- Page 1 ED-2000plus Electronic Dynamometer with HR-2000 Remote User’s Manual...
- Page 2 EUROPEAN COUNTRIES WARNING This is a Class A product. In a domestic environment this product may cause radio interference in which the user may be required to take adequate measures. CAUTION Risk of electrical shock. Do not remove cover. No user service- able parts inside.
-
Page 3: Table Of Contents
Table of Contents Table of Contents .................... 3 Specifications ....................4 ED-2000plus Introduction ................5 Normal Operation Mode ............... 6 RS-232 Operation ................7 Device Information Mode ..............8 Configuration Mode ................9 Disabling the Radio-Link Software to Save Battery Power ..10 Sleep Mode ................ -
Page 4: Specifications
On/Off, Test, Clear/Zero, Peak hold, Function key, Units Power: Standard 9V battery, alkaline or lithium. The ED-2000plus has approximately 200 hours of use with the 9V alkaline battery. Battery life can be extended with the use of a 9V lithium battery. These values represent “average” use;... -
Page 5: Ed-2000Plus Introduction
(up to 255) devices controlled by a single HR-2000 display. This is called a multidrop system. Data can be extracted from either the ED-2000plus or the HR-2000. This data can be sent to a computer by pressing the DATA SEND key or requested by The ED-2000plus is not suit- the computer by sending an ENQUIRE code. -
Page 6: Normal Operation Mode
Reads net force value. Can be positive or negative. Can tare up to 100% of capacity. SEND DATA Send displayed information via RS-232 No change in the display. Not used with the ED-2000plus F+CLR/ZERO Reverts to gross reading. Shows the gross force value. UNITS... -
Page 7: Rs-232 Operation
You can operate the ED-2000plus with a computer or other data logging RS-232 Operation device via RS-232. To place the ED-2000plus in RS-232 mode, use one hand to press and hold the F key and use the other hand to press the ON key. -
Page 8: Device Information Mode
To acitvate the device information mode from normal operating mode use one Device Information hand to press and hold the F key and use the other hand to press the UNITS Mode key. Return to normal operations by using one hand to press and hold the F key and use the other hand to press the CLR/ZERO key. -
Page 9: Configuration Mode
To activate the configuration mode from normal operation, use one hand to Configuration Mode press and hold the F key and use the other hand to press the TEST key. Return to normal operations by using one hand to press and hold the F key and use the other hand to press the CLR/ZERO key. -
Page 10: Disabling The Radio-Link Software To Save Battery Power
Power the Radio-Link option, disable the software. To disable the Radio-Link software see the SErch section in Table 5 below. Notice that the change will not take effect until the ED-2000plus has been switched off and then back on. Label... -
Page 11: Battery Replacement
When the low battery annunciator appears, you have approximately five hours Battery Replacement of usage left. To change the nine-volt battery in the ED-2000plus, follow these steps: 1. Remove the two knurled thumb screws from the battery compartment cover. (Be careful not to lose these screws.) See Figure 6. -
Page 12: Hr-2000 Introduction And Operation
Addresses reading. The ED-2000plus looks at the poll signal that the remote sent and determines if the address matches. If it does match, the ED-2000plus re- High frequency signals are sponds with its reading. -
Page 13: Operation
When communication is established and working properly the display will wants to transmit a message mirror the ED-2000plus display and the leftmost decimal point will blink every and is waiting for access or for ½ second. If communication is broken, the display will flash a small o in the an answer. -
Page 14: Radio Operation With Rs-232
SEND key on the HR-2000. In listen mode, the HR-2000 waits to receive an enquire code from the exter- nal device, polls the ED-2000plus for the information, then returns it to the external device. To enter listen mode, use one hand to press and hold the F key and use the The force value received is right other hand to press the ALT key. -
Page 15: For Wireline Communication
You can set the address for each HR-2000 and ED-2000plus operating in a Addressing Mode given area so that they can work without interference. If several systems are operating in the same airspace each HR-2000 and ED-2000 must have a unique address. - Page 16 The Destination address must dress. match with the address entered 1. With one hand, press and hold in the ED-2000plus. This value the F key and use the other hand has a default of 100. to press the ON/OFF key. . .
- Page 17 · A Poll value of zero places the remote in Manual Poll mode. The remote will only poll the instrument when the UNITS key is pressed by the operator. The ED-2000plus will reply and the HR will display the reading until the unit is polled again (or until the screen blanks after ten seconds of non communication).
-
Page 18: Appendix - Weighing And Force Measurement Practice
Safety limit your liability always insist upon factory supplied shackles and pins and factory tested and certified safe optional equipment. All DILLON products are designed to meet the published Safe Working Load (SWL) and Ultimate Safety Factor (USF) standards of the United States Military. -
Page 19: Good Force Measurement Practice
Good Force Measurement Practice... - Page 20 Dillon A division of Weigh-Tronix Inc. 1000 Armstrong Dr. Fairmont, MN 56031 USA Telephone: 507-238-4461 Facsimile: 507-238-8258 e-mail: dillon@weigh-tronix.com www.dillon-force.com Force Measurement Products & Systems...
