Blue Thumb Pump Specifications

Model
Power (Watt)
MD 120
7
MD 180
9.5
MD 290
16
MD 370
24
MD 530
33
MD 660
43
MD 798
58
MD 1110
92
MD 1300
110
MD 1495
153
MD 1980
250
* Wattage will vary based on head pressure.
OWNER'S
MANUAL
Flow (GPH)
Max. Head (Feet)
120
2.60
180
4.70
290
5.95
370
7.60
530
7.92
660
8.82
798
9.30
1110
12.20
1300
13.50
1495
16.70
1980
20.00
Current (Amp)
Cord Length
0.08
6 ft
0.12
6 ft
0.23
16 ft
0.40
16 ft
0.55
20 ft
0.73
20 ft
0.80
20 ft
0.85
20 ft
1.00
20 ft
1.46
20 ft
2.60
20 ft
Models
Mag-Drive 120
Mag-Drive 180
Mag-Drive 290
Mag-Drive 370
Mag-Drive 530
Mag-Drive 660
Mag-Drive 800
Mag-Drive 1110
Mag-Drive 1300
Mag-Drive 1495
Mag-Drive 1980
Outlet
¾ in
¾ in
1 in
1 in
1 in
1 in
1 in
1 in
1¼ in
1¼ in
1¼ in

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mag-Drive 120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Blue Thumb Mag-Drive 120

  • Page 1 Mag-Drive 180 Mag-Drive 290 Mag-Drive 370 Mag-Drive 530 Mag-Drive 660 Mag-Drive 800 Mag-Drive 1110 Mag-Drive 1300 Mag-Drive 1495 Mag-Drive 1980 Blue Thumb Pump Specifications Model Power (Watt) Flow (GPH) Max. Head (Feet) Current (Amp) Cord Length Outlet MD 120 2.60 0.08...
  • Page 2 You have purchased a quality pump from Blue Thumb, Manufacturers of Quality Pond Products. If you experience trouble with your pump please reference the Troubleshooting section of this manual. If you are unable to remedy the problem please contact your local Blue Thumb dealer for further assistance. IMPORTANT...
  • Page 3 6. TROUBLESHOOTING Before taking any troubleshooting action, disconnect the pump from the power supply by removing the plug from the socket. Problem Possible causes Solutions The pump does not run. • Power cord unplugged. • Plug cord securely into the socket and check if there is voltage on the line.
  • Page 4 60 days of purchase). Replacement liability in all events is limited to replacing or repairing at Blue Thumb’s sole discretion of any part or parts which are defective in material or workmanship. Proof of purchase is required on all claims in the form of invoice copy, sales ticket, etc. Warranty void if pump is not installed as per these instructions.
