- Page 1 Model SA-14 User Guide Super Audio CD Player...
-
Page 2: Laser Safety
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Safety Instructions
This product was designed and manufactured to meet strict quality and safety standards. There are, however, some in- stallation and operation precautions which you should be par- ticularly aware of. 1. Read Instructions — All the safety and operating instruc- tions should be read before the appliance is operated. -
Page 4: Note To Catv System Installer
EXAMPLE OF ANTENNA GROUNDING ACCORDING TO NATIONAL ELECTRICAL CODE INSTRUCYIONS CONTAINED IN ARTICLE 810 -"RADIO AND TELEVISION EQUIPMENT" NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV (Cable-TV) system installer's attention to Article 820-40 of the NEC, which provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. -
Page 5: Installation
INTRODUCTION Thank you for selecting the Marantz SA-14 Super Audio CD Player for your A / V system. This Compact Disc Player incorporates a number of features designed to enhance the listening of your favorite audio sources. Please read these operating instructions carefully. We recommend that you read the entire user guide before you attempt to connect or operate the player. -
Page 6: Compact Discs
If such a disc is played on the CD player, impossibility of taking out the disc or other malfunction may result. - Page 7 CONNECTIONS NOTE For protection of the components and the speak- ers, be sure to turn off the power before making connections. Unbalanced connectioncords (included) Rear Panel RIGHT ITT CANNON CONNECTION: Optical fiber cable (commercially available) Pre-main amplifier, etc. SELECTION PHONO ANALOG LEFT OUTPUTS...
-
Page 8: Controls, Connections And Indicators
CONTROLS, CONNECTIONS AND INDICATORS Please read the following instructions referring to the illustration on page Some of the operations described in this user’s guide can only be operated from the remote control unit. In the description of controls, the names of the buttons which are available on both the main unit and the remote control unit are enclosed in , and the names of the buttons which are available only on the remote control unit are enclosed in... -
Page 9: Using The Remote Control Unit
G G G G G REMOTE switch When using this unit independently, set this switch to INTERNAL. When using this unit in a system incorporating a Marantz tuner or timer equipped with a remote sensor, set the switch to EXTERNAL. NOTE Always set this switch to INTERNAL unless the unit is connected with other MARANTZ equipment through a system connection. - Page 10 REMOTE CONTROL UNIT RC-14SA When the power to the SACD player is ON and a disc is loaded on the disc tray, the remote control unit (RC-14SA) can be used to operate the player’s various functions. SACD/CD DISPLAY TIME PROG PLAY MODE CANCEL 10/0...
- Page 11 Open the disc tray by pressing the 0 OPEN/CLOSE button, remove the disc, then close the tray by lightly pressing its front edge. Always keep the disc tray closed even when the CD player is not being used. To pause playback: Press the PAUSE button.
-
Page 12: Repeat Play
• To stop random playback and resume normal playback: Press the PLAY MODE button again. button twice in the middle • If the Each time one of these buttons is pressed, the CD player selects a track at random and starts playing that track. Light up TRACK... -
Page 13: Program Play
PROGRAM PLAY Programming (To play the desired tracks in a certain order) (Example: To program track No. 6 first, then track No. 14.) Press the PROG button in stop mode. The PROGRAM indicator flashes. Flashes PROGRAM * If the operations in step and following are not performed within 30 seconds in this mode, the unit will automatically return to the stop mode. -
Page 14: About Balanced Jacks
2. European system (Pin 2 = HOT, Pin 3 = COLD) COLD The SA-14 uses the USA system of 1. When a preamp or main amplifier adopting the European system is connected using a cable with XLR balanced connectors, the repro- duced signal may be inverted of phase. -
Page 15: Troubleshooting
In the event of difficulty, consult your dealer or write directly to the nearest location to you that is listed on the Marantz Authorized Service Station list. Please quote the model and serial number of the equipment and give a full description of what you think is abnormal about the equipment’s... -
Page 16: Front View
MODEL SA-14 FRONT VIEW POWER REAR VIEW RIGHT ANALOG LEFT OUTPUTS UNBALANCED ITT CANNON ITT CANNON BALANCED CONNECTION: GROUND COLD(-) SUPER AUDIO CD PLAYER SA-14 REP 1 TRACK PLAY PROGRAM TOTAL SACD DIGITAL REMOTE FILTER OUTPUTS CONTROL STANDARD EXTERNAL HOT(+) CUSTOM OPT. - Page 17 MODEL SA-14 TECHNICAL SPECIFICATIONS Audio Characteristics Channels Frequency range Frequency characteristics Dynamic range THD (1kHz) wow & flutter Analog output output level (unbalanced) output level (balanced) Digital output output level (cinch JACK) output level (optical) Optical Readout System Laser Wave length...
- Page 18 P.O. Box 685, Bell Village, Port Louis, Mauritius PO BOX 1280, Sandhausen 69200, Germany A division of Marantz Europe B.V., Building SFF2, P.O. Box 80002, 5600 JB Eindhoven, The Netherlands 14 Malvern Road, Mt. Albert, Auckland, New Zealand Sandkerveien 64, Oslo 0483, Norway P.O.
