MartinLogan Voyage In-Wall Stereo/Home Theater Front/Center/Surround Brochure & Specs

T
ickeT
™
IN-WALL STEREO/HOME THEATER FRONT/CENTER/SURROUND
COMpACT, AFFORDAbLE, HIgH-pERFORMANCE IN-WALL SpEAKER
Significantly smaller than the Passage, the elegant, affordable Ticket is
nonetheless a very strong performer. Its dual long-throw, high-resolution
woofers, integrated dome tweeter, and advanced Vojtko™ crossover deliver
rich, clear sound and superb stereo imaging. Ticket also features paintable
end caps and a selection of grille colors for perfect matching with any
décor. Its quick and easy, yet very secure, installation system is the same
used in Voyage and Passage.
Frequency Response
Crossover Frequency
High Frequency Driver
Mid/Low Frequency Drivers
Power Handling
Dimensions (HxWxD)
Projection From Wall Surface
Required Wall Opening
The Loudspeaker Technology Company
www.martinlogan.com
75–20,000 Hz ± 3dB
Sensitivity 88 dB/2.83 volts/meter
Impedance 8 Ohms
2900 Hz
1" (2.54cm) neodymium soft dome
Two 4" (10.2cm) aluminum cone
150 watts
Weight 5 lbs. (2.3kg)
15.7" x 7.5" x 4.69" (39.8 x 18.4 x 11.9cm)
1.125" (2.9cm)
14.25" x 5.875" (36.2 x 14.9cm)
Application:
Home theater front/center/surround
and stereo in-wall loudspeaker for
small rooms.
Although compact and affordable,
Ticket is an excellent performer,
boasting sound quality more akin
to what you would hear from our
floor standing speakers than from
a conventional in-wall.
Key Features:
• High-resolution dome tweeter
• Dual 4-inch low-distortion alumi-
num cone woofers
• Precision Vojtko™ crossover
• Rigid aluminum chassis
• Quick, no-hassle installation
• Paintable end caps
• Fully paintable option
FINISH OpTIONS
C U S T O M
I N S TA L L
black
Cloth
paintable
White Metal
©2009 MartinLogan, Ltd. All rights reserved.
Silver White
Cloth Cloth
