Dimensions and weight
Dimensions
Matrox MXO2 Mini 6 1/2" x 4 5/16" x 1 1/2"
(166mm x 110mm x 40mm)
Matrox MXO2 LE 9 1/4" x 9 1/2" x 2"
(235mm x 241mm x 51mm)
Matrox MXO2 13" x 9½" x 2"
(330mm x 241mm x 51mm)
Matrox MXO2 Rack 21" x 18" x 8.25"
(533mm x 457mm x 210mm)
Broadcast-quality HD/SD video and audio input/output
Video I/O
Weight
The Matrox MXO2 products provide a full range of professional video inputs
and outputs.
0.6 lbs
(280g)
MXO2 LE, MXO2 and MXO2 Rack provide RS-422 machine control for frame-
accurate capture and print-to tape with Adobe Premiere Pro.
2 3/4 lbs
(1245g)
Matrox MXO2 LE, MXO2 and MXO2 Rack provide SD analog black burst
(bi-level) or HD tri-level sync genlock. They can genlock to any type of video
3 1/2 lbs
(1600g) input or to house sync. Timing offset controls can be used to align your video
output relative to your external genlock source to compensate for cable
15 lbs
delays within your facility. On MXO2 Rack, loop through is supported.
(7000g)
Matrox MXO2 LE, MXO2 and MXO2 Rack support up to five user-selectable
simultaneous video outputs – HD and/or SD on HDMI, SDI, and analog.
Video Inputs
Component HD/SD
(YUV or RGB)
SDI HD/SD
Y/C
Composite
HDMI (YUV or RGB)
Video Outputs
Component HD/SD
(YUV or RGB)
SDI HD/SD
Y/C
Composite
HDMI (YUV or RGB)
inputs and outputs
MXO2 Mini MXO2 LE MXO2
Yes Yes Yes
No Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
No Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Matrox MXO2 Family for PC Product Guide
Video
MXO2 Rack
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
5
