MartinLogan Dynamo 500 Brochure

D 500
ynamo
™
STEREO/HOME THEATER SUBWOOFER
AFFORdABlE lOW-FREqUEncy AccURAcy
No other subwoofer offers Dynamo 500's combination of bass extension,
power, and detail at such an affordable price. Perfect for either home theater
or stereo applications, the Dynamo 500 is solidly built with high-density
materials to minimize cabinet resonance and provide a foundation for
the high-output 10-inch woofer and high-current 120-watt, 360-watt peak
amplifier. Additionally, dual rear-mounted low-turbulence ports maximize
bass output while minimizing port induced distortions.
Whether you are looking for high performance bass to enhance your music
experience or take your home theater system to the next level, a new Dynamo
family subwoofer should be at the top of your list.
Frequency Response
Low Pass Filter Frequencies
Low Frequency Driver
Dimensions (HxWxD)
The Great American Speaker Company
www.martinlogan.com
29–200 Hz ± 3dB
50–200Hz
10" (25.4) polypropylene cone; ported
Amplifier 120 watts rms (360 watts peak)
Inputs Left & Right/LFE RCA
Weight 28.5 lbs. (12.9kg)
14.69" x 13" x 15.27"
(37.3 x 33 x 38cm)
Application:
Home theater and stereo subwoofer
ideal for medium and small rooms.
Every element of the compact and
powerful Dynamo 500 is meticulously
designed to deliver a staggering
low-frequency performance at an
extremely affordable price.
Key Features:
• Ultra efficient low-distortion
120-watt amplifier with 360-watt
peak output
• Low-distortion 10-inch polypropylene
cone woofer
• Dual low-turbulence ports for
extreme bass output
• High-density cabinet construction
• Connects via Stereo Left/Right
Inputs or Home Theater LFE Input
FiniSH OpTiOnS
D E S I G N
S E R I E S
Black Ash
©2009 MartinLogan, Ltd. All rights reserved.
