Summary of Contents for LG LRSC26925SW, LSRC26923SW, LRSC26925TT, LSRC26923TT

  • Page 2: Table Of Contents

    Table of Contents Introduction Installation Operation Suggestion on Food Storage Care and Maintenance...

  • Page 3: Introduction

    Introduction...
  • Page 5 Introduction...

  • Page 6: Identification Of Parts

    Door Rack Lower Cover NOTE If you find some parts missing from your unit, they may be parts only used in other • models. (i.c. the Optichill is not included in all models) Refrigerator Compartment Introduction Dairy Corner Water Filter Lamp...

  • Page 7: Installation

    2. Avoid placing the unit near heat sources, direct sunlight, or moisture. 3. To avoid vibrations, the appliance must be leveled. 4. Do not install this refrigerator in areas where the ambient temperature is below 41 F. It will have an adverse effect on performance.

  • Page 8: Door Removal

    NOTE • After removing the door, take it into the kitchen where you are installing the refrigerator. Lay it down on a blanket and be careful to avoid damaging the water feed tube. Remove the 1) Loosen the hinge cover screws and remove the cover.

  • Page 9: Door Replacement

    Move the Refrigerator entrance door as shown in the right picture. Door replacement Mount the doors in the reverse order of removal after the refrigerator is brought to the installation area. Feed water tube installation Before Automatic icemaker operation needs water pressure of 21.3~121psi(lb/inch Installation is, a 7oz.

  • Page 10: Water Connection Instruction Guide

    1/4-inch drill bit Hand drill or electric drill (properly grounded) NOTE Your refrigerator dealer has a kit available with a 1/4-inch saddle-type shut-off valve, • a union, and copper tubing. Before purchasing, make sure a saddle-type valve complies with your local plumbing codes. Do not use a piercing-type or 3/16-inch saddle valve which reduces water flow and clogs more easily.
  • Page 11 4. To determine the length of copper tubing you will need, measure from the connection on the lower left rear of the refrigerator to the water pipe. Add 7 feet (2.1m) to allow for moving refrigerator for cleaning. Use 1/4-inch O.D.

  • Page 12: Operation Instruction Guide

    Tighten any connections that leak. the Shutoff Valve Plug In the Refrigerator Arrange the coil of copper tubing behind the refrigerator so it does not vibrate against the back of the refrigerator or against the wall. Push the refrigerator back to the wall.
  • Page 13 The first ice and water may include particles or odor from the feed water pipe or feed water box. This is also necessary if the refrigerator has not been used for a long time. Never store beverage cans or other foods in ice storage bin for the purpose of rapid cooling.

  • Page 14: Height Adjustment

    After leveling the The refrigerator doors will close smoothly by adjusting the height adjusting screw. If door height the doors do not close correctly, performance may be affected. Next 1. Wipe off all dust accumulated during shipping and clean your appliance thoroughly.

  • Page 15: Operation

    Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting The Temperatures and Functions...
  • Page 16 To deactivate this mode is same as the activation methods. The mode inactivates when resetting the power. 3. To change temperature display from Fahrenheit to Celsius press and hold “FREEZER” and “REFRIGERATOR” buttons simultaneously for more than 5 seconds. Do the same to convert back to Celsius. Operation...
  • Page 17 The actual inner temperature varies depending on the food status, as the indicated setting temperature is the target temperature, not actual temperature within refrigerator. Please adjust temperature as above after using refrigerator for minimum 2~3 days. Dispenser You can select water or ice.
  • Page 18 After the machine is powered again, crushed ice will be automatically selected. The unit is newly installed It takes about 12 hours for a newly installed refrigerator to make ice. Jet Freezer Please select this function for prompt freezer.
  • Page 19 121 F is indicated with HI. Door open warning A warning tone will sound 3 times at thirty-second intervals if the refrigerator or freezer door is left open for more than sixty seconds. Please contact with the local service center if warning continue to sound even after closing the door.
  • Page 20 Throw away the ice (about 20 pieces) and water (about 7 glasses) first made after Cautions refrigerator installation. This is also necessary when the refrigerator has not been used for a long time. Keep children away from the dispenser. Children may play with or damage the controls.

  • Page 21: Wine Holder

    Operation Shelf Shelf Height The refrigerator compartment shelf is movable so that you can place it at a height Adjustment according to space requirement of foods. Slide Shelf Pull the shelf ahead and take off it while lifting both front and rear part.

  • Page 22: Humidity Control In The Vegetable Compartment

    Egg Bin (Applicable to some models only) You can place the egg box wherever you want it. [Normal] NOTE Never use the egg box as an ice storage bin. It can be broken. • Never store the egg box in the freezer compartment or fresh compartment. •...

  • Page 23: Applicable To Some Models Only

    If you open the refrigerator door, an indicator lamp shows the status of the Optichill. The lamp goes off when the door is closed. Press the left SELECT button to cycle through FRUIT VEGE(39°F) CHILLED ROOM(30°F) PARTIAL FREEZING(27°F) FRUIT VEGE(39°F).

  • Page 24: Suggestion On

    Egg Bin Place this egg box in the proper location. Refreshment Store foods of frequent use such as beverage, etc. Center Refrigerator Store side dishes or other foods at a proper distance. Compartment Shelf Refrigerator Store small packed food or beverages such Compartment as milk, juice, beer, etc.

  • Page 25: Food Storage

    NOTE • If you keep the refrigerator in a hot and humid place, frequent opening of the door or storing a lot of vegetables in it may cause condensation to form. Remove the condensation with dust cloth free from care.

  • Page 26: Care And

    Compartment slightly striking Turn the bulb counterclockwise. Max. 40 W bulb Lamp for refrigerator is used and can be purchased at a service center. Dispenser Lamp Seperate the lamp by pulling it out, and then remove the lamp. Max. 15 W bulb for refrigerator is used and can be purchased at a service center.
  • Page 27 To remove the lamp cover, press the protrusion under the lamp cover to the front and Lamp in then pull the lamp cover out. Refrigerator Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be Compartment purchased at a service center. NOTE Be sure to remove parts from the refrigerator door when removing the vegetable •...

  • Page 28: Maintenance

    General Information During average length vacations, you will probably find it best to leave the refrigerator Vacation Time in operation. Place freezable items in freezer for longer life. When you plan to store the refrigerator, remove all food, disconnect the power cord, clean the interior thoroughly, and Block the doors open to prevent mold and mildew.

  • Page 29: Troubleshooting

    Call local electric company. This is normal. Larger, more efficient units run longer in these conditions. It is normal for the refrigerator to work longer under these conditions. It takes some hours for the refrigerator to cool down completely.
  • Page 30 Set the freezer or refrigerator control to a colder setting until the freezer or refrigerator temperature is satisfactory. Set the freezer or refrigerator control to a colder setting until the freezer or refrigerator temperature is satisfactory. Warm air enters the refrigerator/ freezer whenever the door is opened.
  • Page 31 Vibrating or Floor is uneven or weak. rattling noise. Refrigerator rocks on the floor when it is moved slightly. Items placed on the top of the refrigerator are vibrating. Dishes are vibrating on the shelves in the refrigerator.
  • Page 32 Occurrence Possible cause Odors in refrigerator Interior needs to be cleaned. Food with strong odor is in the refrigerator. Some containers and wrapping materials produce odors. Opening/Closing of doors/Drawers Door(s) will not Food package is keeping door open. close. Door(s) will not Door was closed too hard, causing other close.
  • Page 33 To Obtain Nearest Authorized Service Center Call 1-800-243-0000, push option #1, 24 hours a day, 7days per week. Please have your product type (Monitor, TV, VCR, MWO, Refrigerator) and ZIP code ready. Possible cause Remove ice storage bin, and thaw and the contents.
  • Page 34 LG ELECTRONICS, INC. LG REFRIGERATOR LIMITED WARRANTY - USA...
  • Page 35 Notes...
