Mechanical Specifications

17.1.

Physical Parameters

TABLE 13 – PHYSICAL PARAMETERS
Dimensions, J3 & J5
Dimensions, J3 & J5
unpopulated
17.2.

Mechanical Drawings

Within this section are mechanical drawings provided for the purpose of understanding the general size,
shape, and layout of the epConnected Asset device. For the most complete & up-to-date documentation on
mechanical drawings, along with more on the epConnected Asset device, please refer to the materials
provided at https://www.embeddedplanet.com/product-documentation.
Embedded Planet, Inc. | 31225 Bainbridge Rd Suite N, Solon, OH 44139 | 216-245-4180 | www.embeddedplanet.com | Page 28 of 37
epConnected Asset | Product User Manual
Parameter
With JST connector and expansion
populated
Description
header
No JST connector or expansion
header
Document Version: 1.0.0 | 26 Jan 22
Length Width
28.40mm 56.5mm
28.40mm 56.5mm
Height
12.67mm
10.24mm
