Discount Car Stereo A2DIY-JAG98 Quick Start Manual

Bluetooth 1997-06 xk (x100)and 1998-03 xj (x308) with cd changer
Hide thumbs Also See for A2DIY-JAG98:

Advertisement

Quick Links

Download this manual
Courtesy of: DiscountCarStereo.com
Serving the internet community since 1995
A2DIY-JAG98
QUICK START BLUETOOTH INSTALL GUIDE FOR 1997-06 XK (X100) AND 1998-03 XJ (X308) WITH CD CHANGER
Created June 9, 2020
Revised: July 11, 2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the A2DIY-JAG98 and is the answer not in the manual?

Questions and answers

Related Manuals for Discount Car Stereo A2DIY-JAG98

Summary of Contents for Discount Car Stereo A2DIY-JAG98

  • Page 1 Courtesy of: DiscountCarStereo.com Serving the internet community since 1995 A2DIY-JAG98 QUICK START BLUETOOTH INSTALL GUIDE FOR 1997-06 XK (X100) AND 1998-03 XJ (X308) WITH CD CHANGER Created June 9, 2020 Revised: July 11, 2021...
  • Page 2 2. Locate short thick black pigtail cable on CD Auto changer. This cable Note: The A2DIY-JAG98 does not interfere with the functionality of existing leads to amplifier (premium systems) or to radio (standard systems). AM/FM/radio), and requires/retains use of the 6-disc changer.
  • Page 3 Fig. 4 6. Connect module male plug (See Fig. 4) to CD changer female connector (See Fig. 3) Note: Male right angle plug does not have an arrow; Align Fig. 2 imaginary arrow shown in Fig. 4a with arrow on factory CD female connector (See Fig.
  • Page 4 Routing Audio cable (sedan) Use pry tool to open gap between window pillar and rear deck as seen in Fig. 5. From inside trunk fish audio plug (See Fig. 4) through and into the cabin. (See Fig. 6) Fig. 8 Fig.
  • Page 5 Installing Bluetooth Module In our 2001 XJR test vehicle with Premium Audio, the Bluetooth module was installed in armrest (See Fig. 10). In this area you will also find factory phone plug (See Fig. 11) and cigar lighter, either of which can be used to power module (see Fig.

  • Page 6: Aux Input

    Fig. 14 Audio cable Fig. 13 4. Secure module and proceed to next section Playback options explained These options are available at checkout: Fig. 15 1. Retain changer playback (default) Module 2. Auxiliary input (instead of changer playback) Retain Changer playback 3.
  • Page 7 Optional USB “Fast Charge” Kit 2. Insert male terminal from supplied 3ft. cable (See Fig. 19) through hole (not for thumb drives etc.) created in step 1 and connect to installation harness charging port (See Fig. 20) Fig. 19 Flush mount 3 ft. USB cable Fig.

  • Page 8: Bracket Mount

    Locate a flat surface at location of choice within 3.2 ft. of module to Bluetooth feature comparison: mount USB support bracket (See Fig. 23) using adhesive/tape or screws (included). Feature JAG-HF JAGCD-HF BT45-JAG A2DIY-JAG98 A2DIY-JAG98R CD changer retention ✓ ✓ ✓ Audio input (aux) ✓...
  • Page 9 Bluetooth Media button Media button Operation: Pairing media button: Once paired with smartphone/Tablet, users may perform the following functions Ensure Bluetooth is enabled on your device (e.g., on iOS devices with Bluetooth 3.0 and later and Android 4.0 or later. Smartphone/Tablet etc.) scan/search for available devices and select BT009 These functions do not apply to the Jaguar radio.

  • Page 10: Test Operation

    XJ and 2000-06 XK and 2000-03 XJ Standard audio system. 2000+ Press radio “CD” button. vehicles with Premium Audio system (amplifier in trunk—See Fig. 28) require our A2DIY-JAG98. To be clear, any 1997-06 XK and 2000-03 XJ with premium audio (amplifier in trunk) requires the A2DIY-JAG98. I Fig. 27 3.
  • Page 11 Tap next Next to LANNI, then tap Name Enter a new name (e.g. Jaguar-BT etc.) tap Done on keyboard, then tap © 1995-Jul-21 Discount Car Stereo, Inc. All rights reserved. Information in this document is The custom name given now appears in Bluetooth settings of your device.
