6. Device Specifications

TABLE 5 – DEVICE SPECIFICATIONS
Feature/Specification
Cellular Capabilities
Internet Protocols
LTE CAT M1 Specification
SIM
Cellular Certifications
GNSS Specifications
Power Supply
Dimensions
Environmental
Cellular Technologies: LTE-M (LTE CAT M1)
SMS: over NAS
Lower power modes: PSM, eDRX
Operating Frequencies: 699MHz to 1980MHz
Cellular Operating Mode: Half-duplex FDD
RF Output Power: Up to +20dBm (Power Class 5)
IPv4/IPv6 stack with TCP and UDP protocols
TLDS/DTLS
Bands: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B25, B26, B27, B28, B66, B71, B85
RX Sensitivity CAT M1: -102.2 to -107.5 dBm depending on band
Uplink: up to 1Mbps
Downlink: up to 588kbps
Removable: 4FF (nano) SIM card slot
Soldered down: MFF2
Internal: Telit simWISE™
PTCRB: Complete (Chronos)
AT&T: Complete (Chronos)
Verizon: Complete (Chronos)
Constellations: GPS, GLONASS, BeiDou, Galileo, QZSS
Tracking Sensitivity: -159dBm
Navigation Sensitivity: -155dBm
Cold Start Sensitivity: -144dBm
For battery charging: 3.75Vdc to 5.5Vdc into J2 (USB connector)
For device operation: 3.2Vdc-4.2Vdc into J3 (JST battery connector/through-holes)
3.7Vdc nominal
Fully populated board: 46.4mm x 38.4mm x 12.67mm (1.83in x 1.51in x 0.50in)
Operating Temperature Range: -40°C to +85°C
Storage Temperature Range: -40°C to +85°C
Humidity Range: 20% RH to 90% RH
Description
