Supported Commands
The switcher can be controlled from a remote device or computer via GV Grass Valley
These commands can either be sent to the switcher over a serial or Telnet connection.
Sending GVG100 LUA Commands to the Switcher
The switcher accepts direct injection of GVG100 commands using LUA via a Telnet connection. This allows you
to perform various functions such as querying the switcher for the state of buttons, or sending commands to
the switcher, such as transitioning a key.
To Set the Switcher to Editor Mode
Tip:
You can quickly turn off editor mode by pressing and holding the MENU button and pressing PERS.
1. Press MENU > Pers.
2. Use the Editor knob to select On to allow the switcher to be controlled by an external editor.
GVG100 Command Modes
The switcher supports two modes of operation, a Legacy mode for basic GVG100 commands, and a Ross mode
for additional Ross-specific extensions to the protocol.
• Legacy Mode — allows basic control over a single ME (ME 1) and the first two keyers (Key 1 and Key 2) on
that ME
• Ross Mode — allows advanced control over multiple MEs, keyers, and aux buses.
To Send GVG Commands to the Switcher
1. Create a connection to the switcher.
• Telnet — Create a Telnet connection to the switcher on port 2100. The default IP address of the switcher
is 192.168.0.123.
• Serial — Open a serial connection to the switcher editor port. Refer to the GV Grass Valley
sheet for information on connecting to an editor over a serial connection.
2. At the
gvg100>
• injectGVG100command("") — Sends a GVG100 command to the switcher.
• print() — Prints the value of any arguments as strings, or prints "nil" if an argument is not a string.
• printhelp() — Prints detailed help on all available commands.
• printhex() — Prints the value of number arguments as hex strings. If the argument is not a number
then "nan" is printed. If the argument is not an unsigned integer (a float or a negative number) then
"notUInt" is printed.
• setGVG100legacymode() — Switches between GVG100 legacy mode (true) and Ross mode (false)
command interpretation.
Example Commands
• setGVGlegacymode(false) — sets Ross Mode.
©
®
2021 Ross Video Limited. Ross
, MiniME , and any related marks are trademarks or registered trademarks of Ross Video Limited. All other trademarks are the property of their respective companies. PATENTS ISSUED and PENDING. All rights reserved. No
part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, mechanical, photocopying, recording or otherwise, without the prior written permission of Ross Video. While every precaution has been
taken in the preparation of this document, Ross Video assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.
prompt, enter the commands you want to run.
GVG100
®
GVG100 commands.
®
GVG100 setup
4802DR-401--05
