar appears to the right of the setup screen, it indicates that there are Most of the configuration settings are either predefined according to the Load Optimal more available fields not shown on the screen. Use the up and down arrow keys to Defaults settings which are stored in the BIOS or are automatically detected and scroll through all the available fields.
Page 6: Advanced
from 1 to 31. Year displays the year, from 1999 to 2099. System Time The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23.
Page 7 This field is used to enable or disable execute disable bit. When this field is set to Disabled, it will force the XD feature flag to always return to 0. XD can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat Enterprise 3 Update 3).
Page 8 Configures the SATA as IDE or AHCI mode. • • AHCI This option configures the Serial ATA drives as Parallel ATA physical storage device. This option configures the Serial ATA drives to use AHCI (Advanced Host Controller Interface). AHCI allows the storage driver to enable the advanced Serial ATA features which will increase storage performance.
Page 9 Onboard Serial Port Max Baud Rate This field configures the maximum baud rate of the serial port 0, the options are 115200 bps and 921600 bps. This field configures the maximum baud rate of the serial port 1, the options are 115200 bps and 921600 bps.
Page 10: Chipset
PPM Configuration Setting incorrect field values may cause the system to This section is used to configure Intel SpeedStep. malfunction. Host Bridge Displays the memory information Chipset This section is used to configure the system based on the specific features of the chipset.
Page 11 Due to Intel® VBIOS wrong address issue in HDMI mode, thereis no “HDMI” display output option in the BIOS menu. Please refer to the following table for the display reference when a HDMI monitor is connected to AEAD 104. Fixed Graphics Memory Size Azalia Controller...
Page 12: Boot
SMBus Controller Boot option #1 This section is used to configure SMBus. High Precision Timer This section is used to configure High Precision Event Timer. Restore AC Power Loss This section is used to configure Restore AC Power Loss. This field is used to adjust the boot sequence of the system. Boot Option #1 is the first boot device that the system will boot from, next will be #2 and so forth.
Page 13: Save & Exit
Administrator Password Confirm by selecting Yes to discard all changes made and restore the previously saved Sets the administrator’s password settings. Restore Defaults User Password To restore the BIOS to default settings, select this field then press <Enter>. A Sets the user’s password. dialog box will appear.
