MartinLogan Abyss ESL Series Brochure & Specs

Stereo/home theater subwoofer

Advertisement

Quick Links

D
i
epth
STEREO/HOME THEATER SUBWOOFER
DEEp, pOWERFUl, AnD DETAilED
Depth i deploys the full array of MartinLogan's subwoofer technologies
to achieve deep, rich, satisfying bass while preserving electrostatic-like
accuracy and detail. Its TriLinear™ BalancedForce™ alignment, advanced
low-distortion switching amplifier, and sophisticated triple-servo control
systems extract the very best possible performance from Depth i's high-
resolution triple 8-inch aluminum-cone woofers. The result? Levels of purity
and accuracy seldom found in subwoofers at twice the price.
Frequency Response
Low Pass Filter Frequencies
High Pass Filter Frequencies
25Hz Level Control
Low Frequency Drivers
Dimensions (HxWxD)
The Loudspeaker Technology Company
www.martinlogan.com
20–120 Hz ± 3dB
30, 35, 45, 55, 65, 80Hz, CLX (optional)
40, 70Hz, Bypass
±10dB
Three 8" (20.3) aluminum cone
Amplifier
350W (900W peak)
Inputs
Left/Right RCA Line Level, RCA LFE,
Speaker Level
Outputs
RCA Sub Out, RCA Right/Left
Weight
70 lbs. (47.7kg)
17 .9" x 17 .1" x 16.5" (45.4 x 43.5 x 41.8cm)
Application:
Home theater and stereo subwoofer
ideal for large and medium rooms.
Packing all of Descent i's innovative
technology into a cabinet 40%
smaller, Depth i delivers powerful
bass with electrostatic-like detail.
Key Features:
• Advanced Triple Servo Control
• BalancedForce™ driver alignment
• Ultra efficient 350-watt amplifier
• 3 low-distortion 8-inch aluminum
cone woofers
• Top mounted controls
• 25Hz level control
• Unique crossover and level settings
for simultaneous 2-channel and LFE
connections
• Custom ETC™ spikes
FiniSH OpTiOnS
E S L
S E R I E S
Black Ash
Maple
Visit configurator.martinlogan.com to
explore the full range of finish options.
©2009 MartinLogan, Ltd. All rights reserved.
natural
Dark
Cherry
Cherry
Birdseye
Rotary Cut
Maple
Bubinga
