User Manual
WHAT'S INCLUDED

SECTION 1: WARNINGS

- The Nozzle of the 3Doodler Create+
can become hot. DO NOT touch
the Nozzle, or you may be burned!
- DO NOT allow the Nozzle near or in
contact with flammable materials.
- Inform others in the area that the Pen
is hot and should not be touched.
Unplug and set the Control Switch
to OFF when not in use or before
storing.
Allow the Nozzle to cool
completely before storing.
The Unblocking Tool can become
hot. DO NOT touch the metal part
of the Unblocking Tool after using
it to clean your 3Doodler Create+
or you may burn yourself!
ADULT USE ONLY. KEEP OUT OF REACH OF CHILDREN.
Disposal of this product
At the end of your 3Doodler Create+'s life, please do not dispose of it
in your general household waste. In order to prevent possible harm to
the environment or human health from uncontrolled waste disposal,
please dispose of your 3Doodler Create+ separately in accordance
with local laws and regulations.
02/2022
3Doodler
Create+ Pen
75 strands of
3Doodler 3mm
PLA Refills
Colors may vary
DO NOT use the 3Doodler Create+
near bathtubs, showers, basins or
other vessels containing water.
This could result in death due to
electric shock.
The 3Doodler Create+ should only be
used with 3Doodler Create+ plastic
filament. Misuse of your 3Doodler
Create+, setting your pen to the
wrong heating temperature, or use
of non-approved plastic filament
or other materials may result in
damage to your pen or injury to
you, and will void your warranty.
Injuries to the user may include, but
are not limited to, harm sustained
from inhaling substances that are
not suitable for heating; or burns
from flammable materials used in
the 3Doodler Create+.
For more information on the separate collection systems for waste
of electrical and electronic equipment, please contact your local
municipal authority. You can also contact the retailer from which
you purchased your 3Doodler Create+, who may have a recycling
program, or be part of a specific recycling scheme that you can use.
Unblocking
Tool
Power
Adapter
Nozzle
Spanner
WARNING: This 3D Printing
Device, when used with a styrene
filament (ABS / HIPS / or PC-ABS),
can expose you and others in the
same room to styrene, which is
a chemical known to the State of
California to cause cancer. For
more information, go to
www.P65Warnings.ca.gov.
ALWAYS OPERATE YOUR 3D
PRINTING DEVICE IN A WELL-
VENTILATED AREA.
1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Create+ and is the answer not in the manual?

Questions and answers

Related Manuals for 3Doodler Create+

Summary of Contents for 3Doodler Create+

  • Page 1: Section 1: Warnings

    Disposal of this product For more information on the separate collection systems for waste At the end of your 3Doodler Create+’s life, please do not dispose of it in your general household waste. In order to prevent possible harm to...

  • Page 2: Section 2: Getting Started

    Reversing plastic How it Works: The 3Doodler Create+ melts plastic filament and uses a motor and gears to push it through the pen’s nozzle in a thin line. This process is called extruding or extrusion, and we will refer to it throughout this user manual.
  • Page 3 SECTION 2: GETTING STARTED STEP 2: Load and extrude GREEN Light plastic With the LED light GREEN, Select one strand of Click either speed button plastic (included in the box). once and release. You will hear insert the PLA strand into the the drive gear start.
  • Page 4 SNIP THOSE ENDS! After removing a plastic strand from the 3Doodler Create+, cut and dispose of any partially melted material at the end of your strand. This will reduce blockages and clogging issues.

  • Page 5: Take A Break

    Plastic that is shorter than 5.3 inches cannot be reversed. You should feed it all the way through your 3Doodler Create+ and use it up. Or you can push the plastic out the back of the pen using your unblocking tool - See Section 3, Step 3B.)
  • Page 6 NOTE: If you have a spare power adapter please use it to test your 3Doodler Create+. You will need a DC 5V2A power supply with a 3.5mm barrel. This will help determine if the problem is with your 3D pen or with the included power adapter.
  • Page 7 SECTION 3: TROUBLESHOOTING The plastic may be wrapped around the drive gear. Maintenance Mini Cover Screwdriver Remove the maintenance cover using a Use a mini screwdriver or unblocking mini screwdriver. tool to lift and clear the plastic strand from the drive gear through the open area beneath the maintenance cover or from the plastic loading port.

  • Page 8: Section 4: Tips And Best Practices

    Do not forget • After removing a strand of plastic from the 3Doodler Create+, cut and discard any partially melted material at the end of to snip your the strand. This will reduce blockages or clogging issues.
  • Page 9 TAKE A Give your 3Doodler Create+ a rest after every 2 hours of continuous BREAK: Doodling. 30 minutes of down time should be plenty. Treat your •...

  • Page 10: Section 5: Stencils

    SECTION 5: STENCILS SECTION 5: STENCILS Eiffel Tower 02/2022...
  • Page 11 SECTION 5: STENCILS Glasses 02/2022...
