COMPACT AIR
COMPRESSOR
24 L 2.0HP
INSTRUCTION MANUAL
SPECIFICATIONS
Input:
230–240V ~ 50Hz
Motor:
1500W S3:25%
No Load Speed:
4,000/min
Tank Volume:
24 litres
Max. Pressure:
10 bar (145psi)
Max. Air Delivery: 173 l/min
@ 4 Bar: 107 l/min
@ 7 Bar: 76 l/min
IP Rating:
IP20
Weight:
16.2kg
ozito.com.au
WHAT'S IN THE BOX
Compact Air Compressor
Wheels x 2, Hub Cap x 2,
Axle x 1, Caps x 2
Support Foot
ACP-2419
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ozito ACP-2419
Summary of Contents for Ozito ACP-2419
- Page 1 Wheels x 2, Hub Cap x 2, Tank Volume: 24 litres Max. Pressure: 10 bar (145psi) Axle x 1, Caps x 2 Max. Air Delivery: 173 l/min @ 4 Bar: 107 l/min @ 7 Bar: 76 l/min IP Rating: IP20 Weight: 16.2kg Support Foot ozito.com.au ACP-2419...
-
Page 2: Know Your Product
4. Quick-release air outlet 11. Hub caps • Examine the machine for signs of transit damage. If damaged, do not use, contact Ozito . 5. Support foot 12. Axle • The compressor should be set up near the area of use. -
Page 3: Operation
OPERATION 2. OPERATION Switching On/Off Fitting the supporting foot Note: It is recommended that the power supply is protected by a 1. Screw the supporting foot in the Residual Current Device (RCD) of rating not exceeding 30mA. supporting foot bracket. 1. -
Page 4: Checking The Safety Valve
Preset pressure Checking the safety valve The minimum and maximum preset tank pressure is set at the factory WARNING!: WEAR SAFETY GLASSES AND EAR and the operator should not alter it. PROTECTION. KEEP YOUR FACE AWAY FROM THE SAFETY VALVE WHEN CARRYING OUT THIS CHECK. Switch-on pressure approx. -
Page 5: Troubleshooting
2. Leak in a quick-lock 2. Check the quick- coupling lock coupling and replace if necessary. 3. Insufficient pressure 3. Open the set on the pressure pressure regulator. regulator further. ACP-2419... -
Page 6: Cleaning And Maintenance
MAINTENANCE 4. CLEANING & MAINTENANCE Removing IMPORTANT! BEFORE CLEANING YOUR OIL FREE AIR condensation water COMPRESSOR OR CARRYING OUT ANY MAINTENANCE PROCEDURE, MAKE SURE THAT THE MOTOR IS OFF AND The condensation water must be THE TOOL DISCONNECTED FROM THE POWER SUPPLY drained off after each use by opening TO PREVENT ACCIDENTAL STARTING. -
Page 7: Description Of Symbols
Spare parts can be ordered from the Special Orders Desk at your local Bunnings Warehouse. For further information, or any parts not listed here, visit www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 New Zealand 0508 069 486... -
Page 8: Electrical Safety
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. -
Page 9: Warranty
Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 0815...
