Matrox MXO2 Rack Connections
XLR - 8 channels of
balanced audio
Power connector
AES/EBU – 4 channels via 2
RS422
Host interface
HDMI – HD/SD with up to 8
channels of embedded audio
Analog component
BNC connectors
Y/C Composite
AES/EBU – 4 channels
via 2 BNC connectors
Y/C
Composite
HDMI – HD with up to 8
XLR - 4 channels of
channels of embedded
balanced audio
connections
Matrox Mxo2 rack
Two SDI – HD/SD with up to 8
channels of embedded audio
per output
HD/SD
Analog component
Genlock – bi-level and
HD/SD
tri-level genlock via a
single BNC connector
with loop through
SDI – HD/SD with
up to 8 channels of
embedded audio
